Soundcore Motion X600 Manuale utente

USER MANUAL

soundcore Motion X600

English 01

Čeština 11

Dansk 21

Deutsch 31

Español 41

Suomi 51

Français 61

Italiano 71

Nederlands 81

Norsk 91

Język polski 101

Portugues do Brasil 111

Pусский 121

Svenska 131

Türk 141

日本語 151

한국어 161

简体中文 171

繁體中文 181

ةيِبَرَعل 191

תי ִ

רבִע201

01 EN

At a Glance

1. Power

2. Bluetooth

3. Spatial Sound

4. BassUp

5. Volume Down

6. Play / Pause

7. Volume Up

8. USB-C Charging Input

9. AUX IN

02 EN

Charging

Use a certified USB-C cable and charger to prevent any damage.

Fully charge this speaker before the first use to prolong the lifespan of the built-in

battery.

Flashing red Low battery

Steady red Charging

Steady white Fully charged

03 EN

Powering On / Off

Press once Power on

Steady white

Press and hold for at least 2 seconds Power off

Light off

This speaker will power off automatically after 20 minutes if no device is connected.

04 EN

Using Your Speaker

Bluetooth Mode

With this speaker, you can enjoy music through your Bluetooth-enabled devices.

Press once Enter Bluetooth pairing mode

Flashing blue Bluetooth pairing

Steady blue Bluetooth connected

• To re-enter Bluetooth pairing mode, press the Bluetooth button once.

• This speaker can only play music on one mobile device at a time. To play from

another connected device, pause the device that's currently active first.

• Each time you power on your speaker, it will automatically connect to your

last connected device if available within the Bluetooth range. If not, press the

Bluetooth button to enter Bluetooth pairing mode.

05 EN

TWS (True Wireless Stereo) Mode

Two identical Motion X600 speakers can pair with each other for stereo sound.

Both speakers can play the same audio (one as the left channel and the other as

the right channel).

1. Connect either speaker with your Bluetooth device.

2. On both speakers, press and hold the Bluetooth button for at least 2 seconds

to enter TWS pairing mode.

Press and hold for at least 2 seconds Enter TWS pairing mode

Flashing white TWS pairing

Steady blue (Speaker 1) TWS connected

Steady white (Speaker 2)

To exit TWS mode, press and hold the Bluetooth button for at least 2 seconds.

06 EN

Spatial Sound

Spatial sound places sound all around you to create an immersive listening

experience.

x1 OFF

Press once Turn spatial sound on / off

Steady white Spatial sound on

Light off Spatial sound off

LDAC

Use devices powered by Android 8.0 or later to experience LDAC quality sound.

1. Open the soundcore app.

2. Go to the Settings icon on the home page.

3. Click on "Sound Mode."

4. Select "Preferred audio quality" to switch to LDAC codec.

07 EN

• It takes about 10 seconds to switch audio codecs. You may be requested to

update the speaker's firmware if available.

• LDAC provides higher quality sound, increases power consumption, and

reduces playtime.

• Enable LDAC in a low-interference environment to ensure a stable Bluetooth

connection.

AUX Mode

Insert a 3.5mm AUX cable (not included) to play audio on an external device.

When using AUX mode, control audio playback via the connected device.

08 EN

Button Controls

Press once Power on

Press and hold for at least 2

seconds Power off

Press once Enter Bluetooth pairing mode

Press and hold for at least 2

seconds Enter / exit TWS pairing mode

Press once Turn spatial sound on / off

Press once Turn BassUp on / off

Press Volume up / down

Press once Play / pause

Press twice Next track

Press three times Previous track

Press once Answer / end a call

Press and hold for at least 2

seconds Reject a call

Press and hold for at least 2

seconds Activate voice assistant software

Reset

Press and hold the Bluetooth button and volume up button simultaneously for at

least 4 seconds to reset the speaker.
