Lux Tools ZKGS-1600 Manuale utente
3
7
3
4
10
65
1
8
9
2
1
11
20
19
18
16
17
12
1514
13
2
temp.book Seite 3 Donnerstag, 7. April 2016 9:58 09
4
18
19
11
3
16 22
23
7
21
3
4
temp.book Seite 4 Donnerstag, 7. April 2016 9:58 09
5
31
31
5
25
24
6
temp.book Seite 5 Donnerstag, 7. April 2016 9:58 09
6
6
26
4
5
7
9
27
8
temp.book Seite 6 Donnerstag, 7. April 2016 9:58 09
7
9
1
19
20
3
17
28
2
19
10
temp.book Seite 7 Donnerstag, 7. April 2016 9:58 09
8
32
11
29 3031
12
2
3
13
temp.book Seite 8 Donnerstag, 7. April 2016 9:58 09
9
Original instructionsTrim, crosscut and mitre saw
Table of contents
Before you begin… . . . . . . . . . . . . . . . . . 9
For your safety . . . . . . . . . . . . . . . . . . . . 9
Your product at a glance . . . . . . . . . . . 13
Assembly . . . . . . . . . . . . . . . . . . . . . . . . 14
Operation . . . . . . . . . . . . . . . . . . . . . . . . 14
Cleaning and maintenance . . . . . . . . . 16
Storage and transport . . . . . . . . . . . . . 17
Troubleshooting . . . . . . . . . . . . . . . . . . 17
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . 18
Technical data . . . . . . . . . . . . . . . . . . . . 18
Claims for defects. . . . . . . . . . . . . . . . . 34
Before you begin…
Intended use
The device is intended for cross cuts, mitred
cuts, inclined cuts and double mitre cuts in
elongated workpieces such as profiles and
strips.
Only materials for which the corresponding
saw blade is permitted can be processed.
This product is not intended for commercial
use. Generally acknowledged accident pre-
vention regulations and enclosed safety
instructions must be observed.
Only perform work described in these
instructions for use. Any other use is
improper. The manufacturer will not assume
responsibility for damage resulting from such
use.
What are the meanings of the symbols
used?
Danger notices and information are clearly
marked throughout these instructions for
use. The following symbols are used:
These symbols identify the required personal
protection equipment:
For your safety
General safety instructions
• To operate this device safely, the user
must have read and understood these
instructions for use before using the
device for the first time.
• If you sell or pass the device on, you must
also hand over these operating instruc-
tions.
General power tool safety warnings
• Save all warnings and instructions for
future reference. The term power tool
in the warnings refers to your mains oper-
ated (corded) power tool or battery oper-
ated (cordless) power tool.
Work area safety
• Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
• Do not operate power tools in explo-
sive atmospheres, such as in the pres-
ence of flammable liquids, gases or
dust. Power tools create sparks which
may ignite the dust or fumes.
• Keep children and bystanders away
while operating a power tool. Distrac-
tions can cause you to lose control.
Electrical safety
• Power tool plugs must match the out-
let. Never modify the plug in any way.
Do not use any adapter plugs with
earthed (grounded) power tools.
Unmodified plugs and matching outlets
will reduce risk of electric shock.
• Avoid body contact with earthed or
grounded surfaces such as pipes, radi-
ators, ranges and refrigerators. There
is an increased risk of electric shock if
your body is earthed or grounded.
DANGER! Direct danger to life and
risk of injury! Directly dangerous
situation that may lead to death or
severe injuries.
WARNING! Probable danger to life
and risk of injury! Generally dan-
gerous situation that may lead to
death or severe injuries.
CAUTION! Possible risk of injury!
Dangerous situation that may lead to
injuries.
NOTICE! Risk of damage to the
device! Situation that may lead to
property damage.
Note: Information to help you reach
a better understanding of the pro-
cesses involved.
WARNING! Read all safety warn-
ings and all instructions. Failure to
follow the warnings and instructions
may result in electric shock, fire and/
or serious injury.
GB
temp.book Seite 9 Donnerstag, 7. April 2016 9:58 09
10
• Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric
shock.
• Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase
the risk of electric shock.
• When operating a power tool out-
doors, use an extension cord suitable
for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of elec-
tric shock.
• If operating a power tools in a damp
location is unavoidable, use a residual
current device (RCD) protected sup-
ply. Use of an RCD reduces the risk of
electric shock.
Personal safety
• Stay alert, watch what you are doing
and use common sense when operat-
ing a power tool. Do not use a power
tool while you are tired or under the
influence of drugs, alcohol or medica-
tion. A moment of inattention while oper-
ating power tools may result in serious
personal injury.
• Use personal protective equipment.
Always wear eye protection. Protec-
tive equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate condi-
tions will reduce personal injuries.
• Prevent unintentional starting. Ensure
the switch is in the off-position before
connecting to power source and/or
battery pack, picking up or carrying
the tool. Carrying power tools with your
finger on the switch or energizing power
tools that have the switch on invites acci-
dents.
• Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a rotating
part of the power tool may result in per-
sonal injury.
• Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in unex-
pected situations.
• Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
• If devices are provided for the connec-
tion of dust extraction and collection
facilities, ensure these are connected
and properly used. Use of these devices
can reduce dust-related hazards.
Power tool use and care
• Do not force the power tool. Use the
correct power tool for your applica-
tion. The correct power tool will do the
job better and safer at the rate for which
it was designed.
• Do not use the power tool if the switch
does not turn it on and off. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
• Disconnect the plug from the power
source and/or the battery pack from
the power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of start-
ing the power tool accidentally.
• Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
• Maintain power tools. Check for mis-
alignment or binding of moving parts,
breakage of parts and any other condi-
tion that may affect the power tool’s
operation. If damaged, have the power
tool repaired before use. Many acci-
dents are caused by poorly maintained
power tools.
• Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
• Use the power tool, accessories and
tool bits etc. in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
Service
• Have your power tool serviced by a
qualified repair person using only iden-
tical replacement parts. This will ensure
that the safety of the power tool is main-
tained.
GB
temp.book Seite 10 Donnerstag, 7. April 2016 9:58 09
