CYP CH-1106TX & RX Manuale utente
CH-1106TX & RX
HDMI v1.3 to CAT6
Transmitter & Receiver
with IR return control
Operation Manual
CH-1106TX & RX
Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2009 by Cypress Technology.
All Rights Reserved.
Version 1.0 October 2009
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
Always follow basic safety precautions to reduce the risk of
re, electrical shock and injury to persons.
To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
Do not attach the power supply cabling to building surfaces.
Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide
ventilation.
Revision History
Version No Date Summary of Change
V1 20091020 Preliminary Release
Table of Contents
1
1
1
1
2
3
4
4
5
6
6
6
7
9
1. Introduction ……………………..……………………...…........….…….
2. Applications …………………..………………….……...................…..
3. Package Contents ………………………...........……….................…
4. System Requirements ……………..……….........………............…….
5. Features …………………………………………......……........…...……
6. Specications ………………………………...……..........………....….
7. Operation Controls and Functions ……………...……..............……
7.1 Front Panel ..............................................................................
7.2 Rear Panel .…………………………………..…….......…...….…
8. Pin Assignment .............................……………..........…......…....…...
8.1 IR Cable Pin Assignment .......................................................
8.2 RJ-45 Pin Denitions ................................................................
10. Connection and Installation ….………………….........…..…..…......
11. Acronyms …......................................................................................
1. Introduction
The HDMI 1.3 transmitter and receiver over CAT6 is the ideal device to send
your HDMI signals over long distances. Instead of using expensive HDMI
cables, your existing CAT6 cables/sockets can replace HDMI cables while
performing the same functions like transferring Deep Color (12 bits/color)
video and lossless compressed (Dolby TrueHD, Dolby Digital Plus and DTS-
HD Master Audio) digital audio. Moreover, you can use the existing remote
to control the source and connect it to another transmitter and receiver to
extend your HDMI signal to distances you never thought possible. This HDMI
1.3 Transmitter and receiver is your only choice when looking for an HDMI
extender.
2. Applications
Showroom display/control
Home entertainment systems
Commercial displays
Lecture room display/control
3. Package Contents
HDMI 1.3 Transmitter x 1
HDMI 1.3 Receiver x 1
IR Eye Receiver cable x 1
IR Eye Blaster cable x 1
5V DC power supply adaptor x 2
Operation Manual x 1
4. System Requirements
HDMI input source equipment, output HDMI displayer, two CAT6 cables and
source equipment’s remote control.
1
5. Features
HDMI 1.3, HDCP 1.1 and DVI 1.0 compliant.
Supports digital video formats in Deep Color Mode at up to 36 bits (12bits/
color) and new lossless compressed (Dolby TrueHD, Dolby Digital Plus
and DTS-HD Master Audio) digital audio .
Supports CAT-6 cables for data/DDC transmission
Equalizes and recovers any incoming TMDS data before re-transmitting it
in flawless quality regardless of the incoming signal.
HDMI cable distance testing showed with 1080p/8bits & 12bits resolution
the Input/Output distance can reach up to 15/15 meters away. With
CAT6 cable, distance test with 1080p/8bits & 12bits resolution the I/O
source can run up to 45/20m away.
Note:
A. Cable tested with CAT-6E /23AWG/Solid, using cables of another type
may result in a different operating distance.
B. Cable distance tested with equipment PS3 40G, 37" Philips 8 bit LCD
TV and 37" SamSung 12 bit LCD TV.
C. Figures provided in this manual are for reference only, actual
gures may depend on the source and display used along with the
type of cable.
Supports CEC bypass and xvYCC
Includes an IR Receiver and Blaster
Supports wide range of IR frequencies from 20~60KHz
Can be connected to another transmitter and receiver to extend an
HDMI signal to an extreme distance
2
6. Specications
Transmitter 1 x HDMI
1 x IR Blaster
1 x CAT-6 Output Video
1 x CAT-6 Output DDC
Receiver 1 x HDMI
1 x Receiver
1 x CAT-6 Input for Video,
1 x CAT-6 Input for DDC
HDMI Input Cable 1080p 8-bit (15M), 12-bit (15M)
HDMI Output Cable 1080p 8-bit (15M), 12-bit (15M)
CAT6 Cable 1080p 8-bit (45M), 12-bit (20M)
Power Supply 5V/1A (US/EU standards, CE/FCC/UL certied)
(US/EU standards, CE/FCC/UL certied)
ESD Protection Human body model: ±8kV (air-gap discharge)
±4kV (contact discharge)
Dimensions (mm) 78.5(W) x 117(D) x 30(H) / Transmitter
78.5(W) x 72(D) x 30(H) / Receiver
Weight(g) 200 / Transmitter
90 / Receiver
Chassis Material Aluminum
Silkscreen Color Silver
Operating Temperature 0˚C ~ 40˚C / 32˚F ~ 104˚F
Storage Temperature -20˚C ~ 60˚C / -4˚F ~ 140˚F
Power Consumption 3.6W/TX, 3.6W/RX
Relative Humidity 20 ~ 90% RH (non-condensing)
3
7. Operation Controls and Functions
7.1 Front Panel
CH-1106TX CH-1106RX
① IR Transmitter: This slot is where you connect the IR blaster cable. Place the
IR eye in front of the source equipment(s) in order to send an IR signal, the
IR blaster has a frequency range from 20KHz to 60KHz.
② HDMI INPUT: This slot is where you connect the HDMI or DVI output port of
your source equipment such as DVD/Blu Ray players or set-top-boxes with
an HDMI cable or receiver unit, you may also connect this device to
another unit from the same family or some other type of splitter to further
extend an HDMI signal.
Example:
③ Power: This slot is where you plug the 5V DC power supply into the unit
and connect the adaptor to an AC outlet.
④ HDMI OUTPUT: This slot is where you connect the HDMI or DVI input port of
your display such as HDTV’s or HD monitors or you can connect this device
to another unit from the same family or some other type of splitter to
further extend an HDMI signal.
① ② ③
POWER 5V
HDMI INPUT
IR
Transmitter
④ ⑤
POWER 5V IR
Receiver
HDMI OUTPUT
DVD
Player
HDMI
Cable
HDMI
Cable
CAT6
VIDEO
DDC
CAT6
CH-1106TX CH-1106RX CLUX-22HC
CLUX-1H4CAT
CLUX-1H8CAT
HDMI
HDMI
HDMI
HDMI
HDMI
Cable
CAT6
VIDEO
DDC
CAT6 HDMI LCD TV
HDMI LCD TV
CH-1106TX CH-1106RX
HDMI
HDMI
HDMI
Cable
or
CAT6
VIDEO
DDC
CAT6
HDMI
HDMI
4
Example:
⑤ IR Receiver: This slot is where you connect the IR receiver cable and
place the IR eye in front of the display then use the existing remote
controls to control input source equipment(s). The IR receiver accepts the
frequency range from 20KHz to 60KHz.
7.2 Rear Panel
CH-1106TX CH-1106RX
①DDC input/output: Connect the DDC output of transmitter to the DDC
input of the receiver unit using a CAT-6 cable.
②Video input/output: Connect the video output of the transmitter to the
video input of the receiver unit using a CAT-6 cable.
① ②
DDC VIDEO
CAT6 OUTPUT
①②
VIDEO DDC
CAT6 INPUT
DVD
Player
HDMI
Cable
HDMI
Cable
HDMI
Cable
CAT6
VIDEO
CAT6
VIDEO
DDC
CAT6
DDC
CAT6 HDMI LCD TV
CH-1106TX
CH-1106TX
CH-1106RX
CH-1106RX
HDMI
HDMI
HDMI
HDMI
HDMI
HDMI
5
