PowerWalker VFI 10000CRM LCD Manuale utente

Online UPS

PowerWalker VFI 10000CRM LCD

Manual

Uninterruptible Power Supply System

Please comply with all warnings and operating

instructions in this manual strictly. Save this

manual properly and read carefully the following

instructions before installing the unit. Do not

operate this unit before reading through all

safety information and operating instructions

carefully.

Table of Contents

1. SAFETY AND EMC INSTRUCTIONS ................................................................................................. 2

1-1. TRANSPORTATION AND STORAGE...............................................................................................................2

1-2. PREPARATION.......................................................................................................................................2

1-3. INSTALLATION ......................................................................................................................................2

1-4. CONNECTION WARNINGS ...............................................................................................................3

1-5. OPERATION .........................................................................................................................................4

1-6. STANDARDS .........................................................................................................................................4

2. INSTALLATION AND OPERATION .................................................................................................. 5

2-1. UNPACKING AND INSPECTION ...................................................................................................................5

2-2. REAR PANEL VIEW.................................................................................................................................5

2-3. SINGLE UPS INSTALLATION .....................................................................................................................6

2-4. SOFTWARE INSTALLATION .......................................................................................................................7

3. OPERATIONS.................................................................................................................................. 8

3-1. BUTTON OPERATION ..............................................................................................................................8

3-2. LED INDICATORS AND LCD PANEL ............................................................................................................8

3-3. AUDIBLE ALARM..................................................................................................................................10

3-4. SINGLE UPS OPERATION ......................................................................................................................11

3-5. ABBREVIATION MEANING IN LCD DISPLAY.................................................................................................13

3-6. LCD SETTING ....................................................................................................................................14

3-7. OPERATING MODE/STATUS DESCRIPTION .................................................................................................19

3-8. FAULT CODE ......................................................................................................................................21

3-9. WARNING INDICATOR ..........................................................................................................................21

4. TROUBLE SHOOTING ................................................................................................................... 22

5. STORAGE AND MAINTENANCE..................................................................................................... 23

5-1. STORAGE ..........................................................................................................................................23

5-2. MAINTENANCE....................................................................................................................................23

6. SPECIFICATIONS ......................................................................................................................... 24

1. Safety and EMC instructions

Please read carefully the following user manual and the safety instructions before installing the unit or using

the unit!

1-1. Transportation and Storage

Please transport the UPS system only in the original package to protect against shock and

impact.

The UPS must be stored in the room where it is ventilated and dry.

1-2. Preparation

Condensation may occur if the UPS system is moved directly from cold to warm environment.

The UPS system must be absolutely dry before being installed. Please allow at least two hours for the

UPS system to acclimate the environment.

Do not install the UPS system near water or in moist environments.

Do not install the UPS system where it would be exposed to direct sunlight or nearby heater.

Do not block ventilation holes in the UPS housing.

1-3. Installation

Do not connect appliances or devices which would overload the UPS (e.g. big motor-type

equipment)) to the UPS output sockets or terminal.

Place cables in such a way that no one can step on or trip over them.

Do not block air vents in the housing of UPS. The UPS must be installed in a location with good

ventilation. Ensure enough space on each side for ventilation.

UPS has provided earthed terminal, in the final installed system configuration, equipotential

earth bonding to the external UPS battery cabinets.

The UPS can be installed only by qualified maintenance personnel.

An appropriate disconnect device as short-circuit backup protection should be provided in the

building wiring installation.

An integral single emergency switching device which prevents further supply to the load by the

UPS in any mode of operation should be provided in the building wiring installation.

Connect the earth before connecting to the building wiring terminal.

Installation and Wiring must be performed in accordance with the local electrical laws and

regulations.

1-4. Connection Warnings

•There is no standard backfeed protection inside, please isolate the UPS before working according to this

circuit. The isolation device must be able to carry the UPS input current.

•This UPS should be connected with TN earthing system.

•The power supply for this unit must be single-phase rated in accordance with the equipment nameplate.

It also must be suitably grounded.

•Use of this equipment in life support applications where failure of this equipment can reasonably be

expected to cause the failure of the life support equipment or to significantly affect its safety or

effectiveness is not recommended. Do not use this equipment in the presence of a flammable anesthetic

mixture with air, oxygen or nitrous oxide.

•Connect your UPS power module’s grounding terminal to a grounding electrode conductor.

•The UPS is connected to a DC energy source (battery). The output terminals may be live when the UPS

is not connected to an AC supply.

Before working on this circuit

-Isolate Uninterruptible Power System (UPS)

-Then check for Hazardous Voltage between all

terminals including the protective earth.

Risk of Voltage Backfeed

1-5. Operation

Do not disconnect the earth conductor cable on the UPS or the building wiring terminals in any

time since this would cancel the protective earth of the UPS system and of all connected loads.

The UPS system features its own, internal current source (batteries). The UPS output sockets or

output terminal blocks may be electrically live even if the UPS system is not connected to the building

wiring outlet.

In order to fully disconnect the UPS system, first press the “OFF” button and then disconnect the

mains.

Ensure that no liquid or other foreign objects can enter into the UPS system.

The UPS can be operated by any individuals with no previous experience.

1-6. Standards

* Safety

IEC/EN 62040-1

* EMI

Conducted Emission...............................:IEC/EN 62040-2

Category C3

Radiated Emission..................................:IEC/EN 62040-2

Category C3

*EMS

ESD.........................................................:IEC/EN 61000-4-2

Level 4

RS........................................................ ...:IEC/EN 61000-4-3

Level 3

EFT......................................................... :IEC/EN 61000-4-4

Level 4

SURGE................................................... :IEC/EN 61000-4-5

Level 4

CS........................................................... :IEC/EN 61000-4-6

Level 3

Power-frequency Magnetic field.............. :IEC/EN 61000-4-8

Level 4

Low Frequency Signals............................:IEC/EN 61000-2-2

Warning: This is a product for commercial and industrial application in the

second environment-installation restrictions or additional measures may be

needed to prevent disturbances.

2. Installation and Operation

There are two different types of online UPS: standard and long-run models. Please refer to the following

model table.

Model

Type

Model

Type

PowerWalker VFI

10000CRM LCD

Standard

model

PowerWalker VFI

10000CRM LCDL

Long-run

model

2-1. Unpacking and Inspection

Unpack the package and check the package contents. The shipping package contains:

● One UPS

●One user manual

● One monitoring software CD

●One RS-232 cable (option)

●One USB cable

● One battery cable (option)

NOTE: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged

during transportation. Do not turn on the unit and notify the carrier and dealer immediately if there is any

damage or lacking of some parts. Please keep the original package in a safe place for future use.

2-2. Rear Panel View

Diagram 1: PowerWalker VFI 10000CRM LCD (L) Rear Panel

Diagram 2: Input/Output Terminal Diagram 3: Battery Pack Rear Panel

1. External battery connector

2. RS-232 communication port

3. Intelligent slot

4. USB communication

5. Emergency power off function connector (EPO connector)

6. Input circuit breaker

7. Input/Output terminal (Refer to Diagram 2 for the details)

8. Output terminal

9. Grounding terminal

10. Utility input terminal

11. Battery pack output circuit breaker

2-3. Single UPS Installation

Installation and wiring must be performed in accordance with the local electric laws/regulations and execute

the following instructions by professional personnel.

1) Make sure the mains wire and breakers in the building are in compliance with the standard of rated

capacity of UPS to avoid the hazards of electric shock or fire.

NOTE: Do not use the wall receptacle as the input power source for the UPS, as its rated current is less than

the UPS’s maximum input current. Otherwise the receptacle may be burned and destroyed.

2) Switch off the mains switch in the building before installation.

3) Turn off all the connected devices before connecting to the UPS.

4) Prepare wires based on the following table:

Model

Wiring spec (AWG)

Input

Output

Battery

Ground

PowerWalker VFI 10000CRM LCD

PowerWalker VFI 10000CRM LCDL

NOTE 1: It is recommended to use suitable wire in above table or thicker for safety and efficiency.

NOTE 2: The selections for color of wires should be followed by the local electrical laws and

regulations.

5) Remove the terminal block cover on the rear panel of UPS. Then connect the wires according to the

following terminal block diagrams: (Connect the earth wire first when making wire connection. Disconnect

the earth wire last when making wire disconnection!)

Terminal Block wiring diagram

NOTE 1: Make sure that the wires are connected tightly with the terminals.

NOTE 2: Please install the output breaker between the output terminal and the load, and the breaker

should be qualified with leakage current protective function if necessary.

Input Neutral

Input Line

Ground

Output Line

Output Neutral

6) Put the terminal block cover back to the rear panel of the UPS.

Warning: (Only for standard model)

● Make sure the UPS is not turned on before installation. The UPS should not be turned on during wiring

connection.

● Do not try to modify the standard model to the long-run model. Particularly, do not try to connect the

standard internal battery to the external battery. The battery type and voltage and numbers may be

different. If you connect them together, it maybe causes the hazard of electric shock or fire!

Warning: (Only for long-run model)

● Make sure a DC breaker or other protection device between UPS and external battery pack is installed. If

not, please install it carefully. Switch off the battery breaker before installation.

Warning:

● For standard battery pack, there are one DC breaker to disconnect the battery pack and the UPS. But for

other external battery pack, make sure a DC breaker or other protection device between UPS and

external battery pack is installed. If not, please install it carefully. Switch off the battery breaker before

installation.

NOTE: Set the battery pack breaker in “OFF” position and then install the battery pack.

● Pay highly attention to the polarity marking on external battery terminal block, and make sure the

correct battery polarity is connected. Wrong connection may cause permanent damage of the UPS.

● Make sure the protective earth ground wiring is correct. The current spec, color, position, connection and

conductance reliability of wire should be checked carefully.

● Make sure the utility input & output wiring is correct. The current spec, color, position, connection and

conductance reliability of wire should be checked carefully. Make sure the L/N terminal is correct, not

reverse or short-circuited.

2-4. Software Installation

For optimal computer system protection, install UPS monitoring software to fully configure UPS shutdown.

Indice

Altri manuali PowerWalker UPS

PowerWalker

PowerWalker VFI 6000T LCD L Manuale utente

PowerWalker

PowerWalker VI 650 GX Manuale utente

PowerWalker

PowerWalker VFI 1000R LCD Manuale utente

PowerWalker

PowerWalker VFI 3000 LCD Guida all'installazione

PowerWalker

PowerWalker VI 650 GX Manuale utente

PowerWalker

PowerWalker VI 500T/HID Manuale utente

PowerWalker

PowerWalker VFI 10000CP 3/3 Manuale utente

PowerWalker

PowerWalker VFI 1000RM LCD Manuale utente

PowerWalker

PowerWalker VI 500 R1U Manuale utente

PowerWalker

PowerWalker VFI 6000CRM LCD Manuale utente

PowerWalker

PowerWalker VFI 10K CPH Manuale utente

PowerWalker

PowerWalker VI 1200 RLE Manuale utente

PowerWalker

PowerWalker VFI 1000 AT Manuale utente

PowerWalker

PowerWalker VFI 1000 RMG PF1 Manuale utente

PowerWalker

PowerWalker PF 1 6K Manuale utente

PowerWalker

PowerWalker VFI 1000RT LCD Manuale utente

PowerWalker

PowerWalker VI TW Series Manuale utente

PowerWalker

PowerWalker 1000 LCD/UK Manuale utente

PowerWalker

PowerWalker VFI 6000RT LCD Manuale utente

PowerWalker

PowerWalker VFI 1000 C LCD Manuale utente

PowerWalker

PowerWalker VFI 1000 CRM Manuale utente

PowerWalker

PowerWalker VFI 1000CRM LCD Manuale utente

PowerWalker

PowerWalker VFI 10000P/RT LCD Manuale utente

PowerWalker

PowerWalker VFI CG PF1 Series Manuale utente

Manuali UPS popolari di altre marche

Pylontech

Pylontech Victron & Pylontech US5000 Manuale utente

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Manuale utente

Mecer

Mecer ME-1000-WTU Manuale utente

Mustek

Mustek PowerMust 530(B) Plus Manuale di installazione e funzionamento

Emerson

Emerson Liebert NXL series Manuale utente

MAKELSAN

MAKELSAN BOXER SERIES Manuale utente

Block

Block PC-0524-400-0 Manuale utente

CyberPower

CyberPower CP585LCD Manuale utente

Eaton

Eaton 3S Istruzioni per il montaggio

CyberPower

CyberPower Office Tower Series UPS 1000 Manuale utente

CyberPower

CyberPower BM100 Manuale utente

Best Power

Best Power 610 Manuale utente

Best Power

Best Power Unity/I UT3K Manuale utente

Mustek

Mustek PowerMust 400 Offline Manuale utente

Xantrex

Xantrex Trace 512 UR-UPS Manuale utente

Forza

Forza SL-1501UL Manuale utente

LEGRAND

LEGRAND keor 310081 Manuale utente

ABB

ABB Conceptpower DPA 500 Manuale utente
