USB3.0Single ExpressCard/34

Quick Installation Guide

Introduction

The USB 3.0 Single ExpressCard/34 adds a USB

3.0porttoyourExpressCard-equippedcomputer,

enhancing existing systems with the latest USB

3.0 technology.

Key Features and Benefits

• Compliant with Universal Serial Bus 3.0

Specification, Revision 1.0

• Compliant with PCI Express Base

Specification, Revision 2.0

• Supports data transfer rate up to 5Gb/s

and backward compatible with previous

versions of USB devices

Serial Number Sticker

For future product return or exchange, this serial

number is required. Please keep it for your

reference.

Figure 1: Layout

System Requirements

• Notebook or desktop PC with an available

ExpressCard slot

• Windows®7 (32-/64-bit) / Vista (32-/64-

bit) / XP (32-/64-bit)

Package Contents

•USB 3.0 Single ExpressCard/34 adapter

• USB power cable

• Driver CD

• Quick installation guide

Layout

ExpressCard connector

USB 3.0 port

Power adapter jack (optional)

USB Power Cable Installation (optional)

The USB Power Cable is only needed when the

ExpressCard doesn't provide enough power to

power up your USB device. Self powered USB

devices do not need this optional power cable to

work.

1. Unplug the USB device from the

ExpressCard.

2. Remove the USB 3.0 Single ExpressCard/34

adapter from the ExpressCard slot.

3. Connect the USB Power Cable to the

ExpressCard.

4. Plug the other end of the cable into any USB

port of the computer.

5. Insert the USB 3.0 Single ExpressCard/34

into the ExpressCard slot of your computer.

6. Plug in your USB device into the

ExpressCard.

Installation

Please make sure the ExpressCard is installed

before proceeding with driver installation.

Windows 7 (32-/64-bit) / Vista (32-/64-bit)

1. At the Windows desktop.

For Windows 7: Go directly to step 2.

For Windows Vista: At the Found New

Hardware window, click Cancel.

2. Insert the driver CD.

For Windows 7: At the AutoPlay box, click

Open folder to view files, then double

click Setup.

For Windows Vista: At the CD Autoplay

window, double click Setup.

3. At User Account Control.

For Windows 7: Click Yes.

For Windows Vista: Click Continue.

4. At Welcome, click Next.

5. Select I accept the terms of the license

agreement, click Next.

6. At Ready to Install the Program, click

Install.

7. Wait while the InstallShield Wizard

configures your system. Depending on

your system hardware this process may

take several minutes to complete.

8. At InstallShield Wizard Complete, click

Finish.

Windows XP (32-/64-bit)

1. At the Found New Hardware Wizard, click

Cancel.

2. Insert the driver CD. Click Start, Run. Type

D:\Setup.exe, click OK. (Change D: to

match your CD\DVD-ROM drive letter)

3. At Welcome, click Next.

4. Select I accept the terms of the license

agreement, click Next.

5. At Ready to Install the Program, click

Install.

6. Wait while the InstallShield Wizard

configures your system. Depending on

your system hardware this process may

take several minutes to complete.

7. At InstallShield Wizard Complete, click

Finish.

To Verify Successful Installation

1. Go to Device Manager to verify installation.

For Windows 7: Right click Computer,

click Manage, click Device Manager.

For Windows Vista: Right click Computer,

click Manage, click Continue, then click

Device Manager.

For Windows XP: Right click My Computer,

click Manage, click Device Manager.

2. Double click Universal Serial Bus

controllers. A Renesas Electronics USB

3.0 Host Controller and a Renesas

Electronics USB 3.0 Root Hub should be

displayed.

Technical Support and Warranty

QUESTIONS? SIIG’s Online Support has answers! Simply visit our web site at

www.siig.com and click Support. Our online support database is updated daily with

new drivers and solutions. Answers to your questions could be just a few clicks away.

You can also submit questions online and a technical support analysts will promptly

respond.

SIIG offers a lifetime manufacturer warranty with this product. This warranty covers

the original purchaser and guarantees the product to be free of any defects in materials

or workmanship for the life of the product.

SIIG will, at our discretion, repair or replace (with an identical product or product

having similar features and functionality) the product if defective in materials or

workmanship. This warranty gives you specific legal rights, and you may also have other

rights which vary from state to state. Please see our web site for more warranty details.

If you encounter any problems with this product, please follow the procedures below.

A) If it is within the store's return policy period, please return the product to the store

where you purchased from.

B) If your purchase has passed the store's return policy period, please follow the steps

below to have the product repaired or replaced.

Step 1: Submit your RMA request.

Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA or

fax a request to 510-657-5962. Your RMA request will be processed, if the product

is determined to be defective, an RMA number will be issued.

Step 2: After obtaining an RMA number, ship the product.

• Properly pack the product for shipping. All accessories that came with the

original package must be included.

• Clearly write your RMA number on the top of the returned package. SIIG will

refuse to accept any shipping package, and will not be responsible for a product

returned without an RMA number posted on the outside of the shipping

carton.

• You are responsible for the cost of shipping to SIIG. Ship the product to the

following address:

SIIG, Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

RMA #:

• SIIG will ship the repaired or replaced product via Ground in the U.S. and

International Economy outside of the U.S. at no cost to the customer.

PRODUCTNAME

USB 3.0 Single ExpressCard/34

FCC RULES: TESTED TO COMPLY WITH FCC PART 15, CLASS B

OPERATING ENVIRONMENT: FOR HOME OR OFFICE USE

FCCCOMPLIANCESTATEMENT:

This device complies with part 15 of the FCC Rules. Operation is subject

to the following two conditions: (1) This device may not cause harmful

interference, and (2) this device must accept any interference received,

including interference that may cause undesired operation.

THE PARTY RESPONSIBLE FOR PRODUCT COMPLIANCE

SIIG,Inc.

6078 Stewart Avenue

Fremont, CA 94538-3152, USA

Phone: 510-657-8688

USB 3.0 Single ExpressCard/34 is a trademark of SIIG, Inc. SIIG and the SIIG logo are

registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of

MicrosoftCorporation. All other names used in thispublication are foridentification only and

may be trademarks of their respective owners.

About SIIG, Inc.

Founded in 1985, SIIG, Inc. is a leading manufacturer of IT connectivity

solutions (including Serial ATA and Ultra ATA Controllers, FireWire, USB,

and legacy I/O adapters) that bridge the connection between Desktop/

Notebooksystemsand external peripherals. SIIGcontinues to growbyadding

A/V and Digital Signage connectivity solutions to our extensive portfolio.

SIIGproductsoffercomprehensiveuser manuals,manyuser-friendlyfeatures,

and are backed by an extensive manufacturer warranty. High quality control

standards are evident by the overall ease of installation and compatibility of

our products, as well as one of the lowest defective return rates in the industry.

SIIG products can be found in computer retail stores, mail order catalogs,

throughmajordistributors, system integrators,andVARs in theAmericasand

the UK, and through e-commerce sites.
