TRENDnet TEW-222CF Manuale utente

Doc. No.: 090402-02

TEW-222CF

IEEE802.11b11Mbps

CompactFlashCard

User Guide

REGULATORY STATEMENTS

FCC Certification

The United States Federal Communication Commission (FCC)

and the Canadian Department of Communications have

established certain rules governing the use of electronic

equipment.

Part15, Class B

This device complies with Part 15 of FCC rules. Operation is

subject to the following two conditions:

1) This device may not cause harmful interface, and

2) This device must accept any interface received, including

interface that may cause undesired operation. This

equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate

radio frequency energy, and if not installed and used in

accordance with the instructions, may cause harmful

interference to radio communications. However, there is no

guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful

interference to radio or television reception, which can

be determined by turning off and on, the user is encouraged

to try to correct the interference by one or more of the

following measures:

?Reorient or relocate the receiving antenna.

?Increase the distance between the equipment and receiver.

?? Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

CAUTION:

1) To comply with FCC RF exposure compliance

requirements, a separation distance of at least 20 cm must

be maintained between the antenna of this device and all

persons.

2) This transmitter must not be co-located or operating in

conjunction with any other antenna or transmitter.

Table of Contents

INTRODUCTION..................................................1

FEATURES................................................................1

WIRELESS NETWORK OPTIONS.............................2

The Peer-to-Peer Network......................2

The Access Point Network......................3

LED INDICATORS...................................................3

FOR WINDOWS CE3.0........................................5

SOFTWARE INSTALLATION....................................5

HARDWARE INSTALLATION..................................7

NETWORK CONNECTION........................................8

CONFIGURATION UTILITY...................................11

Network Status Icon & Icon Menu......11

The Status Icon.......................................11

Icon Menu................................................12

Link...........................................................13

Configuration..........................................14

Encryption................................................16

Site Survey...............................................18

About........................................................19

FOR NOTEBOOK PC.........................................20

HARDWARE INSTALLATION................................20

SOFTWARE INSTALLATION..................................20

In Windows 98........................................20

In Windows ME......................................22

In Windows 2000...................................24

In Windows XP.......................................26

NETWORK CONNECTION......................................28

In Windows 98/ME................................28

In Windows 2000/XP.............................31

CONFIGURATION...................................................34

Use Manufacturer’s Configuration

Utility........................................................34

Use Windows XP's Wireless

Configuration Utility..............................43

SPECIFICATIONS ..............................................48

-1-

INTRODUCTION

A wireless LAN is like a regular LAN, except

that you can share information without looking

for a place to plug in, and augment networks

without installing or moving wires. Based on

radio frequency (RF) technology, a wireless LAN

transmits and receives data over the air, along

with the guarantee to provide privacy and

noninterference by the use of separate radio

frequency.

The 802.11b Wireless CompactFlash Card is the

perfect solution for your wireless network

applications and based on the IEEE 802.11b

standard offering a data rate of 11Mbps in a

wireless LAN environment. It is a high-speed

wireless network card that connect directly to

your PDA or Notebook (with a passive

adapter)—just plug it in and you’re ready to share

data, printers, or high speed Internet access over

your existing wireless network. User-friendly

software makes it simple to set up.

Features

??Compliant with IEEE 802.11b standard for

2.4GHz Wireless LAN

??Compliant with Compact Flash Type I

Standard

??Compatible with Windows CE 3.0

??Compatible with Windows 98/ME/2000/XP

(with a passive adapter)

??Plug-and-play operation provides easy setup

??Works with all existing network infrastructure

-2-

??Compatible with specific wireless products

and services

??Capable of up to 128-Bit WEP Encryption

??Freedom to roam while staying connected

??11 Mbps High-Speed Transfer Rate

??Rich diagnostic LED indicators with built-in

Antenna

??Lower power consumption and power save

mode

??Easy to install and configure

Wireless Network Options

The Peer-to-Peer Network

This network installation lets you set a small

wireless workgroup easily and quickly.

Equipped with Wireless CompactFlash Cards or

wireless PCI, you can share files and printers

between each PC and laptop.

Or you can use one computer as an Internet

Server to connect to a wired global network and

share files and information with other PCs via a

wireless LAN.

-3-

The Access Point Network

The network installation allows you to share files,

printers, and Internet access much more

conveniently. With Wireless CompactFlash

Cards, you can connect wireless LAN to a wired

global network via anAccess Point.

LED Indicators

Link: Orange (On/Blink)

Access Point Mode

Glow –linking to an Access Point.

Blink –searching for Access Points in the

networks.

-4-

Peer-to-Peer Mode

Glow –forming a Basic Service Set or joining to

a Basic Service Set.

Blink –searching for other wireless LAN cards in

the wireless network.

Act: Green (ON/OFF)

Transmitting/receiving wireless data.

-5-

FOR WINDOWS CE3.0

Software Installation

Connect your PDA to your PC. Make sure you

have the Microsoft ActiveSync Utility installed

on your PC to make an active connection.

Caution: DO NOT insert the Wireless

CompactFlash Card into the PDA BEFORE

installing the configuration utility.

1. Insert the device driver CD into the CD-ROM

drive.

2. Open the WINCE3.0 folder.

3. Inside the WINCE3.0 folder, click on

PrismForPocketCE.

For Handheld PC users: Please select

PrismForHandHeldCE.

-6-

4. Click Next to continue.

5. Click OK.

6. Click Finish.
