AT&T CL80111 Manuale utente

User’s manual

CL80111

DECT 6.0 expansion handset

for use with AT&T models

CL83101/CL83201/CL83301/

CL83351/CL83401/CL83451

Congratulations

on your purchase of this AT&T product. Before using this AT&T

product, please read the Important safety information section on

pages 19-21 of this manual. For complete instructions, please

refer to the manual provided with your CL83101/CL83201/

CL83301/CL83351/CL83401/CL83451 telephone. You can also

visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

Model number: CL80111

Type: DECT 6.0 expansion handset

Serial number: ________________________________________________

Purchase date: ________________________________________________

Place of purchase: _______________________________________________

Both the model and serial numbers of your AT&T product can be

found on the bottom of the charger.

Save your sales receipt and original packaging in case it is

necessary to return your telephone for warranty service.

Telephones identified with this logo have reduced noise and

interference when used with most T-coil equipped hearing aids and

cochlear implants. The TIA-1083 Compliant Logo is a trademark of

the Telecommunications Industry Association. Used under license.

the AT&T logo are trademarks of AT&T Intellectual Property licensed to

Advanced American Telephones, San Antonio, TX 78219. Printed in China.

The ENERGY STAR® program (www.energystar.gov) recognizes and

encourages the use of products that save energy and help protect

our environment. We are proud to mark this product with the

ENERGY STAR® label indicating it meets the latest energy

efficiency guidelines.

Compatible with

Hearing Aid T-Coil

TIA-1083

Parts checklist

Your telephone package contains the following items. Save your

sales receipt and original packaging in the event warranty service

is necessary.

Battery for

cordless handset

Cordless handset Charger for cordless

handset with power

adapter installed

Battery

compartment

cover

User’s manual

CL80111

DECT 6.0 expansion handset

for use with AT&T models

CL83101/CL83201/CL83301/

CL83351/CL83401/CL83451

BY 1021

BT183342/BT283342

2.4V 400mAh Ni-MH

User’s manual

CL80111

DECT 6.0 expansion handset

for use with AT&T models

CL83101/CL83201/CL83301/

CL83351/CL83401/CL83451

Table of contents

Getting started

Installation...................................................................................................................1

Quick reference guide - handset......................................................................2

Charger installation.................................................................................................5

Battery installation and charging.....................................................................6

Registration and deregistration

Adding and registering handsets .....................................................................8

Deregistering handsets .........................................................................................9

Deregister all handsets from your telephone base ............................9

Appendix

Troubleshooting .....................................................................................................10

Maintenance.............................................................................................................18

Important safety information ..........................................................................19

Safety information.............................................................................................19

Especially about cordless telephones.....................................................20

Precautions for users of implanted cardiac pacemakers..............21

Pacemaker patients..........................................................................................21

Especially about telephone answering systems................................21

FCC Part 68 and ACTA........................................................................................22

FCC Part 15..............................................................................................................24

Limited warranty....................................................................................................25

Technical specifications .....................................................................................28

DECT 6.0 digital technology.........................................................................28

Telephone operating range..........................................................................28

Redefining long range coverage and clarity........................................28

HD audio................................................................................................................28

See pages 6-7

for easy instructions.

You must install and

charge the battery before

using the telephone. STOP!

Installation

Your product may be shipped with a protective sticker covering the

handset display - remove it before use.

For customer service or product information, visit our website at

www.telephones.att.com or call 1 (800) 222-3111.

In Canada, dial 1 (866) 288-4268.

Avoid placing the telephone base too close to:

Communication devices such as television sets, VCRs, or other

cordless telephones.

Excessive heat sources.

Noise sources such as a window with traffic outside, motors,

microwave ovens, refrigerators, or fluorescent lighting.

Excessive dust sources such as a workshop or garage.

Excessive moisture.

Extremely low temperature.

Mechanical vibration or shock such as on top of a washing

machine or workbench.

•

Getting started

Quick reference guide - handset

CHARGE indicator

On when the handset is charging in the

telephone base or charger.

/SPEA�ERSPEA�ER

Press to make or answer a call using the

speakerphone.

Press to switch between the speakerphone and

the handset.

Getting started

TONE

Press to switch to tone dialing temporarily

during a call if you have pulse service.

REDIAL/PAUSE

Press repeatedly to view the last 10 numbers

dialed.

While entering numbers, press and hold to insert

a dialing pause.

MUTE/DELETE

During a call, press to mute the microphone.

When the handset is ringing, press to mute the

ringer temporarily.

While reviewing the caller ID history, the

directory or the redial memory, press to delete

an individual entry.

While predialing, press to delete digits.

During message playback, press to delete the

playing message.

PHONE/FLASH

Press to make or answer a call.

During a call, press to answer an incoming call

when you receive a call waiting alert.

During message playback, press to call back the

caller if caller’s number is available.

While reviewing a caller ID log entry, press

repeatedly to add or remove 1 in front of the

telephone number before dialing or saving it in

the directory.

Quick reference guide - handset

Getting started

During an outside call, intercom call, message

or announcement playback, press to change

the audio quality to best suit your hearing.

#(pound key)

Press repeatedly to display other dialing

options when reviewing a caller ID log entry.

OFF/CANCELOFF/CANCEL

During a call, press to hang up.

While in a menu, press to cancel an operation,

back up to the previous menu, or exit the

menu display, or press and hold this button to

exit to idle mode.

When the handset is ringing, press to mute the

ringer temporarily.

Press and hold while the telephone is not in

use to erase the missed call indicator.

MENU/SELECT

When the handset is not in use, press to show

the menu.

While in the menu, press to select an item or

save an entry or setting.

pDIR/VOLUME

Press pDIR to show directory entries when

the handset is not in use.

Press to scroll up while in menus.

While entering names or numbers, press to

move the cursor to the right.

Press to increase the listening volume during a

call or message playback.

qCID/VOLUME

Press qCID to show caller ID history when the

handset is not in use.

Press to scroll down while in menus.

While entering names or numbers, press to

move the cursor to the left.

Press to decrease the listening volume during

a call or message playback.

Quick reference guide - handset

Getting started

The >symbol highlights

a menu item.

Main menu

Play messages

Answering sys

Directory

Caller ID log

Intercom

Ringers

Set date/time

Settings

Website

•

Using menus:

Press MENU/SELECT to show the menu.

Press qCID or pDIR to scroll through menu items.

Press MENU/SELECT to confirm or save changes to a highlighted

menu item.

Press OFF/CANCEL to cancel an operation, back up to the

previous menu, or exit the menu display.

•

PUSH TO TAL�

Press to initiate a one-to-one or one-to-group broadcast.

Press and hold to broadcast to a group of system devices.

For complete instructions, refer to the user’s manual provided with

your CL83101/CL83201/CL83301/CL83351/CL83401/CL83451

telephone system.

If you are unable to find your user’s manual, go to

www.telephones.att.com to read and/or download the manual.

>Play messages

Answering sys

Main menu

IMPORTANT INFORMATION

Use only the power adapter supplied with this product. To order a replacement

power adapter, visit our website at www.telephones.att.com or call

1 (800) 222-3111. In Canada, dial 1 (866) 288-4268.

The power adapter is intended to be correctly oriented in a vertical or floor

mount position. The prongs are not designed to hold the plug in place if it is

plugged into a ceiling, under-the-table or cabinet outlet.

•

Plug the power adapter into an

electrical outlet not controlled by

a wall switch.

Charger installation

Install the charger as shown below.

Getting started

Battery installation and charging

Install the battery as shown on page 7. Once you have installed

the battery, the screen indicates the battery status (see the table

below). If necessary, place the handset in the telephone base or

charger to charge the battery. For best performance, keep the

handset in the telephone base or charger when not in use. The

battery is fully charged after 10 hours of continuous charging. See

the table on page 28 for battery operating times.

If the screen shows Place in charger and flashes, you need to

charge the handset without interruption for at least 30 minutes to

give the handset enough charge to use the telephone for a short

time. The following table summarizes the battery charge indicators

and actions to take.

Getting started

Battery indicators Battery status Action

The screen is blank,

or shows Place in

charger and

(flashing).

Battery has no or

very little charge. The

handset cannot be used.

Charge without interruption

(at least 30 minutes).

The screen shows

Low battery and

(flashing).

Battery has enough

charge to be used for a

short time.

Charge without interruption

(at least 30 minutes).

The screen shows

HANDSET X.

Battery is charged. To keep the battery charged,

place it in the telephone base or

charger when not in use.

NOTE: If you are on a phone call in low battery mode, you hear four short

beeps every minute.

Altri manuali per CL80111

Indice

Manuali Cornetta popolari di altre marche

Swissvoice

Swissvoice ePure HD Manuale utente

Philips

Philips TD6736/BH051P Manuale utente

ASCOM

ASCOM I62 - Manuale utente

LG-Ericsson

LG-Ericsson LIP-9010 Manuale utente

GE 1583 Manuale utente

iiNet

iiNet Handset Manuale utente

ASCOM

ASCOM 9p23 Manuale utente

AirCell

AirCell ST 3100 Manuale utente

Eaton

Eaton HHIR-LCD-PROG Istruzioni per il montaggio

Mitel

Mitel 112 Manuale utente

SBC

SBC SBC-381H Manuale utente

Mitel

Mitel 5602 Manuale utente

ASCOM

ASCOM d81 Messenger Istruzioni per l'installazione

SpectraLink

SpectraLink 7522 Manuale utente

Avaya

Avaya L100 Series Come usare

ooma

ooma HD2 Handset Manuale utente

Yealink

Yealink IPW56 Manuale utente

Sony

Sony SBH52 Manuale utente
