DATASHEET

Discover™Series

Mini-Domes

Features that make a difference:

High impact vandal resistant housing that retains shape even after

forceful impact

High impact vandal resistant polycarbonate bubbles (clear and tinted)

Snap-on bubble liner for an extra level of covertness

Greater viewing flexibility with 3-axis camera positioning

Three high quality lens options for better image quality and improved

low light performance

Multiple camera options, including WDR model with latest

Pixim technology

Night-Saver mode for extreme low light conditions

Easy installation with 8 mounting options (surface, flush, pendant,

wall, wall pole, wall exterior corner, inside corner, electrical box)

Discover Mini-Drone option

Optional heater kit for -50°C (-58°F)

The Discover series of Mini-Domes delivers a vandal resistant

camera solution at a non-vandal resistant price. This selection

of high performance fixed cameras includes high impact,

vandal resistant dome housings built to withstand even the

harshest environments. Unlike other dome housings in the

industry, which are made of metal, the Discover series

housing is made with extremely durable composite and

polycarbonate materials that have “shape memory”. The

housing comes with a choice of clear or tinted vandal resistant

bubbles and includes a bubble liner to make it more covert.

Advanced 3-axis camera pivoting gives you exactly the angle

you need while optimal white balance provides the clearest,

most color-perfect images possible.

With three different mini-domes to choose from, there’s a

Discover solution just right for your particular security

requirements.

The Discover wide dynamic range (WDR) camera uses over

504 lines of resolution and a pixel-by-pixel shutter speed that

lets you see better in areas where both very bright and dark

areas exist, such as an entranceway. This model also features

up to a 2x digital zoom to get an even closer view of the

action. Night-Saver mode improves performance in low light

situations, automatically switching from color to monochrome

as light dims and reverting back to color once light is restored.

The WDR mini-dome also includes a DVR-Saver mode which

helps conserve valuable hard drive space, reducing the size of

video files by up to 30% when used with an Intellex

digital

video management system.

The Discover high resolution camera has 540 TVL and also

includes a user-selectable Night-Saver mode. For challenging

lighting environments, a selectable expanded auto white

balance mode is available. Vivid colors and powerful low light

performance provide some of the best images available today.

The Discover standard resolution camera offers a cost

effective solution for the value-conscious with 330 TVL. It is

available with a 3.8 - 9.5mm vari-focal, auto iris lens.

Each Discover Mini-Dome can be easily mounted in one of

eight ways (surface, flush, pendant, wall, wall pole, wall

exterior corner, inside corner, electrical box)

SPECIFICATIONS

AD001_DS_200510_R1_LT_EN

Model Number Configuration for Discover Mini-Domes

General

Imager Pixim Orca sensor 1/3–inch CCD 1/3–inch CCD

Video Output 1.0 Vp-p/75-ohm, BNC 1.0 Vp-p/75-ohm, BNC 1.0 Vp-p/75-ohm, BNC

Horizontal Resolution 504+ TV lines 540 TV lines 330 TV lines

Active Pixel Count (H x V) Universal: 720 x 540 NTSC: 768 x 494 (PAL: 752 x 582) NTSC: 510 x 492 (PAL: 500 x 582)

Minimum Scene Illumination 0.95 lux @ F1.2 0.65 lux @ F1.2 0.7 lux @ F1.2

Digital Slow Shutter (DSS) 2x (default) – 32x N/A N/A

Wide Dynamic Range 120 dB / 17 bit N/A N/A

Sync System Line-lock, phase-adjustable or internal Line-lock, adjustable or internal Internal

S/N Ratio >42 dB 50 dB 48 dB

White Balance Automatic White Balance (AWB), AWB AWB

One-touch & manual

AWB Ranges—Normal (Extended) 2200 K-7500 K (2000 K-11000 K) 2700 K-11000 K (2000 K-18000 K) 2700 K-11000 K (N/A)

WDR Metering Zone One zone adjustable N/A N/A

Backlight Compensation N/A Center weighted On/Off N/A

Flickerless Mode Selectable On/Off Selectable On/Off N/A

Night-Saver Selectable On/Off Selectable On/Off N/A

DVR-Saver Mode Selectable On/Off N/A N/A

Digital Zoom Scalable, up to 2x N/A N/A

Power Comsumption 3 Watts 2.8 Watts 1.7 Watts

Weight 0.9 kg (1.9 lbs) 1.0 kg (2.2 lbs) 0.9 kg (1.9 lbs)

High Resolution

ADCDH Series Standard Resolution

ADCDS Series

Wide Dynamic Range

ADCDW Series

Common to all Discover Mini-Domes

Physical, Electrical, Environmental & Regulatory

Dimensions (H x W) 92 x 136 mm (3.6 x 5.4 in)

Housing Color White

Bubble Material Polycarbonate

Bubble Diameter 94 mm (3.7 in)

Bubble Thickness 2.5 mm (0.1 in)

Minimized F-Stop (Tinted & Clear) F1.0 & F0

Pan & Effective Tilt (at 17 in) Range 2360º & 180º(+/-90º)

Power Input112 VDC -10% +20%

24 VAC +/-20%, 50/60 Hz

Power Connection Flying lead or plug

Without Heater -30º to 50ºC (-22º to 122ºF)

With Optional Heater -58º to -50ºC (-50º to 122ºF)

Humidity 90% (noncondensing)

Storage Temperature -20º to 60ºC (-4º to 140ºF)

Emissions FCC part 15 Class B

CE: EN55022

ICES-003

Immunity CE: EN50130-4

Safety UL/cUL; CSA C22.2

Lenses

2.5 - 6 mm Lens

Iris & F-Stop F1.3 ~ 360 & F1.3

Field of View (H x V) Wide 108.2º x 80.4º (Tele 47.6º x 35.6º)

3.8 - 9.5 mm Lens

Iris & F-Stop F1.2 ~ 360 & F1.2

Field of View (H x V) Wide 74.2º x 54.0º & (Tele 30.0º x 22.4º)

9 - 22 mm Lens

Iris & F-Stop F1.8 ~ 360 & F1.8

Field of View (H x V) Wide 30.7º x 22.7º & (Tele 14.1º x 10.6º)

Accessories

ADCDDRONE Drone, no camera or lens capability

ADCDMWALL Wall mount w/pendant cap

ADCDMCRNRO Outside corner adapter for use with

ADCDMWALL

ADCDMPEND Pendant cap, 3/4" thread

ADCDMCRNR Corner mount

ADCDMPOLE Pole mount for use with ADCDMWALL

ADCDMELEC 4S electrical box adapter

ADCDHTR Heater module

ADCDSLC Video service lead cable

NEC Class 2/LPS power supply required.

Using 2.5-6 mm lens at wide.

BRAND FAMILY CAMERA LENS BUBBLE FORMAT

AD CD X XXXX X X

ADCDH AD Camera H = High Resolution

2506 = 2.5-6 mm C = Clear N = NTSC

Series Discover

3895 = 3.8-9.5 mm T = Tinted P = PAL

0922 = 9-22 mm

ADCDW W = Wide Dynamic Range

2506 = 2.5-6 mm C = Clear U = Universal

Series

3895 = 3.8-9.5 mm T = Tinted

(NTSC/ PAL)

0922 = 9-22 mm

ADCDS S = Standard Resolution

3895 = 3.8-9.5 mm C = Clear N = NTSC

Series

T = Tinted P = PAL
