SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 1 of 15

SpeedDome®Ultra VIIE

Day/Night Camera

Dome Configuration

Utility

Operator’s Manual Supplement

Contents

About this Supplement .......................................... 1

New SpeedDome Ultra VIIE Features .................. 1

DirectSet Menu...................................................... 2

Menu Programming Navigation............................. 3

Changing Camera Functions within Presets......... 3

Programming Motion Detection............................. 4

Programming Sequences...................................... 7

Pattern Options: Fixed or Variable Speed............. 9

Recording Patterns When Configured for 16 ...... 10

SensorNet, RS-422, Manchester, and UTC

Controllers and Switchers .............................. 10

Specifications-Indoor Dome ................................ 12

Specifications-23X Day/Night Camera................ 14

Declarations ........................................................ 15

About this Supplement

This supplement provides detailed information

about SpeedDome Ultra VIIE camera dome

features that are not currently covered in your

operator’s manual. This supplement supports

information found in the following manuals:

•Day/Night Camera Dome Configuration Utility

Operator’s Manual, 8200-0184-04

NOTE: Keep this supplement with your operator’s

manual for reference purposes.

If you need assistance...

Contact your Sales Representative.

New SpeedDome Ultra VIIE

Features

SpeedDome Ultra VIIE provides the following

features with firmware version 0710-0532-0100

and newer.

•DirectSet Menu for accessing commonly used

dome settings.

•AD Up-the-Coax protocol (UTC) for compatible

American Dynamics controllers.

•Motion Detection (available only on domes with

the following part numbers: 0101-0120-01, 0101-

0120-02, 0101-0120-03, 0101-0120-04, 0101-

0120-05, 0101-0120-06).

•16 Sequences.

•Up to 16 Patterns.

•Ability to change camera functions for each

Preset.

Updated information is also provided for the

following:

•SensorNet, RS-422, Manchester, and UTC

matrix switchers and controllers.

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 2 of 15

DirectSet Menu

The DirectSet Menu provides easy access to

commonly used SpeedDome Ultra VIIE features

when used with compatible controllers. This allows

you to change or activate features without starting

the dome configuration menu. See Figure 1 for

examples of the Day/Night camera DirectSet

menu.

Figure 1: Day/Night Camera Dome DirectSet

Menu (3 screens)

To access a feature on the menu, enter the

number and press the DirectSet button (varies by

controller). Table 1 provides a description of the

available options.

Table 1: DirectSet Menu Options

Command Description

0+DirectSet Toggle DirectSet Menu: Toggles

between displaying and hiding

the DirectSet menu.

1+DirectSet Dome Config Menu: Displays the

SpeedDome Ultra configuration

menu.

2+DirectSet Auto Iris/Auto Focus: Resumes

Auto Focus/Auto Iris mode.

3+DirectSet Flip: Rotates the SpeedDome

180° from its current pointing

direction. This is the same as

pressing the Flip button on

compatible controllers.

4+DirectSet Peel Pattern: Runs the default

Apple Peel Pattern. This is the

same as pressing the Peel button

on compatible controllers.

10+DirectSet Night Mode: Sets the dome IR

mode setting to ON. The dome

switches to full-time black-and-

white (B/W) mode.

11+DirectSet Day Mode: Sets the dome IR

mode setting to OFF. The dome

switches to full-time color mode.

12+DirectSet Auto Day/Night Mode: Resumes

the most recently selected

automatic IR mode setting.

•Auto High: B/W mode activates

~30 lux.

•Auto Mid: B/W mode activates

~3 lux.

•Auto Low: B/W mode activates

~ 0.5 lux

13+DirectSet WDR On: Enables Wide Dynamic

Range (WDR). Use this setting

when both bright and low light

areas need to be viewed

simultaneously.

14+DirectSet WDR Off: Disables Wide

Dynamic Range (WDR). Use this

setting when the light level is

constant or when changes in

lighting conditions are gradual.

15+DirectSet Smooth Scan: Initiates a smooth

360° clockwise rotation around

the dome axis using the current

tilt, zoom and focus settings.

0 TOGGLE DIRECT SET MENU

1 DOME CONFIG MENU

2 AUTO IRIS/AUTO FOCUS

3 FLIP

4 PEEL PATTERN

10 NIGHT MODE

11 DAY MODE

12 AUTO DAY/NIGHT MODE

13 WDR ON

14 WDR OFF

FOCUS NEAR = next page

15 SMOOTH SCAN

16 STEPPED SCAN

17 RANDOM SCAN

20 DOME INFORMATION

51 SEQUENCE 1

52 SEQUENCE 2

53 SEQUENCE 3

54 SEQUENCE 4

55 SEQUENCE 5

56 SEQUENCE 6

FOCUS NEAR = next page

57 SEQUENCE 7

58 SEQUENCE 8

59 SEQUENCE 9

60 SEQUENCE 10

61 SEQUENCE 11

62 SEQUENCE 12

63 SEQUENCE 13

64 SEQUENCE 14

65 SEQUENCE 15

66 SEQUENCE 16

FOCUS NEAR = previous page

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 3 of 15

Command Description

16+DirectSet Stepped Scan: Initiates a

clockwise rotation around the

dome axis pausing briefly every

10° (at 1x zoom) for 3 seconds

using the current tilt, zoom and

focus settings.

17+DirectSet Random Scan: Initiates a

clockwise or counter-clockwise

rotation around the dome axis

using the current tilt, zoom and

focus settings. The dome pauses

randomly as it rotates around the

axis.

20+DirectSet Dome Information: Displays the

Dome Information screen

available through the dome

configuration menu.

51+DirectSet Sequence: Runs Sequence 1

52+DirectSet Sequence: Runs Sequence 2

53+DirectSet Sequence: Runs Sequence 3

54+DirectSet Sequence: Runs Sequence 4

55+DirectSet Sequence: Runs Sequence 5

56+DirectSet Sequence: Runs Sequence 6

57+DirectSet Sequence: Runs Sequence 7

58+DirectSet Sequence: Runs Sequence 8

59+DirectSet Sequence: Runs Sequence 9

60+DirectSet Sequence: Runs Sequence 10

61+DirectSet Sequence: Runs Sequence 11

62+DirectSet Sequence: Runs Sequence 12

63+DirectSet Sequence: Runs Sequence 13

64+DirectSet Sequence: Runs Sequence 14

65+DirectSet Sequence: Runs Sequence 15

66+DirectSet Sequence: Runs Sequence 16

255+DirectSet Admin: Reset Dome (Baxall)

Menu Programming

Navigation

The SpeedDome Ultra VIIE is programmed from

on-screen menus that are accessible through your

controller (keyboard, virtual keyboard, or Touch

Tracker®).

The starting point for programming is the

Configuration Menu. To access the menu on

most controllers press and hold the following

buttons in sequence:

Iris Open > Focus Far > Zoom Out

(Consult your keyboard manual for instructions if

unable to access menu programming.)

When programming dome functions, the primary

buttons used for navigation, item selection, and

value increases or decreases are:

Joystick. The joystick allows you to move the

cursor—represented by highlighting—around the

menus. You can select a field when it is

highlighted.

Focus Far button. Pressing the Focus Far button

selects or enables a choice on a highlighted field.

Zoom In/Out button. Pressing the Zoom In/Out

button scrolls a pre-determined list of values either

up or down in a highlighted field.

Changing Camera Functions

within Presets

When Presets are created, they adopt the dome

parameters defined in the Camera Functions

screen. You can now customize camera functions

for each Preset by accessing the Camera

Functions screen from the Preset screen.

Note: If you change the parameters in the Camera

Functions Menu for an existing Preset, you will

need to reprogram the Preset to save the changes.

Motion Detection Zones associated with the Preset

will also require reprogramming.

Follow the steps below to change camera functions

with Presets:

1. Access the Dome Configuration Menu

(Figure 2) by pressing Iris Open, Focus Far

and Zoom Out on your controller.

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 4 of 15

Figure 2.

2. Use the joystick to highlight Alarms / Areas /

Home / Presets / PZ and Press Focus Far to

select. The Alarms / Areas / Home / Presets /

PZ screen appears (Figure 3).

Figure 3.

3. Use the joystick to highlight Presets and press

Focus Far to select. The Select Preset To

Program screen appears (Figure 4).

Figure 4.

4. Use the joystick to highlight the PRESET

NUMBER field and press the Zoom In/Out

button until your desired Preset number

appears.

5. Use the joystick to highlight Camera

Functions and press the Focus Far button.

The Camera Functions screen appears

(Figure 5).

Figure 5.

6. Make your desired changes. For details on the

Camera Functions screen, consult Chapter 3

of the Day/Night Camera Dome Configuration

Utility Operator’s Manual, 8200-0184-04.

7. Use the joystick to highlight EXIT and press the

Focus Far button to select. The Select Preset

to Program screen appears.

8. Program (or reprogram) the Preset by selecting

FOCUS FAR to program preset (see Note on

page 3).

Programming Motion

Detection

Applicable Day/Night SpeedDome cameras are

capable of providing motion detection based on

Preset camera views. Motion detection can be

programmed for any of the 96 Presets defined in

the dome. The motion detection feature is

programmed from the Select Preset to Program

screen.

Understanding Motion Zones

Motion Detection is programmed by positioning

motion zones (represented by rectangular blocks)

within a Preset scene. When motion occurs within

any of the motion zones, the dome will respond by

triggering the action you programmed for it—either

an output, a Preset, a Pattern, or by taking no

action.

DOME CONFIGURATION MENU

PAN / TILT / ZOOM / SYNC OPTS

CAMERA FUNCTIONS

ALARMS / AREAS / PRESETS / PZ

ON-SCREEN TEXT DISPLAY

LANGUAGE / PASSWORD

DOME INFORMATION

RESET TO FACTORY SETTINGS

QUIT WITHOUT SAVING

EXIT AND SAVE CHANGES

ALARMS/AREAS/HOME/PRESETS/PZ

SET ALARM ACTIONS

SET ALARM STATES

SET HOME POSITION

SET NORTH POSITION

AREA BOUNDARIES

PRIVACY ZONES

PRESETS

SCAN LIMITS

EXIT

SELECT PRESET TO PROGRAM

PRESET PRESET NAME

NUMBER

1-96 PRESET 1-96

MOTION DETECTION SETUP

SEQUENCE SETUP MENU

CAMERA FUNCTIONS

FOCUS FAR to program preset

EXIT

CAMERA FUNCTIONS

Auto White Bal ON

IR MODE Auto Low

WDR OFF

AGC/Shutter Max Gain Limit

Open Shutter 28 dB 1/4 s

RESET TO FACTORY SETTINGS

EXIT

CAMERA FUNCTIONS

Auto White Bal ON

IR MODE Auto Low

WDR OFF

AGC/Shutter Max Gain Limit

Open Shutter 28 dB 1/4 s

RESET TO FACTORY SETTINGS

EXIT

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 5 of 15

You can create up to eight motion zones for every

Preset scene. An example of a Preset scene with

one motion zone is shown in Figure 6

Figure 6.

IMPORTANT NOTE: Motion Detection will not

function under certain Camera Functions settings.

Before programming, verify the following:

•IR Mode must not be set to ON.

•WDR must not be set to ON.

Follow the steps below to change the IR Mode and

WDR settings:

1. Access the Dome Configuration Menu

(Figure 7) by pressing Iris Open, Focus Far

and Zoom Out on your controller.

Figure 7.

2. Use the joystick to highlight Camera

Functions and press Focus Far to select. The

Camera Functions screen appears (Figure 8).

Figure 8.

3. Use the joystick to highlight the IR MODE field

and press the Zoom In/Out button to change

settings. Options are OFF, ON, Auto Low, Auto

Mid, Auto High.

4. Use the joystick to highlight the WDR field and

press the Zoom In/Out button to change

settings. Options are On, OFF.

5. Use the joystick to highlight EXIT and press

Focus Far to select.

6. When the Dome Configuration Menu

appears, use the joystick to highlight EXIT

AND SAVE CHANGES and press Focus Far.

Steps to Programming Motion

Detection

Follow the steps below to program motion

detection.

1. Access the Dome Configuration Menu

(Figure 9) by pressing Iris Open, Focus Far

and Zoom Out on your controller.

Figure 9.

2. Use the joystick to highlight Alarms / Areas /

Home / Presets / PZ and Press Focus Far to

select. The Alarms / Areas / Home / Presets /

PZ screen appears (Figure 10).

MOTION DETECTION SETUP

PRESET 1

ZONE 1

ESC/FOCUS = save & exit

One

motion

zone

DOME CONFIGURATION MENU

PAN / TILT / ZOOM / SYNC OPTS

CAMERA FUNCTIONS

ALARMS / AREAS / PRESETS / PZ

ON-SCREEN TEXT DISPLAY

LANGUAGE / PASSWORD

DOME INFORMATION

RESET TO FACTORY SETTINGS

QUIT WITHOUT SAVING

EXIT AND SAVE CHANGES

CAMERA FUNCTIONS

Auto White Bal ON

IR MODE Auto Low

WDR OFF

AGC/Shutter Max Gain Limit

Open Shutter 28 dB 1/4 s

RESET TO FACTORY SETTINGS

EXIT

DOME CONFIGURATION MENU

PAN / TILT / ZOOM / SYNC OPTS

CAMERA FUNCTIONS

ALARMS / AREAS / PRESETS / PZ

ON-SCREEN TEXT DISPLAY

LANGUAGE / PASSWORD

DOME INFORMATION

RESET TO FACTORY SETTINGS

QUIT WITHOUT SAVING

EXIT AND SAVE CHANGES

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 6 of 15

Figure 10.

3. Use the joystick to highlight Presets and press

Focus Far to select. The Select Preset To

Program screen appears (Figure 11).

Figure 11.

4. Use the joystick to highlight Motion Detection

Setup and press Focus Far. The Motion

Detection Setup screen appears (Figure 12).

Figure 12.

5. The PRESET number field is highlighted.

Press the Zoom In/Out button until the Preset

number you want to use for this motion

detection setup (1-96) appears.

6. Use the joystick to highlight the ZONE field.

Use the Zoom In/Out button until the zone

number (1-8) you want to apply to the Preset

appears.

7. Use the joystick to highlight the SENS field.

Use the Zoom In/Out button until the

sensitivity level you want to apply to your zone

appears. Note: Zone sensitivity ranges from

zero (no sensitivity) to five (high sensitivity).

Zero is used to disable individual zones on a

temporary basis.

8. Use the joystick to highlight the ACTION field.

Use the Zoom In/Out button until the action

you want appears. Action determines how the

system will respond when motion is detected.

Choices are:

No Action* - no action occurs

Preset (1-96) – calls a Preset

Pattern (1-16) – runs a Pattern

Output (1-4) – activates an output

*When No Action is programmed on the motion

detection screen, the dome’s return to a Home

position is delayed as long as motion occurs within

the time specified on the return-to-home screen.

9. Press the Focus Far button. The Motion

Detection Setup screen appears (Figure 13).

Figure 13.

10. Using the joystick, move the rectangular zone

indicator to a desired location and press Focus

Far to save and exit. (Note: The rectangular

zone indicator does not appear on-screen until

the joystick is moved.)

11. Repeat steps 6-10 to create additional

detection zones (1-8).

12. When the Motion Detection Setup screen

appears, use the joystick to highlight EXIT and

press Focus In/Out to save.

ALARMS/AREAS/HOME/PRESETS/PZ

SET ALARM ACTIONS

SET ALARM STATES

SET HOME POSITION

SET NORTH POSITION

AREA BOUNDARIES

PRIVACY ZONES

PRESETS

SCAN LIMITS

EXIT

SELECT PRESET TO PROGRAM

PRESET PRESET NAME

NUMBER

1-96 PRESET 1-96

MOTION DETECTION SETUP

SEQUENCE SETUP MENU

CAMERA FUNCTIONS

FOCUS FAR to program preset

EXIT

MOTION DETECTION SETUP

1 PRESET 1

ZONE SENS ACTION

1 0 NO ACTION XX

HIDE ALL ZONES NO

DELETE ALL ZONES

FOCUS FAR to program zones

EXIT

MOTION DETECTION SETUP

PRESET 1

ZONE 4

ESC/FOCUS = save & exit

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 7 of 15

13. Continue to select EXIT on every screen until

menu programming ends.

Note: Motion detection can be hidden without

erasing the motion detection configuration (for

example, during the day when motion is expected).

To hide motion detection, select Yes on the Hide

All Zones field on the Motion Detection Setup

screen.

Activating Motion Detection

Motion detection works in conjunction with existing

Presets. To begin monitoring motion detection, call

the Preset to which motion detection has been

applied.

Note: Motion detection is not guaranteed to

capture 100% of all activity.

Programming Sequences

A Sequence is a sequential display of multiple

camera Presets. Sequences provide a methodical

and effective way to monitor multiple areas of

interest by switching to different Presets

automatically. Sequences are programmed from

the Select Preset to Program screen.

Sequences are created by identifying Preset views

to include in the Sequence and specifying a dwell

time that controls how long each Preset remains on

screen before switching to another Preset. Up to

16 Sequences can be created, each with 16 steps

(Presets).

Steps to Programming

Sequences

Follow the steps below to program Sequences.

1. Access the Dome Configuration Menu

(Figure 14) by pressing Iris Open, Focus Far

and Zoom Out on your controller.

Figure 14.

2. Use the joystick to highlight Alarms / Areas /

Home / Presets/PZ and Press Focus Far to

select. The Alarms / Areas / Home / Presets /

PZ screen appears (Figure 15).

Figure 15.

3. Use the joystick to highlight Presets and press

Focus Far to select. The Select Preset to

Program screen appears (Figure 16).

Figure 16.

4. Use the joystick to highlight Sequence Setup

Menu and press Focus Far to select. The

Sequence Setup Menu screen appears

(Figure 17).

DOME CONFIGURATION MENU

PAN / TILT / ZOOM / SYNC OPTS

CAMERA FUNCTIONS

ALARMS / AREAS / PRESETS / PZ

ON-SCREEN TEXT DISPLAY

LANGUAGE / PASSWORD

DOME INFORMATION

RESET TO FACTORY SETTINGS

QUIT WITHOUT SAVING

EXIT AND SAVE CHANGES

ALARMS/AREAS/HOME/PRESETS/PZ

SET ALARM ACTIONS

SET ALARM STATES

SET HOME POSITION

SET NORTH POSITION

AREA BOUNDARIES

PRIVACY ZONES

PRESETS

SCAN LIMITS

EXIT

SELECT PRESET TO PROGRAM

PRESET PRESET NAME

NUMBER

1-96 PRESET 1-96

MOTION DETECTION SETUP

SEQUENCE SETUP MENU

CAMERA FUNCTIONS

FOCUS FAR to program preset

EXIT

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 8 of 15

Figure 17.

5. Use the Joystick to highlight the SEQUENCE

NUMBER field. Press Zoom In/Out to change

values (1-16).

6. Use the joystick to highlight the STEP field.

Press Zoom In/Out to scroll through available

steps. Steps are displayed in groups of 1-4, 5-8,

6-12, and 13-16.

7. Use the joystick to highlight the PRESET field

and press Zoom In/Out until the desired Preset

number appears (1-96).

8. Use the joystick to highlight the DWELL TIME

MIN field and press Zoom In/Out until the

number of minutes you want the Preset to

remain on screen appears (0-10 minutes).

9. Use the joystick to highlight the DWELL TIME

SEC field and press Zoom In/Out until the

number of seconds you want the Preset to

remain on screen appears (0-60 seconds in 10-

second increments).

10. Repeat steps 8 through 10 above until the first 4

presets have been programmed. If more

Presets are desired, highlight to the STEP field

and use Zoom In/Out to display steps 5-8.

11. When finished, use the joystick to highlight

EXIT and press Focus Far to select.

12. At the Dome Configuration Menu screen,

highlight EXIT AND SAVE CHANGES and

press Focus Far to save.

Running Sequences 1-16

Two options are available for running Sequences:

•Option 1 – If your keyboard supports the

DirectSet command, you can use it to run a

Sequence immediately (see DirectSet Menu,

page 2). Consult your keyboard manual for

information on DirectSet functions.

•Option 2 - Use the Set Home Position method

to schedule one Sequence to run when the

dome returns to its home position (after a

defined period of inactivity).

Follow the steps below to run Sequences from the

Set Home Position screen:

1. Access the Dome Configuration Menu

(Figure 18) by pressing Iris Open, Focus Far

and Zoom Out on your controller.

Figure 18.

2. Use the joystick to highlight Alarms / Areas /

Home / Presets / PZ and Press Focus Far to

select. The Alarms / Areas / Home /

Presets/PZ screen appears (Figure 19).

Figure 19.

3. Use the joystick to highlight Set Home

Position and press Focus Far to select. The

Set Home Position screen appears

(Figure 20).

SEQUENCE SETUP MENU

SEQUENCE NUMBER 1

STEP 1-4 DWELL TIME

STEP PRESET MIN / SEC

1 1 0 0

2 1 0 0

3 1 0 0

4 1 0 0

EXIT

DOME CONFIGURATION MENU

PAN / TILT / ZOOM / SYNC OPTS

CAMERA FUNCTIONS

ALARMS / AREAS / PRESETS / PZ

ON-SCREEN TEXT DISPLAY

LANGUAGE / PASSWORD

DOME INFORMATION

RESET TO FACTORY SETTINGS

QUIT WITHOUT SAVING

EXIT AND SAVE CHANGES

ALARMS/AREAS/HOME/PRESETS/PZ

SET ALARM ACTIONS

SET ALARM STATES

SET HOME POSITION

SET NORTH POSITION

AREA BOUNDARIES

PRIVACY ZONES

PRESETS

SCAN LIMITS

EXIT

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 9 of 15

Figure 20.

4. On the highlighted ACTION field, press the

Zoom In/Out button until Sequence appears.

5. Use the joystick to highlight the number field.

Press the Zoom In/Out button until your

desired Sequence number appears.

6. Use the joystick to highlight the RETURN TIME

MINS field. Press the Zoom In/Out button to

specify when the dome is to return to its home

position after a period of inactivity (1-60 min.).

This will trigger the Sequence to run.

7. Use the joystick to highlight the EXIT field and

press Focus Far to select.

8. Continue to exit until the completely out of all

programming menus.

Note: If a Preset or a Pattern is called by either an

alarm or motion detection while a Sequence is

running, the Sequence will be interrupted.

Pattern Options: Fixed or

Variable Speed

A Pattern is a series of programmed pan/tilt/zoom

dome movements. The SpeedDome Ultra VIIE

allows you to create fixed speed or variable speed

Patterns (variable speed Patterns are dependent

on system capability).

The SpeedDome Ultra VIIE provides three options

when configuring the system for Patterns:

Setting Description

Off Allows programming of three fixed speed

Patterns. The three Patterns are limited

to a total of 99 pan/tilt/zoom movements

(e.g., if one Pattern uses 50 movements,

the remaining two Patterns are limited to

a total of 49 movements). Note: The

VM1 and VM96 systems only support

the OFF setting.

3Allows programming of three variable

speed Patterns. Each Pattern can have

up to 99 pan/tilt/zoom movements.

16 Allows programming of 16 variable

speed Patterns. Each Pattern can have

up to 99 pan/tilt/zoom movements.

Use the following steps to configure the dome for

Patterns:

1. Enter the Dome Configuration Menu

(Figure 21) by pressing Iris Open, Focus Far

and Zoom Out on your controller.

Figure 21.

2. Use the joystick to highlight On-Screen Text

Display and press Focus Far to select. The

On-Screen Text Display screen appears

(Figure 22).

Figure 22.

SET HOME POSITION

ACTION SEQUENCE 1

RETURN TIME MINS 10

EXIT

DOME CONFIGURATION MENU

PAN / TILT / ZOOM / SYNC OPTS

CAMERA FUNCTIONS

ALARMS / AREAS / PRESETS / PZ

ON-SCREEN TEXT DISPLAY

LANGUAGE / PASSWORD

DOME INFORMATION

RESET TO FACTORY SETTINGS

QUIT WITHOUT SAVING

EXIT AND SAVE CHANGES

ON-SCREEN TEXT DISPLAY

STATUS DISPLAY OFF

DISABLE ALL NAMES? YES

DIAGNOSTIC DISPLAY OFF

DIRECTION INDICATOR OFF

PATTERN SELECT 16

NAME CONFIGURATION MENU

TEXT ATTRIBUTE OPTIONS

EXIT

SPEEDDOME ULTRA VIIE DAY/NIGHT CAMERA DOME CONFIGURATION UTILITY 8200-0184-12, REV. A

OPERATOR’S MANUAL SUPPLEMENT 10 of 15

3. Use the joystick to highlight the PATTERN

SELECT field and press Zoom In/Out to select

Off, 3, or 16.

4. Use the joystick to highlight EXIT and press

Focus Far to select. The Dome Configuration

Menu appears.

5. Use the joystick to highlight EXIT AND SAVE

CHANGES and press Focus Far to save.

Recording Patterns When

Configured for 16

Recording Patterns when the Pattern Select field

is set for Off, 3, or 16 is accomplished through

keyboard commands (consult your keyboard user

guide). However, additional steps are required

when the Pattern Select field is set for 16.

Follow the steps below to record 16 variable speed

Patterns:

1. Enter the appropriate keyboard commands to

record a Pattern, using 1, 2, or 3 as your

Pattern number (Consult your keyboard user

guide for specific steps.). The Pattern Select

screen appears (Figure 23)

Figure 23.

2. Use the joystick to highlight a desired Pattern

number (1-16). Press Focus Far to continue.

3. Pan/tilt/zoom the dome as desired for the

Pattern.

4. Execute the keyboard’s Pattern save

command to save the Pattern.

Running 16 Patterns

When a dome is configured for 16 Patterns,

running a Pattern requires displaying the Pattern

Select screen (Figure 23). Follow the steps below

to run a Pattern.

1. Enter the appropriate keyboard command to

run Patterns 1, 2, or 3. The Pattern Select

screen appears.

2. Move the joystick to highlight the desired

Pattern number (1-16) to run.

3. Press Focus Far to select. The Pattern Select

screen disappears and the Pattern runs.

SensorNet, RS-422,

Manchester, and UTC

Controllers and Switchers

The following provides information about

SensorNet, RS-422, Manchester, and UTC

protocols on SpeedDome Ultra VIIE compatible

controllers.

VM8

Supported Protocol SensorNet

Maximum Presets 0

Maximum Patterns11

DirectSet Menu Not supported

Address Range 1-8

Notes:

(1) Apple Peel only. Programmable Patterns are not

available.

VM16/ADTT16 (White Touch

Tracker)

Supported Protocol SensorNet

RS-4221

Maximum Presets 96 – SensorNet

4 – RS-422

Maximum Patterns216

DirectSet Menu Not supported

Address Range 1-16

Notes:

(1) Requires RCSN422 code converter.

(2) Patterns are limited by time and the number of

available dome commands.

PATTERN SELECT

1 5 9 13

1 6 10 14

3 7 11 15

4 8 12 16

EXIT

Altri manuali per SpeedDome Ultra VIIE

Indice

Altri manuali American Dynamics Telecamera di sicurezza

American Dynamics

American Dynamics DeltaDome II Istruzioni per l'installazione e il funzionamento

American Dynamics

American Dynamics ADC722WP Manuale utente

American Dynamics

American Dynamics AD615 Manuale utente

American Dynamics

American Dynamics AD715LS Series Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics Illustra 1MP Manuale utente

American Dynamics

American Dynamics ADCDH Manuale utente

American Dynamics

American Dynamics illustra 600 Manuale utente

American Dynamics

American Dynamics SpeedDome Ultra VII EIS Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics SpeedDome Ultra 8 35x Manuale utente

American Dynamics

American Dynamics Illustra Flex Series Manuale utente

American Dynamics

American Dynamics ADC860 Manuale utente

American Dynamics

American Dynamics ADC721B Manuale utente

American Dynamics

American Dynamics SensorRail IIIe ADRL3TRK Series Manuale utente

American Dynamics

American Dynamics ADC722WP Manuale utente

American Dynamics

American Dynamics ADCA330 Manuale utente

American Dynamics

American Dynamics SpeedDome Ultra VIIE Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics Illustra 625 PTZ Manuale utente

American Dynamics

American Dynamics ADC700 Manuale utente

American Dynamics

American Dynamics SpeedDome RHODULP-01 Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics AD615 Manuale utente

American Dynamics

American Dynamics IP speedDome Ultra 8 Istruzioni di installazione e manutenzione

American Dynamics

American Dynamics RASO series Manuale utente

American Dynamics

American Dynamics illustra 600 Manuale utente

American Dynamics

American Dynamics SpeedDome Optima LT Manuale utente

Manuali Telecamera di sicurezza popolari di altre marche

Okina USA

Okina USA SIR36-870VF650LP Manuale utente

Divio

Divio NDR155PA Manuale utente

Canon

Canon VB-C500D Manuale utente

Easy Access

Easy Access EasyGuard Manuale utente

Vivotek

Vivotek FD9389-EHV-v2 Manuale utente

TUYA

TUYA COSMO W2 Manuale utente

Eusso

Eusso UNC7500-IR Guida all'installazione

urmet domus

urmet domus 1096/204 Manuale utente

VC VC20 series Manuale utente

Axis

Axis Q1614 Manuale utente

ieGeek

ieGeek DD201 Manuale utente

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Manuale utente

Vicon

Vicon V662-D-1 Istruzioni operative

Grundig

Grundig GCH-K0274P Manuale utente

Lorex

Lorex VANTAGE LBC7032 Manuale utente

4xem

4xem WPT Manuale utente

Samsung

Samsung SCV-3082 Manuale utente

Vitek

Vitek VTC-C544 Manuale utente
