Rowlett DE401 Manuale utente

Model:

DE401

Milk frother

Instruction manual

DE401_UK_A5_v1_20210512.indb 1DE401_UK_A5_v1_20210512.indb 1 2021/5/12 16:212021/5/12 16:21

UK Telephone Helpline: 0845 146 2887

Safety Tips

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out

installation and any repairs if required. Do not remove any

components on this product.

• Consult Local and National Standards to comply with the

following:

- Health and Safety at Work Legislation

- BS EN Codes of Practice

- Fire Precautions

- IEE Wiring Regulations

- Building Regulations

• Ensure the milk level is between the ‘MIN’ and ‘MAX’ marks.

• Keep hands and utensils away while use to reduce the risk of

severe personal injury or damage to the appliance.

• Always ensure to use the appliance with cover in place.

• Only use the power base supplied with the appliance.

• Never use accessories which are not recommended by the

manufacturer. They could pose a safety risk to the user and

might damage the appliance. Only use original parts and

accessories.

• NEVER operate an empty appliance to avoid any damage to

the heating elements.

• Be cautious when moving the appliance with hot liquid inside.

• Always switch off and disconnect the power supply to the

appliance when not in use.

• Keep all packaging away from children. Dispose of the

packaging in accordance to the regulations of local authorities.

• If the power cord is damaged, it must be replaced by a

Rowlett agent or a recommended qualified technician in order

to avoid a hazard.

DE401_UK_A5_v1_20210512.indb 2DE401_UK_A5_v1_20210512.indb 2 2021/5/12 16:212021/5/12 16:21

Telephone Helpline: 0845 146 2887

• This appliance can be used by persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and if they

understand the hazards involved.

• This appliance can be used by children aged from 8 years

and above if they have been given supervision or instruction

concerning use of the appliance in a safe way and if they

understand the hazards involved.

• Cleaning and user maintenance shall not be made by children

unless they are aged from 8 years and above and supervised.

• Keep the appliance and its cord out of reach of children aged

less than 8 years.

• Children shall not play with the appliance.

• DO NOT immerse the appliance in water.

• This appliance is intended to be used in household and similar

applications such as:

- staff kitchen areas in shops, offices and other working

environments;

- farm houses;

- by clients in hotels, motels and other residential type

environments;

- bed and breakfast type environments.

• Do not touch the hot surface. Hold the appliance by its handle

only.

• Rowlett recommend that this appliance should be periodically

tested (at least annually) by a Competent Person. Testing

should include, but not be limited to: Visual Inspection,

Polarity Test, Earth Continuity, Insulation Continuity and

Functional Testing.

DE401_UK_A5_v1_20210512.indb 3DE401_UK_A5_v1_20210512.indb 3 2021/5/12 16:212021/5/12 16:21

UK Telephone Helpline: 0845 146 2887

• Rowlett recommend that

this product is connected

to a circuit protected by an

appropriate RCD (Residual

Current Device).

Introduction

Please take a few moments to carefully read

through this manual. Correct maintenance and

operation of this machine will provide the best

possible performance from your Rowlett product.

The appliance is only intended for frothing and

heating milk. Do not use it for anything other than

intended use.

Pack Contents

The following is included:

• Milk frother

• Power base

• Instruction manual

Rowlett prides itself on quality and service,

ensuring that at the time of packaging the contents

are supplied fully functional and free of damage.

Should you find any damage as a result of transit,

please contact your Rowlett dealer immediately.

Before first time use

1. Clean the appliance thoroughly (See section

“Cleaning, Care & Maintenance”).

2. Get to know the paddles:

Mixing

paddle

For mixing milk during

heating

Frothing

paddle For frothing milk

3. Get to know the milk level marks:

Maximum capacity for heating milk: 300ml

Minimum capacity for heating or

frothing milk: 75ml

Maximum capacity for frothing milk: 150ml

Operation

Note for all functions:

Ensure to let the appliance rest for a

Minimum of 3 minutes between two

consecutive cycles, or the appliance will

enter self-protection state automatically

after working for 5 cycles continuously. The

working indicator will flash and the motor

will not run. After about 5 minutes, the

appliance will enter standby and be ready

for use again.

Frothing and heating function

1. Remove the jar from the base.

2. Open the cover. Then mount the frothing

paddle onto the shaft inside the jar.

3. Fill the jar with milk below the “MAX” mark

(150ml). Then close the cover.

4. Place the jar on the base then connect jar to a

mains power supply.

5. Press the heating button once. The

heating indicator light turns On and the

appliance starts to work.

• Note: If desired, you can press the heating

button again to halt operation.

6. Once completed, the appliance stops working

automatically.

DE401_UK_A5_v1_20210512.indb 4DE401_UK_A5_v1_20210512.indb 4 2021/5/12 16:212021/5/12 16:21

Telephone Helpline: 0845 146 2887

Frothing only function

1. Repeat the steps 1-4 as in section “frothing and heating function”.

2. Press the frothing button . The frothing indicator light turns On and the appliance starts to work.

• Note: If desired, you can press the frothing button again to halt operation.

3. Once completed, the appliance stops working automatically.

Heating only function

1. Ensure to mount the mixing paddle onto the shaft.

2. Ensure the milk level is below the “MAX” mark (300ml).

3. After plugging in the base, press the heating button once. The heating indicator light turns On

and the appliance starts to work.

• Note: If desired, you can press the heating button again to halt operation.

4. Once completed, the appliance stops working automatically.

Cleaning, Care & Maintenance

Always disconnect the appliance from the power supply and let it cool down

before cleaning and any maintenance.

• Use soapy water and a damp cloth to clean the exterior of the appliance.

• The jar and cover are NOT dishwasher proof! Use some mild detergent and a damp cloth to

clean.

• Soak the 2 paddles in warm water, then clean with a soft cloth or brush.

• Dry thoroughly after cleaning.

Troubleshooting

Fault Probable Cause Solution

The unit is not working The unit is not switched on Check the unit is plugged in correctly and

switched on

Plug or lead is damaged Call Rowlett agent or qualified technician

Fuse in the plug has blown Replace the plug fuse

Power supply Check power supply

Technical Specifications

Model Voltage Power Current Weight Dimensions

H x W x D mm

DE401 220-240V~, 50-60Hz 450-550W 3A 0.85kg 195 x 160 x 110

DE401_UK_A5_v1_20210512.indb 5DE401_UK_A5_v1_20210512.indb 5 2021/5/12 16:212021/5/12 16:21

UK Telephone Helpline: 0845 146 2887

Electrical Wiring

This appliance is supplied with a 3 pin BS1363 plug and lead.

The plug is to be connected to a suitable mains socket.

This appliance is wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Compliance

The WEEE logo on this product or its documentation indicates that the product must

not be disposed of as household waste. To help prevent possible harm to human

health and/or the environment, the product must be disposed of in an approved and

environmentally safe recycling process. For further information on how to dispose of

this product correctly, contact the product supplier, or the local authority responsible for

waste disposal in your area.

Rowlett parts have undergone strict product testing in order to comply

with regulatory standards and specifications set by international,

independent, and federal authorities.

Rowlett products have been approved to carry the following symbol:

mechanical, photocopying, recording or otherwise, without the prior written permission of Rowlett.

Every effort is made to ensure all details are correct at the time of going to press, however, Rowlett reserves the right to

change specifications without notice.

DE401_UK_A5_v1_20210512.indb 6DE401_UK_A5_v1_20210512.indb 6 2021/5/12 16:212021/5/12 16:21

DECLARATION OF CONFORMITY

• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •

• Declaración de conformidad • Declaração de conformidade

Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp

• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento

Model • Modèle • Modell • Modello

• Modelo • Malli

Milk Frother

DE401 (& -E)

Application of Territory Legislation &

Council Directives(s)

Toepassing van Europese Richtlijn(en)

• Application de la/des directive(s) du

Conseil • Anwendbare EU-Richtlinie(n)

• Applicazione delle Direttive

• Aplicación de la(s) directiva(s) del

consejo • Aplicação de directiva(s) do

Conselho

Low Voltage Directive (LVD) - 2014/35/EU

Electrical Equipment (Safety) Regulations 2016

EN 60335-1:2012 +A11:2014

EN 60335-2-15:2016

EN 62233:2008

Electro-Magnetic Compatibility (EMC) Directive 2014/30/EU - recast of 2004/108/EC

Electromagnetic Compatibility Regulations 2016 (S.I. 2016/1091)

EN55014-1:2017

EN55014-2:2015

EN IEC 61000-3-2: 2019

EN 61000-3-3: 2013 +A1:2019

Restriction of Hazardous Substances Directive (RoHS) 2015/863 amending Annex II to

Directive 2011/65/EU

Restriction of the Use of Certain Hazardous Substances in Electrical and Electronic

Equipment Regulations 2012 (S.I. 2012/3032)

Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers

• Nome del produttore • Nombre del fabricante • Nome do fabricante

Rowlett

I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)

and Standard(s).

Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande

Richtlijn(en) en Standaard(en).

Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus

Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und

Norm(en) entspricht.

Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.

El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y

estándar(es) arriba mencionadas.

Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)

Directiva(s) e Norma(s)

Date • Data • Date • Datum • Data •

Fecha • Data

12th April 2021

Signature • Handtekening • Signature

• Unterschrift Firma • Firma •

Assinatura

Full Name • Volledige naam • Nom et

prénom • Vollständiger Name • Nome

completo • Nombre completo • Nome

por extenso

Ashley Hooper

Eoghan Donnellan

Position • Functie • Fonction • Position

• Qualifica • Posición • Função

Technical & Quality Manager

Commercial Manager/ Importer

Producer Address • Adres fabrikant •

Adresse du producteur • Anschrift des

Herstellers • Indirizzo del produttore •

Dirección del fabricante • Morada do

fabricante

Fourth Way,

Avonmouth,

Bristol,

BS11 8TB

United Kingdom

42 North Point Business Park

New Mallow Road

Cork

Ireland

DocuSign Envelope ID: DEA43870-741B-4107-B0DF-056D21667E6B

DE401_UK_A5_v1_20210512.indb 7DE401_UK_A5_v1_20210512.indb 7 2021/5/12 16:212021/5/12 16:21

DE401_UK_A5_v1_20210512

DE401_UK_A5_v1_20210512.indb 8DE401_UK_A5_v1_20210512.indb 8 2021/5/12 16:212021/5/12 16:21

Altri manuali per DE401

Indice

Altri manuali Rowlett Elettrodomestico da cucina

Rowlett

Rowlett DE401 Manuale utente

Manuali Elettrodomestico da cucina popolari di altre marche

Tayama

Tayama TYG-35AF Manuale utente

AEG

AEG 43172V-MN Manuale utente

REBER

REBER Professional 40 Guida utente

North American

North American BB12482G / TR-F-04-B-NCT-1 Manuale utente

Presto

Presto fountain popper Manuale utente

Westmark

Westmark 1035 2260 Manuale utente

Zanussi

Zanussi ZCG64396XA Manuale utente

HOFFEN

HOFFEN SM-9302M Manuale utente

Philips

Philips HD3133 Manuale utente

Ronco

Ronco Beef Jerky Manuale utente

Hendi

Hendi 470411 Manuale utente

Livoo

Livoo MEN386 Manuale utente

Vogue

Vogue D446 Manuale utente

croydon

croydon WR-10313-700 Manuale utente

ADE

ADE AUTOMATIC-L Manuale utente

Chefman

Chefman RJ43-SQ Series Manuale utente

Vacmaster

Vacmaster VP680 Manuale utente

Jetmaster

Jetmaster 900HG Manuale utente
