Fein ASCD 12-150 W4 Guida all'installazione

ASCD 12-150 W4; ASCD 12-150 W8

Repair instructions

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 1of 24

ASCD 12-150 W4; ASCD 12-150 W8

Contents

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 2of 24

1. Models described

2. Technical data

3. Notes and requirements

4. Tools required

5. Lubricants and auxiliary substances required

6. Removal

7. Fitting

8. Troubleshooting

9. Connection diagram

ASCD 12-150 W4; ASCD 12-150 W8

1. Models described

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 3of 24

These repair instructions describe how to repair the following models:

Model Order number

ASCD 12-150 W4 7 115 05 .. .. .

ASCD 12-150 W8 7 115 04 .. .. .

ASCD 12-150 W4; ASCD 12-150 W8

2. Technical data

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 4of 24

Technical data

All the technical data can be found in the operating instructions for the model.

Tests

Up-to-date test data and test instructions after repair can be found on the FEIN Extranet (Customer Service → Repair Guides).

Lubricants / Auxiliary substances

The lubricants or auxiliary substances and their container sizes available from FEIN can be found on the FEIN Extranet

(Customer Service → Repair Guides).

Lists of spare parts

Lists of spare parts and exploded views are available online at www.fein.com

ASCD 12-150 W4; ASCD 12-150 W8

3. Notes and requirements

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 5of 24

Please note

These instructions are only intended for persons with suitable technical training. It is assumed that the reader has mechanical and

electrical training.

Only use original FEIN spare parts.

Provisions

Please note that power tools may only be repaired, maintained and checked by a trained electrician, as improper repair can result in

serious risks to the user.

The provisions set out in DIN VDE 0701-0702 should be observed after repairs.

The relevant accident prevention regulations of the employer’s liability insurance associations are to be observed when

commissioning.

The German Equipment and Product Safety Act [ProdSG] applies for correct use.

Outside Germany, the regulations applicable in the relevant country must be observed.

ASCD 12-150 W4; ASCD 12-150 W8

4. Tools required

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 6of 24

Standard tools Special tools

Circlip pliers Assembly aid 6 41 22 125 01 0

Slotted screwdriver Extractor tool 6 41 14 037 00 0

Blade

Vice

Torx T10; T15

Side-cutting pliers

Soldering station

Arbor press

Punch Dia. 3 mm; dia. 4 mm

Hacksaw

Sleeve 6 mm inner diameter

20 mm outer diameter

ASCD 12-150 W4; ASCD 12-150 W8

5. Lubricants and auxiliary substances required

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 7of 24

Lubricants

Klübersynth GE 14-151 0,5 g Gearbox

ASCD 12-150 W4; ASCD 12-150 W8

6. Removal

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 8of 24

Removing the sleeve [applies to: ASCD 12-150 W4]

1. Remove the circlip (1).

2. Remove the disc (2).

3. Remove the spiral spring (3).

4. Remove the sleeve (4).

5. Remove the ball (5).

Tools:

- Circlip pliers

- Slotted screwdriver

- Magnet

ASCD 12-150 W4; ASCD 12-150 W8

6. Removal

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 9of 24

Removing the motor housing

1. Cut through the type plate.

2. Remove the circlip (1).

3. Unscrew the four screws (2).

4. Remove the gearbox housing (3).

5. Unscrew the nine screws (4).

6. Remove the motor housing (5).

7. Remove the pressure piece (6).

Tools:

- Blade

- Torx T10

ASCD 12-150 W4; ASCD 12-150 W8

6. Removal

C-SC_CSSM

Version 1.0

2018-06-13

FEIN retains all rights of disposal, such as copying and circulation.

Page 10 of 24

Removing the motor housing

1. Remove the nut (1).

1. Remove all components from the motor housing.

2. Pull off the gearbox (2).

3. Pull off the speed setting switch (3).

4. Remove the insulating ring (4).

5. Pull out the rotor (5).
