85DRV5 / 85DRV5-L
Contents
Chapter 1 Specification ............................................. 9
1-1 85DRV5 / 85DRV5-L Components and Options .............. 1
1-2 Mainboard Specifications ..................................................... 11
1-2.1 CPU Socket ................................................................................... 11
1-2.2 System Chipsets ........................................................................... 11
1-2.3 Memory ......................................................................................... 11
1-2.4 AMI BIOS ..................................................................................... 11
1-2.5 Accelerated Graphics Port (AGP) Interface........................... 11
1-2.6 Advanced System Power Management:................................... 12
1-2.7 Multi-I/O Functions :.................................................................. 12
1-2.8 Expansion Slots ............................................................................ 12
1-2.9 AC’97 Audio Codec on board .................................................... 13
1-2.1 LAN on board (85DRV5-L only)............................................. 13
1-2.11 Hardware Monitor on board ................................................... 13
1-2.12 6-channel Sound Output Support (optional) ........................ 13
1-2.13 Form Factor................................................................................ 13
1-3 Mainboard Specification Table ........................................... 14
1-4 Chipset System Block Diagram........................................... 15
Chapter 2 Hardware Setup..................................... 16
2-1 Pentium 4 CPU and Installation ......................................... 17
2-1.1 To Identify a Pentium 4 CPU..................................................... 17
2-1.2 CPU Installation with Socket 478B .......................................... 18
2-2 Pentium 4 CPU Fan Installation ......................................... 19
2-3 Memory Installation with Warning LED .......................... 2
2-3.1 To Install DDR SDRAM Module .............................................. 2
2-3.2 To Remove a DIMM .................................................................... 21
5
Contents
2-4 AGP 4X/2X Card Installation.............................................. 22
2-5 IDE Connector Installation ................................................. 23
2-6 Flopy Drive Connector ( FDC ) Installation ..................... 24
2-7 ATX V 2. 3 Power Supply Installation .............................. 25
2-8 Jumper and Switch Settings ................................................ 26
2-8.1 JBAT1: Clear CMOS .................................................................. 27
2-8.2 Jp1 and SW1: CPU Clock/Overclock Select........................... 28
2-8.3 Jp2: Flash ROM Write Protection ........................................... 29
2-9 Other Connectors Configuration........................................ 3
2-9.1 On-board FAN Connectors ........................................................ 3
2-9.2 Connector WOL1: Wake On LAN............................................ 31
2-9.3 CD-ROM Audio Connector (CD1) ........................................... 31
2-9.4 PS/2 Mouse And PS/2 Keyboard ............................................... 32
2-9.5 Chassis Panel Connectors ......................................................... 32
2-9.6 RJ45: LAN Connector (85DRV5-L only) ................................ 33
2-9.7 Thermal Sensor Connectors RT1 and RT2 ............................. 34
2-9.8 Complex Pin-header.................................................................... 35
2-9.9 USB Ports and USB Pi-headers................................................. 37
2-9.1 Audio 1: 6-channel Sound Output Connector (optional) ...38
2-9.11 SCR1: Smart Card Reader Connector .................................. 38
2-1 IRQ Description................................................................... 39
Chapter 3 Software Setup ....................................... 4
3-1 Open Up Suport CD .............................................................. 41
3-2 Proceed to VIA 4-IN-1 Drivers Installation ...................... 42
3-3 AC’97 Audio Driver Installation......................................... 44
3-4 Install USB 2. Driver for Win98 / Me / 2 / XP.......... 45
3-5 Install Hardware Monitor Utility ....................................... 47
3-5.1 Installation ................................................................................... 47
3-5.2 Verification .................................................................................. 48
6
85DRV5 / 85DRV5-L
3-6 Install VIA LAN Drivers (for 85DRV5-L only) ................ 49
3-6-1. VIA6183 LAN driver on Windows 9X.................................... 49
3-6-2. VIA6183 LAN driver on Windows NT4. .............................. 51
3-6-3. VIA6183 LAN driver on Win ME / 2 / XP ....................... 52
Chapter 4 AMI BIOS Setup.................................... 54
4-1 About BIOS Setup ................................................................. 55
4-2 To Run BIOS Setup ............................................................... 55
4-3 About CMOS .......................................................................... 55
4-4 The POST ( Power On Self Test ) ....................................... 55
4-5 To Update BIOS ..................................................................... 56
4-6 BIOS SETUP --- CMOS Setup Utility................................ 58
4-6.1 CMOS Setup Utility .................................................................... 58
4-6.2 Standard CMOS Setup ............................................................... 59
4-6.3 Advanced BIOS Features ........................................................... 62
4-6.4 Advanced Chipset Features ....................................................... 65
4-6.5 Power Management Features .................................................... 68
4-6.6 PNP / PCI Configurations .......................................................... 71
4-6.7 Integrated Peripherals................................................................ 73
4-6.8 Hardware Monitor Status .......................................................... 76
4-6.9 Frequency/Voltage Control ....................................................... 78
4-6.1 Set Supervisor Password .......................................................... 8
4-6.11 Load Optimized Defaults ........................................................ 82
4-6.12 Save & Exit Setup...................................................................... 82
4-6.13 Exit Without Saving .................................................................. 82
APPENDICES.......................................................... 84
Appendix-1 Identify Mainboard Model Number ................... 85
Appendix-2 Technical Terms ...................................................... 86
8
85DRV5 / 85DRV5-L
Mainboard
Support CD
Bundled Bonus Pack CD
Bundled Bonus Pack Manual
Temperature Sensor Cable (Optional)
ATA66/100/133 IDE Cable
FDD Cable
User’s Manual
RS232 Cable
USB Cable (Optional)
ITEM CHECKUP
9
Chapter 1 Specification
Topics incl ded in this chapter are:
1-1 Mainboard Components Locations
1-2 Mainboard Specifications
1-3 Mainboard Specification Table
1-4 Chipset Diagram
Introd ction
Chapter 1 Specification
This series of mainboards features an integration of the powerful
processor Intel Pentium 4 and the single-chip North Bridge VIA Apollo
P4X266E plus South Bridge VT8235, by which the whole system per-
formance can be upgraded to 533 MHz system bus.
The Intel P4 processor is a rapid execution engine providing 4X100/
4X133MHz quadpumped system bus to allow 3.2GB data transfer rates
possible, while VIA Apollo P4X266E plus VT8235 supports Intel P4 pro-
cessor to implement the 4X133 Front Side Bus, AGP 4X external bus,
the LPC Super I/O, the DDR266 SDRAM and UATA 133/100/66 data
transfer rate. This chapter is to introduce to users every advanced
function of this high performance integration.
1
85DRV5 / 85DRV5-L
DIMM 3
DIMM 1
DIMM 2
PCI 1
PCI 2
PCI 3
PCI 4
PCI 5
PCI 6
FLASH BIOS
Li
Battery
Peripheral Power
Conne tor
+12 Power
Conne tor
41
Main Power
Conne tor
SW1
ON DIP
1 2 3 4
VIA
P4x266E
VIA
VT8235
1
mPGA478B
IDE2
IDE1
FDC1
1 3
FAN2
FAN1
1
FAN3
1
1
FAN4
IT8705F
LPC I/O
LPT1
COM1
MIC
GAME/MIDI PORT
LINE
OUT
LINE
IN
PS/2 K/B¤
(underside)
PS/2 Mouse
(on top)
USB1 (underside)
USB0 (middle)
RJ 45
(on top)
AC'97
Code
JUSB2
1
10
JUSB1
1
10 SCR1
1
14
AUDIO1
1
14
AGP 4X/2X
WOL1
1
RT1
RT2
1
JP1
1
JBAT1
1
JP2
SAPK RST PLED SLED
HDD/LED IR PWR SMI
++
--
+-
1
30
VIA VT6103
PHY (LAN Controller)
CD1
1
3
2
COM2
Audio Code
DDR 266/200
1-1 85DRV5 / 85DRV5-L Components and Options
RJ45
PHY LAN Controller for 85DRV5-L only
}
Optional 6-channel A dio-O t Connector
11
Chapter 1 Specification
1-2.1 CPU Socket
CPU Socket 478B on board, supporting Intel® Pentium 4 processors in
478-pin package for :
-- 533/400MHz System Bus;
-- Hyper-pipelined technology;
-- Advanced dynamic execution;
-- Advanced transfer cache;
1-2.2 System Chipsets
• North Bridge VIA P4X266E for managing and supporting 4X133/
4X100MHz system Bus, DDR 266/200 SDRAM memory interface,
Hub interface and AGP4X/2X interface.
• South Bridge VIA VT8235 working with North Bridge supporting the
4X V-Link, LPC Super I/O, upstream Hub interface, PCI interface,
IDE interface, LAN interface, USB V2.0 interface as well as the AC’97
6-channel Audio interface
1-2.3 Memory
3 DDR DIMM 184-pin slots on board for DDR 266/200 SDRAMs :
• Supporting unregistered, non-ECC DDR 266/200 SDRAM up to 3
GBs; DIMM voltage adjustable in BIOS Setup
• Supporting installation of mixed volumes yet same type of DDR
SDRAM modules
1-2.4 AMI BIOS
• Supporting Plug & Play V1.0
• Flash Memory for easy upgrade
• Supporting BIOS Writing Protection and Year 2000 compliant
• Supporting BIOS Setup (See Chapter 4 BIOS Setup)
1-2 Mainboard Specifications
1-2.5 Accelerated Graphics Port (AGP) Interface
AGP Controller embedded on board, supporting:
• 1.5V (4X) and 3.3V (2X) power modes in 1 AGP Slot supported
• 4x AD and SBA signaling, AGP pipelined split-transaction longburst
transfers up to 1GB/sec.
• AGP Voltage adjustable in BIOS Setup
12
85DRV5 / 85DRV5-L
1-2.7 M lti-I/O F nctions :
• PCI EIDE Controller, supporting:
-- 2x Ultra ATA133/100 / 66 IDE connectors supporting up to 4 IDE
devices
• Dedicated IR Functions:
-- 1x5 Pin-header dedicated to IR function either through the two
complete serial ports or the third dedicated port Infrared-IrDA (HPSIR)
and ASK (Amplitude Shift Keyed) IR
• Multi-mode parallel data transfer:
-- Standard mode, high speed mode ECP and enhanced mode EPP
• Floppy Disk connector:
-- One FDD connector supporting 2 floppy drives with drive swap support
• Universal Serial Bus Transfer Mode:
-- USB V2.0 compliant, 480 Mb/s USB Bus, supporting Win98 and up oper-
ating system; USB drivers provided in Support CD for user’s installation
-- 2 built-in USB connectors and 2 USB pin-headers which require 2 op-
tional USB cables to provide 4 more optional USB ports
• PS/2 Keyboard and PS/2 Mouse
• UARTs (Universal Asynchronous Receiver / Transmitter):
-- Two complete serial ports (COM1 & COM2) on board
1-2.8 Expansion Slots
• 6 PCI bus Master slots
• 1 AGP 4X/2X slot
• 3 DDR DIMM slots
1-2.6 Advanced System Power Management:
• ACPI 1.0 compliant (Advanced Configuration and Power Interface)
• APM V1.2 compliant (Legacy Power Management)
• ACPI POS (Power On Suspend)
• PS/2 Keyboard & Mouse Power On
• Supporting Ring Power Up Control for Wake-on-LAN (via Connector
WOL1 to add-on PCI LAN card)
• Real Time Clock (RTC) with date alarm, month alarm, and century
field
13
Chapter 1 Specification
1-2.9 AC’97 A dio Codec on board
AC’97 Audio Codec 2.2 compliant on board
1-2.10 LAN on board (85DRV5-L only)
Fast Ethernet Controller integrated in VT8235 and PHY VIA VT6103:
• Supporting 10/100Mb Fast Ethernet Base-T LAN
• LAN Driver enclosed in Support CD for user’s installation.
• Supporting up to 6 channels of PCM audio output
• 6 channel audio consists of Front Left, Front Right, Back Left, Back
Right, Center and Woofer for complete surrround sound effect
• AC’97 Audio Codec Driver enclosed in Support CD for user’s
installation.
1-2.11 Hardware Monitor on board
• Hardware Monitor integrated in Super I/O IT8705F, providing moni-
toring and alarm for flexible desktop management of hardware voltage,
temperatures and fan speeds.
• Utility Software SmartGuardian for displaying Monitoring status is
enclosed in Support CD for user’s installation.
1-2.13 Form Factor
• ATX form factor, ATX power supply, version 2.03 compliant, supported
by one Main Power Connector, one +12V Power Connector and one
Peripheral Power Connector
• Mainboard size: 305mm x 220mm
1-2.12 6-channel So nd O tp t S pport (optional)
• This series is designed with an optional 6-channel Audio-out connec-
tor Audio1”. If this option is chosen, an Audio-out card will be en-
closed in package to provide 3 additional audio-out ports for the 6-
channel sound.
14
85DRV5 / 85DRV5-L
1-3 Mainboard Specification Table
CPU
North Bridge
South Bridge
BIOS
Memory
I/O Chip
AGP interface
Audio
IDE Interface
Networking
PCI Slots
I/O Connectors
VGA Display
Other Features
Optional Feature
LAN On Board
Socket 478B for Intel Pentium 4 CPUs
VIA P4X266E, supporting 533/400MHz FSB
VIA VT8235
AMI BIOS
Supporting DDR 266/200 SDRM, up to 3GB
in 3 DDR DIMM slots
IT8705F
AGP4X/2X mode
AC’97 Audio V2.2 compliant, 6-channel interface
2 UATA 66/100/133 IDE ports
VIA LAN Controller, 1xRJ45 (85DRV5-L only)
6 PCI Master slots on board
6xUSB ports (V2.0), 1xFDD port, 2xCOM ports,
1xLPT, 1xIrDA, 1xPS/2 K/B, 1xPS/2 Mouse,
VGA not integrated on board
BIOS Writing Protection;
Hardware Monitoring in IT8705F
Keyboard Power On;
ATX 2.03 Power Supply;
ATX form factor
85DRV5 85DRV5-L
No Yes
SL-85DRV5 / 85DRV5-L Specifications and Feat res
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali SOLTEK Scheda madre
SOLTEK
SOLTEK SL-61A Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-65EP Manuale utente
SOLTEK
SOLTEK SL-65LIV Manuale utente
SOLTEK
SOLTEK SL-53A2 Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-85DR-C Manuale utente
SOLTEK
SOLTEK 75FRN2 Series Manuale utente
SOLTEK
SOLTEK SL-65FVB Manuale utente
SOLTEK
SOLTEK SL-85DIR3 Manuale utente
SOLTEK
SOLTEK 85DR2-DC Manuale utente
SOLTEK
SOLTEK 85DIR Manuale utente
SOLTEK
SOLTEK SL-65DRV Manuale utente
SOLTEK
SOLTEK SL-54A2-S Manuale utente
SOLTEK
SOLTEK SL-67EV1 Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-63AV Manuale per l'uso e la cura
SOLTEK
SOLTEK SL-B8D-F Manuale utente
SOLTEK
SOLTEK SL-65GS Manuale utente
SOLTEK
SOLTEK SL-PT880E-R Manuale utente
SOLTEK
SOLTEK SL-65EP+-T Manuale utente
SOLTEK
SOLTEK SL-65MIE Manuale utente
SOLTEK
SOLTEK SL-65DVB Manuale utente
Manuali Scheda madre popolari di altre marche
Telit Wireless Solutions
Telit Wireless Solutions SL869-3DR Manuale utente
Gigabyte
Gigabyte GA-9IVDT Manuale utente
Texas Instruments
Texas Instruments ADS8372EVM Manuale utente
Commell
Commell MS-C73 Manuale utente
IBT Technologies
IBT Technologies MB860 Manuale utente
Nvidia
Nvidia TEGRA DG-04927-001_V01 Manuale utente
