FormNo.3418-578RevA
IgnitionServiceKit
TX1000CompactToolCarrier
ModelNo.137-9050
InstallationInstructions
WARNING
CALIFORNIA
Proposition65Warning
ThisproductcontainsachemicalorchemicalsknowntotheStateofCalifornia
tocausecancer,birthdefects,orreproductiveharm.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
Safety
SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal137-9052
137-9052
1.Engine—stop3.Engine—start
2.Engine—run
©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3418-578*A
Installation
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Preparethemachine.
Plate1
Ignitionswitch1
Decal1
Screw2
Wire-harnessadapter1
2
Key2
Installtheswitch.
1
PreparingtheMachine
NoPartsRequired
Procedure
1.Parkthemachineonalevelsurface.
2.Engagetheparkingbrake.
3.Lowertheloaderarms.
4.Shutofftheengineandremovethekey.
g036689
Figure1
2
2
InstallingtheSwitch
Partsneededforthisprocedure:
1Plate
1Ignitionswitch
1Decal
2Screw
1Wire-harnessadapter
2Key
Procedure
1.Openthehoodandsecuretheproprod.
2.Disconnectthebattery;refertotheOperator’s
Manual.
3.Removethecoverplate(Figure2).
g038212
Figure2
1.Bolt(1/4x3/4inch)2.Coverplate
4.Removetheoldignitionswitch(Figure3).
g231591
Figure3
1.Switch2.Wireharness
5.Aligntheplatewiththeedgesontheframe
(Figure4).
g230876
Figure4
1.Plate2.Edge
6.Usingtheplateasatemplate,drill2holesinthe
frameasshownwitha4mm(5/32inch)drillbit.
7.Assemblethedecal,wire-harnessadapter,and
ignitionswitchtotheplate(Figure5).
Note:Discardtheincludedbackupwasher.
Installthepartsshown.
3
g230873
Figure5
1.Harnessadapter4.Decal
2.Switch5.Nut
3.Plate
8.Connectthewireharnesstotheadapter.
9.Securetheassemblytotheframeusingthe2
self-tappingscrews(Figure6).
g230874
Figure6
1.Screws
10.Plugthemainconnectortotheadapteronthe
keyswitch.
Important:Alsoplugthesinglewireonthe
adapterintothecorrespondingconnector
onthemainharness.
11.Installthecoverplate(Figure2).
12.Connectthebattery;refertotheOperator’s
Manual.
13.Closethehood.
4
