MerCs Strider M8 Manuale utente
1
02 4047 0777 www.mercs.com.au02 4047 0788
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
• Two taris shifting controlled by 240VAC Input Signal
• 1A/5A CT connection
• Backlit LCD screen
• Programmable CT/PT ratio
• Pulse output and Modbus
• High sensitive touch buttons
• MID version optional
Features
MerCs Strider M8
Instruction Manual
ME-PM-630MCT-2T
The Unit can measure and display:
Unit Characteristics
• Voltage and THD% (total harmonic distortion) of all phases
• Line frequency
• Currents,current demand and current THD% of all phases
• Power, maximum power demand and power factor
• Active energy imported and exported
• Reactive energy imported and exported
Introduction
The MerCs Strider M8 is a three phase multifunction DIN rail meter. It can measure and display the characteristics of 1p2w,3p3w and 3p4w sup-
plies, including voltage, current, power, active and reactive energy imported or exported. Energy is measured in terms of kWh, kVarh. Max demand
current can be measured over preset periods of up to 60 minutes. The MerCs Strider M8 also has dual taris function. It is an idea product for
application that have two power sources . With 230VAC signal, the meter can shift the measurement from T1 to T2.
In order to measure energy, the unit requires voltage and current inputs in addition to the supply required to the power the meter. The required
current inputs are obtained via current transformers. This meter can be congurable to work with a wide range of CTs, giving the unit a wide range
of operation. Build-in interface provides pulse, RS485 Modbus RTU outputs and the conguration is password protected.
Current Transformer Primary Current RS485 Modbus RTU / M-Bus
ME-PM-630MCT Series is CT operated. y ou will need to set the
correct ratio.
As an example: If using 100/5A CT, you will need to insure CT2 (Sec-
ondary) is set to 5 and CT rate is 0020. You divide the primary by
the secondary to get the CT rate to be entered (100/5=20).
ME-PM-630MCT V2 and ME-PM-630MCT-2T V2 both meter have
a Rs485 port with Modbus RTU protocol. ME-PM-630MCT-Mbus
V2 has a M-Bus port complying with EN13757-3. Rs485 or M-Bus
provide a means of remotely monitoring and controlling the unit.
Set-up screens are provided for setting up the communication port.
02 4047 0777 www.mercs.com.au02 4047 0788 2
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Selects the Voltage and
Current display screens. In
Set-up Mode, this is the “Left”
or “Back” button.
Select the Frequency and
Power factor display screens.
In Set-up Mode, this is the “Up”
button.
Select the Power display
screens. In Set-up Mode, this is
the “Down” button.
Select the Energy display
screens. In Set-up mode, this is
the “Enter” or “Right” button.
Measurements
The buttons operate as follows:
U/I
ESC MPE
Pulse output
Two pulse outputs that pulse measured active and reactive energy.The Pulse 2 constant for active energy is 3200imp/kWh. (Terminals 11 & 12) The
pulse width for Pulse 1 can be set from the set-up menu (Terminals 9 & 10).
The first screen lights up all display seg-
ments and can be used as a display check. Software version information The interface performs a self-test and in-
dicates the result if the test passes.
Start-up Screens
*After a short delay, the screen will display active energy measurements.
C1C2
Phase to neutral voltages Current on each phase. Phase to neutral voltage THD%. Current THD% for each phase.
Voltage and Current
Each successive press of the button selects a new parameter:
U/I
ESC
02 4047 0777 www.mercs.com.au02 4047 0788 3
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Frequency and Power Factor
(total) Power Factor of each phase Maximum Power Demand Maximum Current Demand
Frequency and Power Factor and Demand
Each successive pressing of the button selects a new range:
M
Instantaneous Active Power
in kW
Instantaneous Reactive
Power in kVAr
Instantaneous Volt-Amps
in KVA Total kW, kVArh, kVA
Power
Each successive pressing of the button selects a new range:
P
Import active energy in kWh
Export active energy in kWh
Energy Measurements
Each successive pressing of the button selects a new range:
E
02 4047 0777 www.mercs.com.au02 4047 0788 4
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Import reactive energy in kVArh
Export reactive energy in kVArh
Total active energy in kWh
Total reactive energy in kVArh
T1 active energy in kWh
T2 active energy in kWh
SDM630MCT-2T V2 only:
02 4047 0777 www.mercs.com.au02 4047 0788 5
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Setting up is password protected so you must enter
the correct password (default ‘1000’) before
processing.
If an incorrect password is entered, the display will
show: PASS Err
To exit setting-up mode, press repeatedly until the measurement screen is restored.
U/I
ESC
Setting Up
To enter set-up mode, pressing the button for 3 seconds, until the password screen appears.
E
T1 reactive energy in kVArh
T2 reactive energy in kVArh
Set-up Entry Methods
Some menu items, such as password and CT, require a four-digit number entry while others, such as supply system, require selection from a number
of menu options.
02 4047 0777 www.mercs.com.au02 4047 0788 6
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Menu Option Selection
1. Use the and buttons to scroll through the dierent options of the set up menu.
2. Press to conrm your selection
3. If an item ashes, then it can be adjusted by the and buttons.
4. Having selected an option from the current layer, press to conrm your selection. The SET indicator will appear.
6. On completion of all setting up, press repeatedly until the measurement screen is restored.
5. Having completed a parameter setting, press to return to a high er menu level. The SET indicator will be removed and you will be able
to use the and buttons for further menu selection.
E
MP
MP
E
U/I
ESC
U/I
ESC
MP
When Setting up the unit, some screens require the entering of a number. In particular, on entry to the setting up section, a password must be
entered. Digits are set individually, from left to right. The procedure is as follows:
1. The current digit to be set ashes and is set using the and buttons.
2. Press to conrm each digit setting. The SET indicator appears after the last digit has been set.
3. After setting the last digit, press to exit the number setting routine. The SET indicator will be removed.
Number Entry Procedure
MP
E
U/I
ESC
Change Password
Use the and to choose the change pass-
word option.
Press the to enter the change password routine.
The new password screen will appear with the rst
digit ashing
MP
E
02 4047 0777 www.mercs.com.au02 4047 0788 7
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Use and to set the rst digit and
press to conrm your selection. The next
digit will ash.
Repeat the procedure for the remaining three digits.
After setting the last digit, SET will show.
MP
E
Press to exit the number setting routine and return to the Set-up menu. SET will be removed
U/I
ESC
DIT Demand Integration Time
This sets the period in minutes over which the current and power readings are integrated for maximum demand measurement. The options are: o,
5, 8, 10, 15 20, 30, 60 minutes
From the set up menu, use and buttons
to select the DIT option. The screen will show the cur-
rently selected integration time.
Press to enter the selection routine. The cur-
rent time interval will ash
MP
E
02 4047 0777 www.mercs.com.au02 4047 0788 8
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Use and buttons to select the time
required.
Press to conrm the selection.
SET indicator will appear.
MP
E
Press to exit the DIT selection routine and return to the menu
U/I
ESC
Supply System
This Unit has a default setting of 3 Phase 4 wire (3P4).
Use this section to set the type of electrical system.
From the Set Set-up menu, use and
buttons to select the System option. The screen will
show the currently selected power supply supply.
Press to enter the selection routine. The cur-
rent selection will ash
Use and buttons to select the required
system option: 1P21P2(W),3P33P3(W) ,3P43P4(W)
MP
E
MP
02 4047 0777 www.mercs.com.au02 4047 0788 9
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
Press to conrm the selection. SET indicator
will appear.
E
Press to exit the system selection routine and return to the menu. SET will disappear and you will be returned to the main Set Set-up Menu
U/I
ESC
From the Set Set-up menu, use and
buttons to select the CT option.
Secondary CT setting
Press to enter the CT secondary current
selection routine. routine.:5A/1A
Set CT Ratio value
Press to enter the CT Ratio setting screen. The
range is from 0001 to 9999.
MP
E
E
CT Settings
The CT option sets the secondary current (CT2 1A or 5A) of the current transformer (CT) that wires to the meter.
For example, if using a 100/5A current transformer you will enter 0020, as you need to divide the primary by the secondary to get the ratio
(CT rate).
* Please note for the MID approved version device,you will only have one opportunity to set the ratio.
02 4047 0777 www.mercs.com.au02 4047 0788 10
MerCs Strider M8 ME-PM-630MCT-2T
MerCs Pty Ltd, 55 Pendlebury Rd, Cardi, NSW, 2285, Australia | 2019 V1.1
From the Set Set-up menu, use and
buttons to select the PT option. The screen will show
the voltage PT secondary voltage value. The default
value is 400V.
Secondary PT setting
Press to enter the PT secondary voltage selec-
tion routine. The range is from 100 to 500V.
Set PT Ratio value
Press to enter the CT Ratio setting screen. The
range is from 0001 to 9999.
MP
PT Settings
The PT option sets the secondary voltage (PT2 100 to 500V) of the Voltage transformer (PT) that wires to the meter.
For example,
if set the ratio to be 100,it means the primary voltage equals secondary voltage x 100
E
E
From the Set up menu, use and buttons
to select the Pulse output option.
MP
Pulse output
This option allows you to congure the pulse output. The output can be set to provide a pulse for a dened amount of energy active or reactive.
Use this section to set up the pulse output - Units: Total kW h , Total kV A rh
