Rexing V33 Plus Manuale utente
V33 Plus
Quick Start Guide
The information in this manual is subject to change without notice.
Rexing All Rights Reserved
www.rexingusa.com
1
Facebook Instagram Site
Overview
Thank you for choosing REXING! We hope you love your new
product as much as we do. If you need assistance, or have any
suggestions to improve it, please contact us. You can reach us
via [email protected] or call us at (877) 740-8004. Our
support team will respond you as soon as possible.
Always a surprise in Rexing. Check us out here.
https://www.facebook.com/rexingusa/
https://www.instagram.com/rexingdashcam/
https://www.rexingusa.com/support/registration/
2
1. What’s in the Box
1. V33 Plus Quick Start Guide
2. Safety Guide
3. 3M Adhesive Mount
4. Cable Adhesive Spacer
5. Cable Management Tool
6. Rexing V33 Plus Dash Cam
7. 64GB Micro SD Card
8. Car Power Connector (12ft)
9. V33 Plus Rear Camera with Extension Cable (22ft)
8.
1. 2. 3.4.
5.
6.
1. Overview
9.
7.
3
2. Camera Overview
1. 4 IR Lights
2. Power Button / Screen Toggle Button
3. Menu Button / Playback Button
4. Up Button / Mode Button / Wi-Fi Button
5. Down Button / Mic Button
6. OK (Confirm) Button / Video Lock Button / Record Button
7. Micro SD Card Slot
8. Power / USB Charging Port
9. Reset Pinhole
10. Rear Camera Port
7.
2. 4. 5.3. 6.
9.10. 8.
1.
The camera is recording
when the LED is flashing
red. The device is charging
or powered on when the
LED is solid red.
4
Screen Icons
G Sensor Level
Recording (on)
Wi-Fi
(Not Connected)
Wi-Fi (Connected)
Time (24h)MIC (on)
MIC (mute)
Current Date
(DD/MM/YYYY)
Loop Recording
Time
Video Resolution
GPS Signal
(Searching)
IR Lights
Battery Charging
Memory Card
(Inserted)
Memory Card
Remaining Time
Recording Time
(current clip)
Current clip
(Locked)
Recording
Standby Status
WDR Mode (on)
Exposure Value
QHD+QHD+QHD
QHD+QHD+QHD
3. Installation
Step 1: Install the Dash Camera
Place the 3M tape on the mount and properly orient the mount
square to the roof and hood line of the vehicle.
Firmly press the mount onto the windshield. Wait at least 20
minutes before mounting the camera. Orient the mount as
shown on the illustration below.
Orient the
mount as shown
Step 2: Insert the memory card
The Rexing V33 Plus accepts Class 10/UHS-3 or higher Micro
SD memory cards up to 256GB. You will need to insert a
memory card before begin recording. Before inserting or
removing a memory card, first ensure you’ve powered
down the device. Gently push the memory card in until you
hear a click, and allow the spring release to push the card out.
5
Press the OK
button to confirm
formatting the
card
Press the Menu button twice
and toggle down to Format
Step 3: Power on the Camera and Format the
Memory Card
Power the camera by connecting the charger to the car cigarette
lighter and camera. To ensure the V33 Plus records to your
memory card properly and without error. Before you start
using a new memory card, you MUST format the card
within the camera using the format function. Always backup
important data stored on the memory card before formatting.
To format the memory card, make sure you have inserted your
memory card, then turn on the device by connecting to a power
source. Press OK to stop recording. Then press the MENU
button twice to enter the System Setup Menu.
6
Use the UP and DOWN navigation buttons and go to the
Format setting. Press the OK button to confirm the selection.
You may now disconnect from power. The camera will shut
down after 3 seconds. The camera should begin recording
automatically the next time it is powered on.
Step 4: Mount the Rear Camera
Mount the rear camera as shown below. Use rear camera cable
to connect the rear camera to the V33 Plus camera.
front
cabin
rear
7
8
Step 5: Installing the Camera onto the Windshield
Place the camera on the mount and carefully route the power
cable around the windscreen and tuck in under the trim.
Plug the Car Charger Cable into a 12V DC power outlet or the
car cigarette lighter. Connect car charger to the camera. The
camera will auto-start recording once powered on.
Connect the
power cable to
the dash cam
Plug Mini-USB
connector to the
dash cam
Plug charger into
power outlet or
cigarette lighter
Rear Camera
9
Menu Settings
Power on the camera. If the camera is recording, press the OK
button to stop recording.
Hold the MENU button and toggle to the desired mode.
Press the MENU button once to enter the Video Settings.
Press the MENU button twice to enter the Setup Settings.
4. Basic Operation
Device Power
The device will be automatically powered on when plugged
into a 12V accessory socket or cigarette lighter when receives a
charge (i.e. the vehicle is started).
To turn the device on manually, press and hold the Power
button until the welcome screen appears.
The camera will automatically start recording when it’s powered
on.
Press and hold the Power button to turn the device on manually
Exposure
