SIIG ExpressCard 11-in-1 Reader/Writer Manuale utente

ExpressCard 11-in-1

Reader/Writer

Quick Installation Guide

Features and Benefits

•Compatible with SD, mini SD, MMC, RS-MMC,

Memory Stick, Memory Stick Duo (incl. PRO and

MagicGate), Memory Stick PRO, MagicGate

Memory Stick and xD Picture Card memory cards

Note: The copyright protection feature of Magic

Gate is not supported. However, Memory Stick

read/write function is supported.

•Hot-swapping feature allows you to attach/detach

this reader/writer without powering down your

system

•Compliant with USB Storage Class specifications –

no driver installation required!

Serial # Sticker

For future product return or exchange, this serial # is

required. Please keep it for your reference.

04-0420A

System Requirements

•Notebook or desktop computer with an available

ExpressCard slot

•Windows 2000/XP/Server 2003

Package Contents

•ExpressCard 11-in-1 Reader/Writer

•This quick installation guide

Layout

Figure 1. ExpressCard 11-in-1 Reader/Writer

Installation

Hardware Installation

General instructions for installing the ExpressCard

11-in-1Reader/Writerareprovidedbelow. Sincethedesign

ofcomputersvary,refertoyoursystem’sreferencemanual

for further information, if needed.

1. Insert the ExpressCard 11-in-1 Reader/Writer into the

ExpressCard slot of the computer with it's Express

Card Connector facing the slot. Push the card into

the slot gently, yet firmly for a solid connection.

ExpressCard

Connector

Memory

Card Slot

Note: SomeExpressCard slots willclick when the

ExpressCard is fully inserted into the slot.

2. If your system was powered off when you plugged

in the ExpressCard, turn it on and go to Driver

Installationon page 3. Otherwise, go directly to

Driver Installationon page 3.

Driver Installation

Windows2000,XPandServer2003automaticallydetects

and installs the correct driver for theExpressCard 11-in-1

Reader/Writer. No driver installation is needed.

Verify 2000/XP/2003 Installation

1. Right click My Computer, click Manage, then click

Device Manager.

2. Click on the +(plus sign) in front of Disk Drives,

Generic STORAGE DEVICE USB Device should

be displayed.

Using the Reader/Writer

When inserting or removing memory cards, make sure

that theExpressCard11-in-1Reader/Writerdoesnotmove

fromsidetosideintheExpressCardslot,otherwiseitmay

accidentaly eject from the slot.

Inserting Memory Cards

For all memory cards, insert with the gold pins forward

andfacingdown. Pushthememorycardintotheslotuntil

youhearoffeelaclickthenrelease. Thememorycardwill

retract slightly upon release.

Removing Memory Cards

Memory cards can be removed at any time. Push in on

the memory card, when you hear or feel a click, release

pressure and pull the memory card out.

Accessing Memory Cards

When the reader/writer is successfully installed, a

Removable Disk icon will appear in My Computer. To

access the memory card, double click the disk icon.

Removing the ExpressCard

BeforeejectingtheExpressCard11-in-1Reader/Writerfrom

the ExpressCard slot, first use the Safely Remove

Hardwareutilitytostopit. Notfollowingthestepsbelow

couldleadtosystemcrashes,datacorruptionordataloss.

Follow the steps below for your version of Windows.

For Windows 2000

1. Click the Unplug or Eject Hardware icon located in

the taskbar by the system clock.

2. Click Stop USB Mass StorageDevice.....

3. At the Safe To Remove Hardware box, click OK.

The ExpressCard 11-in-1 Reader/Writer can be ejected.

For Windows XP/Server 2003

1. Click the Safely Remove Hardware icon located in

the taskbar by the system clock.

2. Click Safely remove USB Mass Storage Device.....

3. When Safe to Remove Hardware box pops up, the

ExpressCard 11-in-1 Reader/Writer can be ejected.

Blank Page

Technical Support and Warranty

QUESTIONS? SIIG’sOnline Support has answers! Simply visit our website

at www.siig.com and click onSupport. Ouronlinesupportdatabaseisupdated

dailywith newdriversand solutions. Answerstoyour questions couldbe just

a few clicks away. You can also submit questions online and a technical

support analysts will promptly respond.

A 5-year manufacturer warranty supplied with this product is

offered by SIIG, Inc. Please see SIIG website for more warranty

details. If you should happen to encounter any problems with this product,

please follow the procedures below.

If it is within the store's return policy period, please return the

producttothe storewhereyoupurchasedfrom. Ifyour purchasehaspassedthe

store's return policy period, please follow these steps to have the product

repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Support, then RMA to submit a

request to SIIG RMA. If the product is determined to be

defective,anRMA number will be issued. SIIG RMAdepartment canalso

be reached at (510) 413-5333.

Step 2: After obtaining an RMA number, ship the product.

•Properly pack the product for shipping. All accessories that came

with the original package must be included.

•Clearly write your RMA number on the top of the returned package.

SIIG will refuse to accept any shipping package, and will not be

responsibleforaproductreturnedwithoutanRMAnumberpostedon

the outside of the shipping carton.

•You are responsible for the cost of shipping the product to SIIG at the

following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538

RMA #: ________________

•SIIG will ship the repaired or replaced product via Ground

in the U.S. and International Economy outside of the U.S. at

no cost to the customer.

About SIIG, Inc.

Founded in 1985, SIIG, Inc. is a leading computer upgrade manufacturer of

I/O connectivity products, including PCI & ISA serial and parallel ports,

USB,SerialATA&UltraATAcontrollers,FireWire(1394a/b),Networking,

Sound Cards, and other accessories. SIIG is the premier one-stop source of

upgrades.

SIIG products offer comprehensive user manuals, many user-friendly

features, and are backed by an extensive manufacturer warranty. High-

qualitycontrol standards are evidentbythe overall easeof installationand

compatibility of our products, as well as one of the lowest defective return

rates in the industry. SIIG products can be found in computer retail stores,

mail order catalogs, and e-commerce sites in the Americas and the UK, as

well as through major distributors, system integrators, and VARs.

ExpressCard 11-in-1 Reader/Writer is a trademark of SIIG, Inc. SIIG and SIIG logo are

registered trademarks of SIIG, Inc. Other names used in this publication are for

identification only and may be trademarks of their respective companies.

PRODUCT NAME

ExpressCard 11-in-1 Reader/Writer

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B

OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE

FCC COMPLIANCE STATEMENT:

This device complies with part 15 of the FCC Rules. Operation is

subjecttothefollowingtwoconditions: (1)Thisdevicemaynotcause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

SIIG, Inc.

6078 Stewart Ave.

Fremont, CA 94538-3152
