Multitech MultiConnect WF MTS2WFA Manuale utente

MultiConnect™WF

Serial-to-Wi-Fi®Device Server

MTS2WFA

MTS2WFA-R

Quick Start Guide

MultiConnect™WF

Serial-to-Wi-Fi®Device Server

MTS2WFA and MTS2WFA-R

Quick Start Guide

82100350L Rev. A

publication may not be reproduced, in whole or in part, without prior written

permission from Multi-Tech Systems, Inc. Multi-Tech Systems, Inc. makes no

representations or warranty with respect to the contents hereof and specifically

disclaims any implied warranties of merchantability or fitness for any particular

purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this

publication and to make changes from time to time in the content hereof without

obligation of Multi-Tech Systems, Inc. to notify any person or organization of such

revisions or changes.

Revision Date Description

A 11/19/07 Initial release.

Trademarks

Multi-Tech and the Multi-Tech logo are registered trademarks of Multi-

Tech Systems, Inc.

MultiConnect is a trademark of Multi-Tech Systems, Inc. Wi-Fi is a

registered trademark of the Wireless Ethernet Compatibility Alliance

(WECA).

All other brand and product names mentioned in this publication are

trademarks or registered trademarks of their respective companies.

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112 U.S.A.

(763) 785-3500 or (800) 328-9717

U.S. Fax (763) 785-9874

www.multitech.com

Technical Support

Country Email Phone

Europe, Middle East, Africa [email protected] +44 118 959 7774

U.S., Canada, all others suppor[email protected] 800-972-2439 or

763-717-5863

MultiConnect Serial-to-Wi-Fi Device Server

Introduction

This guide shows you how to set up your MultiConnect™WF Device

Server. For detailed information, product specifications, and more, see

the User Guide, available on the MultiConnect CD and the Multi-Tech

Web site.

General Safety

This product can be used in both fixed and mobile applications.

Caution: Maintain a separation distance of at least 20 cm (8 inches)

between the transmitter’s antenna and the body of the user or nearby

persons. This device is not designed for, nor intended to be, used in

applications within 20 cm (8 inches) of the body of the user.

Radio Frequency Interference

Avoid possible radio frequency (RF) interference by carefully following

the safety guidelines below.

•Switch OFF the MultiConnect™WF when in an aircraft. It may

endanger the operation of the aircraft.

•Switch OFF the MultiConnect™WF in the vicinity of gasoline or

diesel-fuel pumps or before filling a vehicle with fuel.

•Switch OFF the MultiConnect™WF in hospitals and any other place

where medical equipment may be in use.

•Respect restrictions on the use of radio equipment in fuel depots,

chemical plants, or in areas of blasting operations.

•There may be a hazard associated with the operation of your

MultiConnect™WF in the vicinity of inadequately protected

personal medical devices such as hearing aids and pacemakers.

Consult the manufacturers of the medical device to determine if it is

adequately protected.

•Operation of the MultiConnect™WF in the vicinity of other

electronic equipment may cause interference if the equipment is

inadequately protected. Observe any warning signs and

manufacturers’ recommendations.

Multi-Tech Systems, Inc. Quick Start Guide

Handling Precautions

All devices must be handled with certain precautions to avoid damage

due to the accumulation of static charge. Although input protection

circuitry has been incorporated into the devices to minimize the effect of

this static buildup, proper precautions should be taken to avoid exposure

to electrostatic discharge during handling and operation.

Shipping Package Contents

•One MultiConnect WF device server

•One 5 dbi reverse SMA antenna

•One mounting bracket

•One power supply (MTS2WFA only)

•A set of four self-adhesive rubber feet

•One printed Quick Start Guide

•One MultiConnect WF CD containing the User Guide, Quick Start

Guide, AT Commands Reference Guide, and Acrobat Reader.

MultiConnect Serial-to-Wi-Fi Device Server

Installation and Cabling

Attaching the MultiConnect WF to a Fixed Location

1. Typically, the MultiConnect WF is mounted against a flat

surface with two mounting screws. Drill the mounting holes at

the desired mounting location. The mounting holes must be

separated by 4-15/16 inches center-to-center.

2. To attach the mounting bracket, slide it into the

corresponding slot on the back of the MultiConnect

chassis.

3. Attach the MultiConnect to the surface with two screws.

Multi-Tech Systems, Inc. Quick Start Guide

Making the Connections for the MTS2WFA (Externally Powered)

Turn off your PC. Place the MultiConnect WF in a convenient

location. Connect it to your PC’s serial port and plug in the power.

Making the Connections for the MTS2BTA-R

Turn off your PC. Place the device server in a convenient location.

Then connect it to your PC’s serial port. The MTSWFA-R draws its

power from the RS-232 cable's Pin 6.

MultiConnect Serial-to-Wi-Fi Device Server

Optional – Direct DC Power Connection

•Connect a fused DC power

cable into the power

connector on the

MultiConnect WF.

•Then attach the two wires

at the other end of the

fused cable to a DC

fuse/terminal block on a

vehicle in which you are

mounting the MultiConnect

WF.

Connect the red wire to the

"+" positive and the black

wire to the "–" negative. Be

sure the GND connection is

correct.

Warning: Over-voltage

protection is provided on

the device. To ensure

complete protection, you

may want to add additional

filtering to the DC input.

Model Number for the Fused DC Power Cable:

FPC-532-DC

82100350L
