Intermec EasyCoder PF2i Manuale utente

Installation

Instructions

CPU Board

for EasyCoder

PF2/4i, PX4/6i &

PM4i

2 CPU Board—Installation Instructions

Before starting to replace the CPU board, take precautions

against electrostatic discharges.

All EasyCoder PF2/4i, PX4/6i and PM4i printers

Replace the CPU board this way:

• Switch oﬀ the power.

• Remove the front/left-hand cover.

• Remove any optional interface boards.

• Disconnect all cables from the CPU board.

• Remove the four #T20 Torx screws and the hexagonal spacer that hold

the CPU board to the plate that covers the power supply unit.

• Lift out the CPU board and remove all SIMMs and any real time

clock.

• Fit the SIMMs and possibly the real-time clock on the new board and

install it in reverse order.

Note: Refer to the Service Manual of each respective printer for

illustrations and instructions.

CPU Board—Installation Instructions 3

EasyCoder PM4i and PX4/6i printers only

e same CPU-board can be used for a range of EasyCoder printers.

However, the ﬁrmware cannot detect in which type of printer the CPU

board is installed. All replacement CPU boards are preprogrammed for

the EasyCoder PF2/4i-series printers, which means that replacement

CPU boards must always be reconﬁgured after being installed in an Easy-

Coder PM4i or PX4/6i printer.

If the printer feeds out labels in a peculiar way, the CPU board may be

conﬁgured for the wrong type of printer (there is a diﬀerence in the dis-

tance between the dot line and the LSS position).

You can easily check if the CPU board is correctly conﬁgured by printing

the “Hardware Info” or “HW” test label in the Setup Mode or sending

the Fingerprint instruction PRINT VERSION$(1).

If the CPU board needs to be reconﬁgured, do the following:

• Switch oﬀ the power.

• Insert a conﬁguration card in the memory card slot. Conﬁguration

cards can be ordered from Intermec via your local service organiza-

tion. Alternatively, the conﬁguration ﬁle (TYPESET.PRG) can be

downloaded from the Intermec Global Sales & Service website and

transferred to a CompactFlash memory card which is then utilized in

the same manner.

• Switch on the power.

• Select the correct printer type from the menus shown in the display

window.

• Switch oﬀ the power.

• Remove the card.

• Switch on the power again and check.

Intermec Technologies Corporation

Corporate Headquarters

6001 36th Avenue West

Everett, WA 98203

tel 425.348.2600

fax 425.355.9551

www.intermec.com
