FF-MM-300-REV - 00
Page 4
Operation and Maintenance Guide Pneumatic Needle Scalers
• Eye and faceand ear protection must be worn
at all times during operation of the
Pneumatic Needle Scaler. ere is a chance
of ying debris from the jobsite and the
quality of wear should be such to protect
against such ying debris such as akes of
the removed layer.
• Suitable gloves must be worn at all times
during operation.
• Safety Shoes with toe cap protection are a
must during operation.
• Scalers are rugged dependable tools designed
to give you years of satisfactory service.
Follow the instructions mentioned here to
enhance life and performance of your scalers.
Daily Before Operating
Disconnect and pour in 1 to 2 ounces of
recommended oil into the Pneumatic Needle
Scaler and reconnect hose aer blowing out any
accumulated dirt in the hose line before
connection
Lubrication Requirements
Always install a line lubricator on the air line as
close to the Pneumatic Needle Scaler as possible.
A Filter Regulator Lubricator unit (FRL)is
strongly recommended. Keep the lubricator bowl
topped up with recommended grade of oil and
check that the oil is reaching the Pneumatic Nee-
dle Scaler. Running the Pneumatic Needle Scaler
without lubrication is likely to cause damage to
the components causing premature replacement.
Operating Instructions
Warning
is Pneumatic Needle Scaler is not designed
for use in an explosive environment.
Caution
Completely turn o the Pneumatic Needle
Scaler and disconnect air supply line before
attempting any service. Read Assembly and
Disassembly instructions.
Warning
Take care not to exceed the maximum 6 bar
(90 psi) supply air pressure. Use a lter and
regulator and lubricator as close to the Pneu-
matic Needle Scaler inlet as operation will
allow ensuring a clean and regulated and
lubricated air ow.
Caution
Do not exert excessive pressure against the
work surface. Keep hoses in good condition.
Check hoses for signs of wear, cracks & bulges
and ensure that they are secure. Accidental
disconnection while hose is pressurized makes
the hose whip and can be a safety hazard.
Caution
• Please check the hose connection prior to
starting Needle Scaler.
• Be aware that these Pneumatic Needle
Scalers can create dust & ying debris.
• Keep hands & clothing away from moving
parts.
• Store these Pneumatic Needle Scalers in
secure & dry environment.
• Do not allow the Pneumatic Needle Scaler
to run unattended.
• Do not modify this Pneumatic Needle
Scaler in any way as this will invalidate the
warranty and could lead to serious injury.
• Do not allow the Pneumatic Needle Scaler
to run continuously whilst not in contact
with the surface being prepared.
• Do not hold the exposed needles whilst
the Pneumatic Needle Scaler is in use
this could cause vibration damage to the
hands.
• Do not drag this Pneumatic Needle Scaler
by air hose.
Warning
Do not use the Pneumatic Needle Scaler in
potentially explosive environments.
