ASROCK X570 CREATOR Manuale utente

Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per AsRock X570 Creator o

cerca il tuo prodotto tra le migliori offerte di Schede Madri

Version 1.0

Published July 2019

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI® and HDMI High-Denition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the

United States and other countries.

Manufactured under license under U.S. Patent Nos: 5,956,674; 5,974,380; 6,487,535;

7,003,467 & other U.S. and worldwide patents issued & pending. DTS, the Symbol, &

DTS and the Symbol together is a registered trademark & DTS Connect, DTS Interactive,

DTS Neo:PC are trademarks of DTS, Inc. Product includes soware.

CE Warning

is device complies with directive 2014/53/EU issued by the Commision of the European

Community.

is equipment complies with EU radiation exposure limits set forth for an uncontrolled

environment.

is equipment should be installed and operated with minimum distance 20cm between

the radiator & your body.

Operations in the 5.15-5.35GHz band are restricted to indoor usage only.

Radio transmit power per transceiver type

Function Frequency Maximum Output Power (EIRP)

WiFi

2400-2483.5 MHz 18.5 + / -1.5 dbm

5150-5250 MHz 21.5 + / -1.5 dbm

5250-5350 MHz 18.5 + / -1.5 dbm (no TPC)

21.5 + / -1.5 dbm (TPC)

5470-5725 MHz 25.5 + / -1.5 dbm (no TPC)

28.5 + / -1.5 dbm (TPC)

Bluetooth 2400-2483.5 MHz 8.5 + / -1.5 dbm

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 8

1.4 I/O Panel 10

Chapter 2 Installation 14

2.1 Installing the CPU 15

2.2 Installing the CPU Fan and Heatsink 17

2.3 Installing Memory Modules (DIMM) 26

2.4 Expansion Slots (PCI Express Slots) 29

2.5 Connecting Graphics Card to DisplayPort Input 31

2.6 Jumpers Setup 33

2.7 Onboard Headers and Connectors 34

2.8 Smart Switches 41

2.9 Dr. Debug 43

2.10 SLITM and Quad SLITM Operation Guide 49

2.10.1 Installing Two SLITM-Ready Graphics Cards 49

2.10.2 Driver Installation and Setup 51

2.11 CrossFireXTM , 3-Way CrossFireXTM and Quad CrossFireXTM

Operation Guide 52

2.11.1 Installing Two CrossFireXTM-Ready Graphics Cards 52

2.11.2 Installing Three CrossFireXTM-Ready Graphics Cards 54

2.12 M.2_SSD (NGFF) Module Installation Guide (M2_1) 56

2.13 M.2_SSD (NGFF) Module Installation Guide (M2_2) 59

Chapter 3 Software and Utilities Operation 62

3.1 Installing Drivers 62

3.2 A-Tuning 63

3.2.1 Installing A-Tuning 63

3.2.2 Using A-Tuning 63

3.3 ASRock Live Update & APP Shop 66

3.3.1 UI Overview 66

3.3.2 Apps 67

3.3.3 BIOS & Drivers 70

3.3.4 Setting 71

3.4 ASRock Polychrome SYNC 72

Chapter 4 UEFI SETUP UTILITY 75

4.1 Introduction 75

4.1.1 UEFI Menu Bar 75

4.1.2 Navigation Keys 76

4.2 Main Screen 77

4.3 OC Tweaker Screen 78

4.4 Advanced Screen 82

4.4.1 CPU Conguration 83

4.4.2 Onboard Devices Conguration 84

4.4.3 Storage Conguration 86

4.4.4 ACPI Conguration 87

4.4.5 Trusted Computing 88

4.4.6 AMD CBS 89

4.4.7 AMD PBS 90

4.4.8 AMD Overclocking 91

4.5 Tools 92

4.6 Hardware Health Event Monitoring Screen 93

4.7 Security Screen 96

4.8 Boot Screen 97

4.9 Exit Screen 99

English

X570 Creator

Chapter 1 Introduction

ank you for purchasing ASRock X570 Creator motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock X570 Creator Motherboard (ATX Form Factor)

• ASRock X570 Creator Quick Installation Guide

• ASRock X570 Creator Support CD

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 1 x ASRock SLI_HB_Bridge_2S Card (Optional)

• 1 x ASRock WiFi 2.4/5 GHz Antenna

• 1 x Right Angle Mini DisplayPort to DisplayPort Cable (Optional)

• 2 x Screws for M.2 Socket (Optional)

• 2 x Standos for M.2 Sockets (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• 2oz Copper PCB

CPU • Supports AMD AM4 socket Ryzen™ 2000 and 3000 series

processors

• IR Digital PWM

• 14 Power Phase design

Chipset • AMD X570

Memory • Dual Channel DDR4 Memory Technology

• 4 x DDR4 DIMM Slots

• AMD Ryzen series CPUs (Matisse) support DDR4 4666+

(OC)/4400(OC)/4300(OC)/4266(OC)/4200(OC)/4133

(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600(OC)/

3466(OC)/3200/2933/2667/2400/2133 ECC & non-ECC, un-

buered memory*

• AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4

3600+(OC)/3466(OC)/3200(OC)/2933/2667/2400/2133 ECC

& non-ECC, un-buered memory*

• AMD Ryzen series CPUs (Picasso) support DDR4 3466+|

(OC)/3200(OC)/2933/2667/2400/2133 non-ECC, un-buered

memory*

* For Ryzen Series CPUs (Picasso), ECC is only supported with

PRO CPUs.

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

* Please refer to page 26 for DDR4 UDIMM maximum

frequency support.

• Max. capacity of system memory: 128GB

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

AMD Ryzen series CPUs (Matisse)

• 3 x PCI Express 4.0 x16 Slots (PCIE1/PCIE4/PCIE6: single

at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE4); triple at x8

(PCIE1) / x8 (PCIE4) / x4 (PCIE6))*

English

X570 Creator

AMD Ryzen series CPUs (Pinnacle Ridge)

• 3 x PCI Express x16 Slots (PCIE1/PCIE4/PCIE6: single at

Gen3x16 (PCIE1); dual at Gen3x8 (PCIE1) / Gen3x8 (PCIE4);

triple at Gen3x8 (PCIE1) / Gen3x8 (PCIE4) / Gen4x4

(PCIE6))*

AMD Ryzen series CPUs (Picasso)

• 1 x PCI Express x16 Slot (single at Gen3x8 (PCIE1) or

Gen4x4 (PCIE6))*

* e PCIe bandwidth is dependent on the CPU installed.

* Supports NVMe SSD as boot disks

• 3 x PCI Express 2.0 x1 Slots

• Supports AMD Quad CrossFireXTM, 3-Way CrossFireXTM

and CrossFireXTM

• Supports NVIDIA® Quad SLITM and SLITM**

• Supports NVIDIA® NVLinkTM with dual NVIDIA® GeForce®

RTX series graphics cards**

** NVIDIA NVLink Bridge does not come with the package.

Please purchase it from NVIDIA® if necessary.

** is feature is only supported with Ryzen Series CPUs

(Matisse and Pinnacle Ridge).

• 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-

802.11ax module (on the rear I/O)

• 15μ Gold Contact in VGA PCIe Slot (PCIE1)

Graphics • Integrated AMD RadeonTM Vega Series Graphics in Ryzen

Series APU*

* Actual support may vary by CPU

• DirectX 12, Pixel Shader 5.0

• Shared memory default 2GB. Max Shared memory supports

up to 16GB.

* e Max shared memory 16GB requires 32GB system memory

installed.

• Supports HDMI 2.0 with max. resolution up to 4K x 2K

(4096x2160) @ 60Hz

• Supports DisplayPort 1.4 Input with max. resolution up to

4K x 2K (4096x2160) @ 120Hz

* DisplayPort 1.4 Input is used to connect a Type-C Monitor.

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI 2.0 Ports (Compliant

HDMI monitor is required)

Altri manuali per X570 CREATOR

Indice

Altri manuali ASROCK Scheda madre

ASROCK

ASROCK P43DE3 Manuale utente

ASROCK

ASROCK N73PC-GS - Manuale utente

ASROCK

ASROCK B550 PG Velocita Manuale utente

ASROCK

ASROCK IMB-A1000 Manuale utente

ASROCK

ASROCK A75iCafe Manuale utente

ASROCK

ASROCK Super Alloy B660M PG Riptide Manuale utente

ASROCK

ASROCK J3160TM-ITX Manuale utente

ASROCK

ASROCK A780FULLHD - V1.0 Manuale utente

ASROCK

ASROCK CONROE1333-DVI-H - V1.0 Manuale utente

ASROCK

ASROCK IMB-185 Manuale utente

ASROCK

ASROCK H610TM-ITX Manuale utente

ASROCK

ASROCK Z590 Phantom Gaming-ITX/TB4 Manuale utente

ASROCK

ASROCK 775i48 Manuale utente

ASROCK

ASROCK G41M-VS Manuale utente

ASROCK

ASROCK IMB-193 Manuale utente

ASROCK

ASROCK 890GM Pro3 R2.0 Manuale utente

ASROCK

ASROCK B450 Pro4 Manuale utente

ASROCK

ASROCK ALIVENF7G-GLAN - V1.0 Manuale utente

ASROCK

ASROCK ALIVESATA2-GLAN Manuale utente

ASROCK

ASROCK P55 PRO/USB3 - Manuale utente

ASROCK

ASROCK Z87 OC Formula ac Manuale utente

ASROCK

ASROCK athena A2 Kit Manuale utente

ASROCK

ASROCK Fatality H97 Killer series Manuale utente

ASROCK

ASROCK H67M-GE/THW Manuale utente

Manuali Scheda madre popolari di altre marche

DFI

DFI SD170 Manuale utente

Asus

Asus P2L97A Manuale utente

Winmate

Winmate IC70 Manuale utente

Asus

Asus MES-B Manuale utente

Grantech

Grantech SYS8F377VGGA-3OMN Manuale utente

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manuale utente

Gigabyte

Gigabyte GA-9IVDT Manuale utente

Texas Instruments

Texas Instruments ADS8372EVM Manuale utente

Commell

Commell MS-C73 Manuale utente

IBT Technologies

IBT Technologies MB860 Manuale utente

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manuale utente

Biostar

Biostar M7VIT Bravo Istruzioni per l'uso e l'installazione

Intel

Intel D33217CK Manuale utente

Asus

Asus F1A55-M LX PLUS R2.0 Manuale utente

EPC

EPC EPC9147C Manuale utente

Asus

Asus EX-B760M-V5 D4 Manuale utente

EPOX

EPOX MU-8KHA0010 Manuale utente

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manuale utente
