Star Micronics SP700 Series Manuale utente

AAnn eeaassyy--ttoo--iinntteeggrraattee,, iinnnnoovvaattiivvee kkiittcchheenn pprriinntteerr tthhaatt

ccaann ttaakkee tthhee hheeaatt..

The SP700 impact printer is the latest addition to Star

Micronics' robust line of printers. Built specifically to work in

environments where heat and humidity can erode the type on

the kitchen order, the SP700 is an ideal solution. This fast,

two-color printer offers crisp, easy to read type for quick

viewing, clamshell design for easy paper loading and an

embedded power supply for space efficiency.

The SP700 ships complete, right out of the box, with free,

feature - packed software included on CD:

•Ability to add graphics (logo,coupons)

•Invert Printing By Driver

•Ethernet Connection Set Up Utility

•Printer Memory Set Up Utility

•Virtual Serial Port (USB or Ethernet)

Thanks to Microsoft’s Digitally Signed Certification (WHQL),

the SP700 drivers features Star’s “intuitive” compatibility

for Microsoft® applications including:

•JavaPOS®

•Linux

•Mac® OSX

•OPOS®

WWhheenn TThheerrmmaall IIssnn’’tt AAnn

OOppttiioonn UUssee SSttaarr’’ss SSPP770000

SSPP770000

2-Co or Printing Wa Mount Bracket “Drop In & Print”

Paper Load

Optiona Buzzer A arm

•C amshe Design for Easy Paper Loading

•Embedded Power Supp y

•2-Co or, High-Qua ity Graphics Printing

•Spi -Proof & Heat-Resistant

•Swappab e Interfaces Avai ab e

•Wa Mount

•Externa Buzzer Option

Features

The Ultimate Impact POS Solution!

Hardware

High Speed (4.7 LPS)

High Relability

Clamshell Splash Resistant Design

Embedded Power Supply

Two Color Capable

Recessed Cable Connections

Small Footprint

Paper Window

Swappable Communication Interfaces

“Drop In & Print” Paper and Ribbon Loading

Prints Up to 3 Copies At Once

Digitally Signed Drivers (WHQL)

Installation CD Included

Software

The Included Receipt Redesign Software

allows you to EASILY:

Add Images (Logos, Coupons and More)

Create a Virtual Serial Port for Legacy Applications

Configure an Ethernet Interface

Configure Memory Switch Settings

StarIO SD

Connectivity

Note: Connections in bbooddare supported;

grayed-out connection types may be

supported by specia request.

9 Pin Serial

25 Pin Serial

Parallel

USB

Powered USB

Ethernet

WiFi

Dual 9-Pin Serial/USB

Virtual Serial Port to USB

Virtual Serial Port to Ethernet

Virtual TCP/IP Port

Drivers

Windows®XP

Vista (32 bit / 64 bit)

Windows 7 (32 bit / 64 bit)

Server 2008 (32 bit / 64 bit)

XP Embedded

POS for .NET

OPOS™

JavaPOS™

USB Vendor Class

Linux™CUPS

Mac OS X CUPS

What's Included

Cutter (SP742), Tear Bar (SP712) or Journal Model

5 ft. Power Cord

Embedded Power Supply

58mm Guide

Power Switch Cover

CD Including Drivers with Software Utilities

Setup Guide

Optional Accessories

Ticket Alarm Buzzer (BU01-24-A)

Wall Mount Bracket (WB-S700)

Vertical Stand it (VS-S700)

Putty or Gray Color Housing

Technical Specifications

Print Method: 9 Pin Impact Dot Matrix

Print Speed: 4.7LPS (13 Receipts Per Minute)

Paper Width: 70mm (standard) / 58mm

(With Paper Guide)

Paper Thickness: 0.06 - 0.08mm

Emulation: Star Mode, ESC/POS™

Buffer: 8 bytes

Power: 110 to 230 VAC

MCBF: 22 Million Lines

Cutter: 1 Million Cuts

Dimensions: W=160mm, H=152, D=245mm

Ribbons: RC700B = 3M Characters

RC700BR = 1.5M Characters, Black

.075M Characters, Red

Warranty US and Canada: 3-Year Limited Warranty, Plus Optional Extended Services Agreement Policies (Extend-A-Star and Swap-A-Star)

For Further Information Sales: 1-800-782-7636 x107

Technical Support: 1-800-782-7636 x105

Web: http://www.starmicronics.com

SP700 Specifications

2/25/10
