TEG- 2400i/TEG- 2600i

Guide d'installation rapide

Pilote sur CD-ROM

Cordon d'alimentation courant alternatif

Câble RS-232

Kit de montage

S S

Contenu de l'emballage

Application

1. Avant de commencer

Français

Workstations with

Fast Ethernet Card

(TE100-PCIWN)

1000Mbps

100Mbps

TEG-S2400i/TEG-S2600i

Server with

Copper Gigabit PCI Adapter

(TEG-PCITXR)

Multi-mode

Mini GBIC Module

(TEG-MGBSX)

2. Branchez le câble réseau à l'avant du

switch.et à vote PC.

1. Branchez le cordon d'alimentation à l'arrière

du TEG-S2400i/TEG-S2600i.

3. Vérifiez que le voyant PWR est vert et ne

clignote pas.

Français

2. Comment effectuer les connexions

1. Allez sur Start (Démarrer) >

Settings (Paramètres) >

Control Pannel (Panneau de

configuration).

2. Double-cliquez sur l'icône Network

Connection (Connexions

réseau).

3. Faites un clic droit sur l'icône Local

Area Connection (Connexions au

réseau local) et cliquez ensuite sur

Properties (Propriétés).

Français

3. Utilisation du Switch

Remarque : Pour plus d'informations sur les fonctions avancées, veuillez

consulter le guide de l'utilisateur.

L'installation est maintenant complète.

4. Cliquez sur l'onglet General et

ensuite sur Properties

(Propriétés). Sélectinnez Internet

Protocol(TCP/IP) (Protocole

Internet(TCP/IP), et cliquez sur

Properties (Propriétés). Modifiez

l'adresse IP et indiquez

192.168.223.10. Cliquez ensuite

sur OK pour appliquer le

paramétrage.

5. Ouvrez votre navigateur Internet,

tapez-y http://192.168.223.100, et

enfoncez la touche Enter.

6. Nom d'utilisateur : admin

Mot de passe : 123

7. Sélectionnez l'option adéquate

permettant de configurer le switch

SNMP.

Français

Q1.

A1.

Q2.

A2.

Q3.

A3.

How come I cannot see any light from any of my LED's?

Your TEG-S2400i/TEG-S2600i is not getting any power. Make

sure that your surge protector or your outlet is getting power and make

sure that the AC Power cord is properly connected to your switch.

After connecting several workstations to the switch, I have all

workstations communicating with the server, but I cannot access the

switch's web configuration utility. What should I do?

Please change your switch's IP address to match the network

segment of your workstations. For configuring your switch's IP address,

please consult the User's Guide.

I have connected several workstations into the switch, but one

workstation does not connect to the network. The LEDs on one of the

ports remain unlit, while the rest of the ports have blinking LEDS. What

do I do?

You either have a faulty network card or a faulty network patch cable.

Make sure that your network card and network cable are functional.

If you have any questions regarding your switch please contact TRENDnet

Technical Support Department.

Troubleshooting
