Topfield Srp-2300 Manuale utente

SRP-2300

User Guide

High Deﬁnition

Digital Satellite Receiver

Personal Video Recorder

Red Button (HbbTV) and Web-Portal

Common Interface(CI+)

The “CI Plus” Logo is a trademark of CI Plus LLP.

The lightning ﬂash with arrowhead symbol, in an equilateral triangle, is intended to alert the

user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of

suﬃcient magnitude to constitute a risk of electric shock to a person.

The exclamation point, in an equilateral triangle, is intended to alert the user to the presence of

important operation and maintenance instructions in the literature accompanying the product.

Precautions

• Read, keep and follow these instructions.

• Heed all warnings.

• Clean with a dry cloth only.

• Do not block any of the ventilation openings.

• Do not install near any heat sources or in direct sunlight as this will impair cooling.

• Do not operate this product near water. Do not place any of the objects ﬁlled with liquids, such as

vases on this unit.

• Do not try to change the plug or defeat its safety purpose. If the provided plug does not ﬁt into

your outlet, consult an electrician for replacement of the obsolete outlet.

• This product is designed for indoor use only.

• Place the digital receiver on a ﬁrm and level surface.

• Do not lay any objects such as magazines on this unit.

• Do not overload power outlets. Doing so may result in a risk of ﬁre or electrical shock.

• Never open this unit’s casing under any circumstances, or the warranty will be void.

• Unplug this unit during lightning storms or when unused for long periods of time.

• Refer all servicing to qualiﬁed service personnel. Servicing is required when the unit has been

damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or

objects have fallen into the unit, the unit became wet from rain or moisture, does not operate

normally, or has been dropped.

• Batteries, including those which contain no heavy metals, may not be disposed with other

household wastes. Please dispose of used batteries in an environmentally sound manner. Find

out the legal regulations which apply in your area.

iii

About this user guide

Thank you for purchasing our digital receiver. Please read this user guide carefully before you use the

digital receiver and keep it handy for future reference.

This User Guide covers the model SRP-2300 .

• Illustrations pictured in this manual may not be exactly the same as the actual product.

• The screenshots used in this manual may not be exactly the same as those you see on the actual

on-screen displays.

• Designs and speciﬁcations of the digital receiver and other accessories are subject to change with-

out any notice in order to introduce new features or improve the functionality of the product.

• iPhone and App Store are registered trademarks of Apple, Inc.

iv CONTENTS

Contents

Contents iv

1 Introduction 1

1.1 Features .............................. 2

1.2 Controlling the digital receiver .................. 3

1.2.1 Front panel ........................ 3

1.2.2 Remote control ...................... 5

1.3 Common Interface ......................... 7

2 Setup 9

2.1 Unpacking ............................. 9

2.2 Safety precautions ......................... 9

2.3 Rear panel connections ...................... 10

2.4 Connecting up your digital receiver ............... 12

2.4.1 Connecting to the antenna ................ 13

2.4.2 Connecting to your television set ............ 14

2.5 Switching on for the ﬁrst time .................. 16

3 Service Search 18

3.1 Searching for broadcasting services ............... 18

3.1.1 Conﬁguring LNB settings ................ 18

3.1.2 Searching for services .................. 21

3.2 Editing the transponder list ................... 23

3.3 Resetting to factory settings ................... 24

3.4 Clearing the services list ..................... 25

CONTENTS v

4 Preference Settings 26

4.1 Language settings ......................... 26

4.1.1 Menu language ...................... 26

4.1.2 Subtitle language ..................... 26

4.1.3 Hard of Hearing ..................... 27

4.1.4 Audio language ...................... 27

4.2 Video and audio settings ..................... 27

4.2.1 High deﬁnition television ................ 28

4.2.2 Television aspect ratio .................. 28

4.2.3 Audio mode ........................ 30

4.3 Local time setting ......................... 30

4.4 Parental control .......................... 32

4.5 Options for recording ....................... 34

4.6 Options for playback ....................... 35

4.7 Options for on-screen display .................. 36

4.8 Options for standby mode .................... 36

5 Every Day Use 37

5.1 Volume control .......................... 37

5.2 Watching television ........................ 37

5.2.1 The services list ...................... 37

5.2.2 The favourite service lists ................ 39

5.2.3 Viewing programme information ............ 40

5.2.4 Selecting audio tracks .................. 41

5.2.5 Selecting subtitle tracks ................. 41

5.2.6 Viewing teletext ...................... 41

5.3 Red Button Service (HbbTV) ................... 42

5.4 Viewing electronic programme guide .............. 43

5.5 Watching multifeed programme ................. 43

5.6 Using time-shift .......................... 44

6 Organising Services 46

6.1 Editing the services list ...................... 46

6.2 Editing the favourite lists ..................... 48

6.3 How to use on-screen keyboard ................. 49

vi CONTENTS

7 Recording and Playback 50

7.1 Recording a programme ..................... 50

7.1.1 Instant recording ..................... 51

7.1.2 Timer recording ...................... 52

7.1.3 Scheduling recordings using the programme guide . . 55

7.1.4 Recording a time-shifted programme .......... 55

7.1.5 Recording a pay service programme .......... 56

7.2 File archive ............................. 56

7.2.1 To delete a recording ................... 57

7.2.2 To sort recordings ..................... 57

7.2.3 To lock a recording .................... 57

7.2.4 To rename a recording .................. 58

7.2.5 To make a new folder ................... 58

7.2.6 To move a recording to another folder ......... 58

7.3 Playing back a recording ..................... 58

7.3.1 To navigate using the progress bar ........... 59

7.3.2 To play in slow motion .................. 60

7.3.3 To play in fast motion ................... 60

7.3.4 To make a bookmark ................... 60

7.3.5 To play back a recording repeatedly .......... 61

7.3.6 To play back a scrambled recording ........... 61

7.4 Copying a recording ....................... 62

7.5 Formatting the hard disk ..................... 62

8 Entertainment portal 63

8.1 Topﬁeld TV Portal ......................... 63

8.2 Copying ﬁles ............................ 64

8.3 Playing back a media ﬁle on the external hard drive . . . . . . 65

8.4 Playing back MP3 ﬁles ...................... 65

8.5 Viewing image ﬁles ........................ 66

8.5.1 How to move a ﬁle to the photo album ......... 66

8.6 Playing back a video ﬁle ..................... 66

9 Accessing via Network 68

9.1 Conﬁguring the router ...................... 68

9.1.1 To access within the local area network ......... 69

CONTENTS vii

9.1.2 To access over the Internet ................ 69

9.2 Conﬁguring the network setting on the digital receiver . . . . 71

10 Firmware Update 72

10.1 From a memory stick ....................... 72

10.2 Over the air(optional) ....................... 73

1 Introduction

Chapter 1

Introduction

The SRP-2300 digital receiver is fully compliant with the inter-

national Digital Video Broadcasting (DVB) standard, and thus

is able to receive digital broadcasts of that standard. For its

operation you need an antenna, which must be installed ap-

propriately.

NOTE

In general we equate a channel with a frequency. However,

unlike analogue broadcasts, digital broadcasts are not all

assigned to their own frequencies; instead, multiple televi-

sion broadcasts are transmitted through a single frequency.

The frequency in digital broadcasting is usually called trans-

ponder or multiplex. To reduce confusion in this manual,

the word service is preferably used than channel as a term

to indicate one television or radio broadcast.

The SRP-2300 also oﬀers the HbbTV (Hybrid Broadcast Broad-

band TV) platform that combines TV services via broadcast

with services via broadband. With this digital receiver adopt-

ing this integrated platform for broadcast and broadband

services, you can enjoy high quality digital broadcast and

seamless on-line streaming of web contents at the same time.

2 Introduction

The following ﬁgure shows the working ﬂow of the HbbTV-

compliant receiver;

P+

P-

Portal

Channel 1

Channel 2

Channel 3

Channel 4

Channel 5

Channel 6 Weather

Music

Films

Catch Up

Quiz

Portal

Teletext

TXT

Info

TV Services Broadcast-related applications

(content can be broadcast, broadband or both)

VoD

Widgets

Broadcast-independent

applications

Red Button

1.1 Features

This digital receiver has the following features:

• Supports DiSEqC 1.0 and DiSEqC 1.1 protocols.

• Can store up to 5,000 television and radio services.

• You can edit the services list.

• Can create lists of your favourite services.

• Can view information about the current television or ra-

dio programme.

• Has an electronic programme guide that provides an

overview of scheduled programmes.

• You can record up to four services while you are cur-

rently watching another.

• You can record many programmes using a built-in hard

drive with large storage capacity.

• Time-shift is a special technical feature available on this

digital receiver. You can pause a programme you are
