ADC520 Series

BLACK AND WHITE SPECIALTY CAMERAS

www.americandynamics.net

FEATURES

The ADC520 Series cameras feature a black and

white imager that delivers a sharp picture at a

very economical cost.

The ADC520 Series offers cameras in housings

different than your typical standard camera.

The ADC520D features a 3.5-inch discreet

dome housing that is an attractive alternative

to a standard camera.

The ADC521B features a low silhouette tube

design that will fit in with most decors.

The ADC522WP is a weather resistant tube

design that meets IP57 for weather resistance.

The built in IR illumination LEDs allow this

camera to produce a picture with 0 lux ambient

light. The 12 IR LEDs provide coverage up to

10 meters (30 ft) to deliver a sharp picture while

producing no visible light.

The ADC523PIR is a camera mounted in a

standard motion detector shell. The camera

blends in to the background appearing as a

security system device. People are unaware that

there is video surveillance in the area.

•1/3-inch interline black

and white imager, EIA

format

•380-line B/W imager

•Sharp picture

•0.5 lux light sensitivity

•Sensitive to IR

illumination

•Discreet housings

•Automatic electronic

shutter

•Automatic gain control

•12 VDC input via

included power supply

•ADC522WP includes IR

illumination and is

weather resistant

AMERICAN DYNAMICS ADC520 SERIES BLACK AND WHITE SPECIALTY CAMERAS

Product specifications and availability subject to

change without notice.

Certain product names mentioned herein may be trade

names and/or registered trademarks of other companies. VS280-04 03/04 L

SPECIFICATIONS

Model Numbers

ADC520D . . . . . . . . . . . . . . . . . . . .B/W camera in 3.5-inch micro dome with

3.6 mm lens

ADC521B . . . . . . . . . . . . . . . . . . . .B/W camera in Bullet Housing with

3.6 mm lens and mount

ADC522WP . . . . . . . . . . . . . . . . . .B/W camera in weatherproof Bullet

Housing with 4.0 mm lens and IR

illuminators and mount

ADC523PIR . . . . . . . . . . . . . . . . . .B/W camera in non-functional PIR

detector housing with 3.6 mm lens

Operational

EIA Imager . . . . . . . . . . . . . . . . . . .Interline transfer 1/3-inch CCD

Video Output . . . . . . . . . . . . . . . . .1.0 Vp-p 75

Active Pixels Count . . . . . . . . . . . .510 (H), 492 (V)

Minimum Scene Illumination . .0.5 lux at F2.0

Horizontal Resolution . . . . . . . . .380 TVL

Light Compensation Modes . . .Auto electronic shutter

1/60 to 1/100,000

Synchronization Modes . . . . . . .Internal

Geometric Distortion . . . . . . . . .None

S/N Ratio . . . . . . . . . . . . . . . . . . . .-48 dB

Input Connectors

Input Power . . . . . . . . . . . . . . . . . .2.1 mm

Composite Video . . . . . . . . . . . . .BNC on cable

Electrical

Input Voltage . . . . . . . . . . . . . . . . .120VAC @ 60Hz

Power Supply Output . . . . . . . . .12VDC (±10%)

Power Consumption . . . . . . . . . .ADC520D 120 mA

ADC521B 120 mA

ADC522WP 120 mA

ADC523PIR 240 mA

Regulatory

Emissions . . . . . . . . . . . . . . . . . . . .FCC Part 15, Class B

ICES-003

Safety . . . . . . . . . . . . . . . . . . . . . . . .UL 1585 (power supply only)

Environmental

Operating Temperature . . . . . . . .-10º to 50º C (14º to 122º F)

Humidity . . . . . . . . . . . . . . . . . . . . .90% RH (non-condensing)

ADC522WP . . . . . . . . . . . . . . . . . .100% RH

Storage Temperature . . . . . . . . . .-30º to +60º C (-22º to 140º F)

Dimensions



Weight



Shipping Weight



Environmental

ADC520D

87 x 57 mm

3.4 x 2.2 in

(D x H)



.18 kg

.40 lbs



.43 kg

.90 lbs 



Indoor Only

ADC521B



26 x 87 mm

1.02 x 3.4 in

(D x L)



.30 kg

.70 lbs



.55 kg

1.20 lbs 



Indoor Only

ADC523PIR



70 x 110 x 49 mm

2.7 x 4.3 x 1.9 in

(W x H x D)



.18 kg

.40 lbs 



.43 kg

.90 lbs 



Indoor Only

ADC522WP



65 x 105 mm

2.5 x 4.1 in

(D x L)



.55 kg

1.20 lbs 



.80 kg

1.80 lbs



IP57



Note: All ADC520 Series cameras ship with a 120 VAC to 12 VDC UL listed power supply with a 6 foot cord. 12 VDC

cameras will not line-lock and are not recommended to be used in a matrix switcher environment.
