SYMA GC88752-13 Manuale utente

1

User manual

Wi-Fi 2.4G frequency range：2412-2462MHz for 11b/g/n(HT20)

Senor

Senor

CMOS,1/5”color

resolution ratio

640*480（300k pixel）

focal length

3.6mm

Lens focal diameter ratio

F2.4

viewing angle

60。

minimum illumination

1.0Lux@550nm

video

Image coding format

H.264

image resolution;

VGA（640x480）/ QVGA（320x240）/QQVGA(160x120)

Maximum transmission rate of


25fps

Light frequency

50Hz、60Hz、Indoor and outdoor adaptive

V-REV

Vertical and horizontal image flip

AWB

SUPPORTING

Wireless

network interface;

IEEE802.11b/g/n

antenna gain

2.0dB

Working model

AP

networking protocol;

networking protocol;

TCP/IP，DHCP，SMPT，HTTP，DDNS，UPNP

working temperature

0 - 50C°，20% - 80%

storage temperature

-10°C ~ 60°，0% - 90%

working voltage

3.3V ~ 5V

working current

200mA ~ 250mA

OPERATION DISTANCE:

2-3M

2

Search and install APP “WIFI GO”, swich No of airplane, the green light will be flashing in 5

seconds, and search to the "FPV_WIFI__XXXX" in mobile phone set, so light keeping

when WIFI is connected,

3

Warning: Changes or modifications to this unit not expressly approved by the

party responsible for compliance could void the user’s authority to operate the

equipment.

NOTE: This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and can radiate radio

frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or more of the

following measures:

□Reorient or relocate the receiving antenna.

□Increase the separation between the equipment and receiver.

□Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

□Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject

to the following two conditions : (1) this device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.
