Instruction and Operation Manual
S402
Thermal Mass Flow Meter
(Insertion)
Dear Customer,
Thank you for choosing our product.
Please read the operating instructions in full and carefully observed
them before starting up the device. The manufacturer cannot be held
liable for any damage which occurs as a result of non-observance or
non-compliance with this manual.
hould the device be tampered with in any manner other than a
procedure which is described and specified in the manual, the warranty
is void and the manufacturer is exempt from liability.
The device is destined exclusively for the described application.
UTO offers no guarantee for the suitability for any other purpose.
UTO is also not liable for consequential damage resulting from the
delivery, capability or use of this device.
2 S402
Table of Contents
1 afety instructions........................................................................4
2 Registered trademarks..................................................................6
3 RF exposure information and statement..........................................7
4 Application..................................................................................8
5 Features......................................................................................8
6 Technical data..............................................................................9
6.1 General.................................................................................9
6.2 Electrical data........................................................................9
6.3 Output-signals......................................................................10
6.4 Accuracy .............................................................................10
6.5 Volumetric flow ranges..........................................................11
7 Dimensional drawing...................................................................12
8 Determining the installation point.................................................13
8.1 Reserving the inlet and outlet sections.....................................13
9 Installing the sensor...................................................................15
9.1 Installation requirements.......................................................15
9.2 Installation..........................................................................16
9.2.1 Calculating the insertion depth..........................................16
9.2.2 Installing the sensor .......................................................18
9.2.3 Install safety line............................................................20
9.2.4 Removing the sensor ......................................................21
9.3 Electrical connection..............................................................21
10 ensor signal outputs................................................................23
10.1 Analog output.....................................................................23
10.2 Pulse output.......................................................................23
10.2.1 Pulse connection diagram...............................................25
10.3 Modbus Interface................................................................26
10.3.1 Modbus settings registers...............................................28
10.3.2 Values registers............................................................29
11 ervice App 4C-F ..................................................................30
12 Calibration...............................................................................31
13 Maintenance.............................................................................31
14 Disposal or waste......................................................................31
S402
1 afety instructions
1 Safety instructions
Please check if this instruction manual matches the
product type.
Please observe all notes and instructions indicated in this
manual. It contains essential information which must be
observed before and during installation, operation and
maintenance. Therefore this instruction manual must be read carefully
by the technician and by the responsible user or qualified personnel.
This instruction manual must be available at the operation site of the
flow meter at any time. In case of any obscurities or questions,
regarding this manual or the product, please contact the manufacturer.
WARNING!
Compressed air!
Any contact with quickly escaping air or bursting
parts of the compressed air system can lead to
serious injuries or even death!
•Do not exceed the maximum permitted pressure range (see
sensors label).
•Only use pressure tight installation material.
•Avoid that persons get hit by escaping air or bursting parts of the
instrument.
•The system must be pressureless during maintenance work.
WARNING!
Voltage used for supply!
Any contact with energized parts of the product, may
lead to an electrical shock which can lead to serious
injuries or even death!
•Consider all regulations for electrical installations.
•The system must be disconnected from any power supply during
maintenance.
•Any electrical work on the system is only allowed by authorized
qualified personal.
4 S402
1 afety instructions
ATTENTION!
Permitted operating parameters!
Observe the permitted operating parameters, any
operation exceeding this parameters can lead to
malfunctions and may lead to damage on the
instrument or the system.
•Do not exceed the permitted operating parameters.
•Make sure the product is operated in its permitted limitations.
•Do not exceed or undercut the permitted storage and operation
temperature and pressure.
•The product should be maintained and calibrated frequently, at
least annually.
General safety instructions
•It is not allowed to use the product in explosive areas.
•Please observe the national regulations before/during installation
and operation.
Remarks
•It is not allowed to disassemble the product.
•Always use spanner to mount the product properly.
ATTENTION!
Measurement values can be affected by malfunction!
The product must be installed properly and
frequently maintained, otherwise it may lead to
wrong measurement values, which can lead to
wrong result.
•Always observe the direction of the flow when installing the flow
meter. The direction is indicated on the housing.
•Do not exceed the maximum operation temperature at the sensor
probe tip.
•Avoid condensation on the sensor element because this will affect
accuracy enormously.
S402 5
1 afety instructions
Storage and transportation
•Make sure that the transportation temperature of the flow meter is
between -30 ... +70°C.
•For storage and transportation, it is recommended to use the
packaging which comes with the flow meter.
•Please make sure the storage temperature of the flow meter is
between -10 ... +50°C.
•Avoid direct UV and solar radiation during storage.
•For the storage the humidity must be <90%, no condensation.
2 Registered trademarks
UTO®Registered trademark of UTO iTEC
MODBU ®Registered trademark of the Modbus Organization,
Hopkinton, U A
Android™,
Google Play
Trademarks of Google LLC
6 S402
3 RF exposure information and statement
RF exposure information and statement
This equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed
and operated with minimum distance of 20 cm between the radiator and
your body.
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Remark: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
uch modifications could void the user’s authority to operate the
equipment.
Remark: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help。
•This device and its antenna(s) must not be co-located or operating
in conjunction with any other antenna or transmitter.
S402 7
4 Application
4 Application
The 402 is a flow meter that is designed to measure the consumption
of compressed air and gases within the permissible operating
parameters. These parameters can be found in chapter 6 Technical data.
The 402 can measure the following values:
•Volumetric flow of the compressed air or gas.
•Total consumption of the compressed air or gas.
The default factory settings are: Volumetric flow in m3/h and Total
Consumption in m3. Other units can be made available using the mobile
service app 4C-F .
The 402 is mainly used in compressed air systems in industrial
environments. The 402 is not designed to be used in explosive areas.
For the use in explosive areas please contact the manufacturer.
5 Features
•Insertion type flow meter for easy installations under pressure
through a ball valve.
•Thermal mass flow measurement, virtually independent of
pressure and temperature changes.
•IP65 casing provides robust protection in the industrial
environment.
•Very fast response time.
•High accuracy and wide measuring ranges. pecial ranges on
request.
•Tube diameters from 1/2” up to 12”, larger diameters on request.
•Android app for remote configuration and online reading
•Various interface available such as analogue, pulse, Modbus/RTU,
and MBU .
8 S402
6 Technical data
6 Technical data
6.1 General
FCC ID：2ASK2-SUTO-005
Parameters tandard unit flow: m3/h
Other units: m3/min, l/min, l/s, cfm, kg/h,
kg/min, kg/s
Consumption units: m3, ft3 , kg
Reference conditions I O1217 20°C 1000 mbar ( tandard-Unit)
DIN1343 0°C 1013.25 mbar (Norm-Unit)
Principle of
measurement
Thermal mass flow
ensor Glass-coated resistive sensor
Measuring medium Air, gas (non corrosive gas)
Operating temperature -30 ... +140°C fluid temperature
-30 ... +70°C casing
Humidity of the meas.
medium
< 90%, no condensation
Operating pressure 1.6 MPa(g)
Housing material PC + AB
Material of the probe
shaft, sensor head
(wetted parts)
tainless steel 1.4404 ( U 316L)
Protection class IP65
Dimensions ee dimensional drawing on page 12
Tube diameter 1/2” to 12” (bigger diameters on request)
Process connection G1/2” (I O 228/1)
Weight 450 g (220 mm standard)
6.2 Electrical data
Power supply 15 ... 30 VDC, 200 mA
S402 9
6 Technical data
6. Output-signals
Analogue output ignal: 4 ... 20 mA, isolated
caling: 0 to max flow
Max load: 250R
Pulse output 1 pulse per consumption unit, isolated switch,
max. 30 VDC, 200 mA (pulse length: 10 ... 120
ms, depending on flow rate)
Modbus output ee chapter 10.3
6.4 Accuracy
Accuracy* ±(2% of reading + 0.3% F )
Temperature drift: < 0.05%/K
tated accuracy at Ambient/process temperature 23°C ± 3°C
Ambient/process humidity <90%
Process pressure at 0.6 MPa(g)
Repeatability ±0.25% of reading
*pecified accuracy is valid only within the minimum and maximum flow
rates that are indicated in section 6.5.
10 S402
Altri manuali per S402
1
Questo manuale è adatto per i seguenti modelli
1
Indice
Altri manuali SUTO Strumento di misura
