Soundcore Rave Plus Manuale utente

Soundcore Rave+

USER MANUAL

English 01

Čeština 09

Dansk 17

Deutsch 25

Español 33

Suomi 41

Français 49

Italiano 57

Nederlands 65

Norsk 73

Język polski 81

Portugues do Brasil 89

Pусский 97

Slovenský Jazyk 105

Türkçe 113

日本語 121

한국어 129

简体中文 138

繁體中文 146

ةيِبَ

رَعل 154

תי ִ

רבִע164

1 Charging

1.1 Charging Your Speaker

Use the included AC power cord to charge your speaker.

Battery level <25%

Battery level 25% - 50%

Battery level 51% - 75%

Battery level 76% - 95%

Battery level >95%

● Fully charge this speaker before the first use to prolong the lifespan of the built-in battery.

● Disconnect your speaker from the power supply when fully charged. Do not charge for

extended periods.

1.2 Checking Battery Level

Battery level <15%

Battery level 15% - 25%

Battery level 26% - 50%

Battery level 51% - 75%

Battery level 76% - 100%

1.3 Charging Your USB Devices

Charge your mobile device through the Power IQ port on the back of this speaker.

2 Powering On/Off

Press and hold for 2 seconds

Power on

Steady white

Press and hold for 2 seconds

Power off

Light off

● Unplug the power cable from the AC mains outlet when not in use for an extended period of

time.

● This speaker will power off automatically after 30 minutes if there is no audio input.

3 Using Your Speaker

3.1 Bluetooth Pairing

With this speaker, you can enjoy music through your Bluetooth-enabled devices.

Press

Enter Bluetooth pairing mode

Flashing blue

Bluetooth pairing

Steady blue

Bluetooth connected

● Each time you power on your Soundcore speaker, it will automatically connect to your last

connected device if available within the Bluetooth range. If not, press the Bluetooth button to

enter Bluetooth pairing mode.

3.2 PartyCast Mode

You can wirelessly connect up to 100 Soundcore Rave+ speakers or Soundcore speakers with

PartyCast functions together.

1. Press and hold the Bluetooth button for 2 seconds on the Soundcore Rave+ that’s currently

connected to your device as the primary speaker.

2. Repeat Step 1 on the other Soundcore Rave+ speakers you want to connect and then press the

Bluetooth button twice to make them secondary speakers in PartyCast pairing.

→ The secondary speakers will automatically connect with the primary speaker.

Press and hold for 2 seconds

Enter PartyCast mode

Slowly flashing white (Primary speaker)

PartyCast pairing

Rapidly flashing white (Secondary speaker)

Slowly flashing white (Primary speaker)

PartyCast connected

Steady white (Secondary speakers)

When PartyCast mode is successfully entered:

● You can power off, adjust the volume, or switch light modes for all speakers by controlling the

primary speaker only.

● You can power off or switch light modes for each secondary speaker individually.

● You can't adjust the volume for each secondary speaker individually.

● Any secondary speaker can be switched to become the primary speaker by pressing the

Bluetooth button twice and connecting to your smartphone. Any primary speaker can be

switched to become the secondary speaker by pressing the Bluetooth button twice and

searching for an available primary speaker.

● To exit the PartyCast mode, press and hold the Bluetooth button on any speaker for 2

seconds.

3.3 AUX/USB Mode

Plug in an audio cable or insert a USB flash drive, then press the source button to switch between

AUX in mode and USB mode (support FAT32 / MP3 / WMA formats).

Press

Switch source

Press and hold for 2 seconds

Exit AUX/USB mode

Steady green

AUX in mode

Steady white

USB mode

● Audio cable or USB flash drive is not provided.

● When using AUX mode, control audio playback via the connected device.

3.4 Wired Party Mode

You can connect multiple Soundcore Rave+ speakers via RCA cables to form a wired party chain.

Then press the source button to enter the wired party mode.

3.5 Button Controls

Press

Play/Pause

Press

Previous track

Press

Next track

Rotate

Adjust volume

Press

Turn BassUp on/off

3.6 Light Effects

Your speaker is equipped with light effects for a party mood.

When powered on, the light effects are automatically turned on. Press the light effect button to switch

among multiple music-sync light effects.

To turn off the light effects, press and hold the light effect button for 2 seconds.

Press

Switch light effects / Turn light effects on

Press and hold for 2 seconds

Turn light effects off

You can also check all available specific light effects in the Soundcore app.

3.7 Microphone Connection

For the best performance, use the microphone (not provided) when in the wired party chain mode.

Connect the microphone to the MIC port. You can adjust the microphone volume by rotating the MIC

ECHO volume knob.

4 Soundcore App

Download the Soundcore app to enhance your experience.

● Set up Bluetooth connection

● Check product information

● Update firmware

● Indicate battery status

● Customize button controls

● Switch among multiple light effects

● Light DJ mode to support light and sound variation

● Enjoy party games

● Switch BassUp mode

● Switch EQ modes

● Set Auto-power off time

5 Specifications

Specifications are subject to change without notice.

Input

100V-240V AC~, 50/60Hz

Charge out

5 V ⎓2.1 A

Audio output power

160W

Battery capacity

4900 mAh / 7.4 V x 2

Charging time

Appr. 5 hours

Playtime (varies by volume level and music content)

Up to 24 hours

Waterproof level

IPX4

USB audio format

.mp3, .wma

Bluetooth version

V5.0

Bluetooth range

20 m / 66 ft
