Vulcan-Hart 1036C Manuale utente

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

Item # __________________________

C.S.I. Section 11420

A2780

ISO9001

Vulcan-Hart Co.

F-31622 (04-07)

Model 1036C

CHEESEMELTERS

QUARTZ HEATER ELECTRIC CHEESEMELTER

Model 1036W

CHEESEMELTERS Quartz Heater Electric Cheesemelter

SPECIFICATIONS:

Quartz heated, cheesemelter, (counter) (wall mount) Vulcan-Hart

Model No. _________ . Stainless steel front, sides, top and interior.

Insulated with 1" on top and sides. Backs have 1" of insulation

on counter and wall mount models. Rack activated micro switch

power heaters to 100% when product is placed on the rack. Idles

at 25% heat when master power switch is “On” and there is no

product on the rack. Solid state controls with cooling fan. Top

mounted energy efﬁcient quartz heaters snap in for easy instal-

lation. Requires 208 volt or 240 volt single phase.

CSA design certiﬁed. NSF listed. U L listed.

MODEL WIDTH SUFFIX

1024 27" C = Counter

1036 361⁄2"

1048 50" W = Wall Mount

STANDARD FEATURES

■Stainless steel top, inside, sides and all fasteners.

■Top, sides, and back are insulated with 1" of insulation.

■Controls are solid state.

■Electrical compartment is fan cooled.

■Inputs are as follows: 1024 models - 2.4 KW

1036 models - 3.6 KW

1048 models - 4.8 KW

■Master switch when “On” causes unit to idle at 25% heat.

■100% power “On” results from placing product on the rack.

■Rack adjustable to any one of four rack positions.

■Clearance to the top from each rack position: Position 1, 2";

Position 2, 31⁄2"; Position 3, 43⁄4"; Position 4, 6".

■Both 1024 and 1036 models have a single “On-Off” switch

and red signal light.

■1048 modelshaveasingle“On-Off” switchwitha red signallight

as well as right and left heater “On” switches and lights.

■Instant “On”, instant “Off” even heating, top quartz heaters.

■Energy efﬁcient snap in heaters for easy installation.

■Available 208 or 240 volt, 1 phase.

■Field wiring connection on left side.

■4' adjustable legs (counter models only).

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028

502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602

NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and

speciﬁcations without notice.

F-31622 (04-07)

CHEESEMELTERS

QUARTZ HEATER ELECTRIC CHEESEMELTER

(Measurements in parenthesis in millimeters)

*Leave 3" clearance on the left side for fan air movement.

Rack Sizes: (1024) 20" x 131/2", (1036) 30" x 131/2", (1048) 42" x 131/2".

Interior Dimensions: 91/2" high, 141/4" deep. Width (1024) 21", (1036) 31", (1048) 44".

A B

Model inches mm inches mm

1024 27" 686 25" 635

1036 361⁄2" 927 341⁄2" 876

1048 50" 1270 48" 1219
