IBASE Technology MB898 Manuale utente

MB898/MB898F/

MB898RF

Socket LGA775 Pentium®4

Intel®Q965 Chipset

Industrial Motherboard

USER’S MANUAL

Version 1.0

Acknowledgments

Award is a registered trademark of Award Software International,

Inc.

PS/2 is a trademark of International Business Machines

Corporation.

Intel and Pentium 4 are registered trademarks of Intel

Corporation.

Microsoft Windows is a registered trademark of Microsoft

Corporation.

Winbond is a registered trademark of Winbond Electronics

Corporation.

All other product names or trademarks are properties of their

respective owners.

MB898 User’s Manual iii

Table of Contents

Introduction.......................................................1

Checklist..............................................................................1

Product Description.............................................................2

Specifications......................................................................3

Board Dimensions...............................................................4

Installations.......................................................5

Installing the CPU...............................................................6

ATX Power Installation ......................................................6

Installing the Memory.........................................................7

Setting the Jumpers .............................................................8

Connectors on MB898 ......................................................12

Watchdog Timer Configuration........................................24

BIOS Setup.......................................................29

Drivers Installation......................................49

Intel Q965 Chipset Software Installation Utility...............50

Intel Q965 Chipset Graphics Driver..................................52

Realtek Codec Audio Driver Installation..........................54

Intel LAN Drivers Installation ..........................................55

Appendix...........................................................57

A. I/O Port Address Map...................................................57

B. Interrupt Request Lines (IRQ)......................................58

iv MB898 User’s Manual

This page is intentionally left blank.

INTRODUCTION

MB898 User’s Manual 1

Introduction

Checklist

Your MB898/MB898F Pentium®4 motherboard package should include

the items listed below:

•The MB898/MB898F motherboard

•This User’s manual

•1 Back I/O shield

•1 IDE cable

•1 Floppy cable

•1 SATA cable

•1 Serial-Port cable

•1 CD containing the following:

•Chipset Drivers

•Flash Memory Utility

INSTALLATIONS

2MB898 User’s Manual

Product Description

The MB898/MB898F LGA 775 Pentium®4 motherboard incorporates

the Intel Q965 chipset that can utilize a single LGA775 processor of up

to 4.0GHz or higher and supports FSB frequency of 533/800/1066Mhz

(133MHz(533MT/s), 200MHz(800MT/s) and 266MHz(1066MT/s)

HCLK respectively.

The Q965 chipset is designed for use with the Pentium®4 processor with

1M Level 2 (CPU integrated) cache. The integrated GMCH component

provides the CPU interface, DDR2 interface, Hub Interface and PCI

Express graphics interface.

Four DDR2 memory sockets supports DDR2 400/533/667/800 SDRAM

DIMM modules of up to 8GB in capacity.

The board is designed with one Intel 82566DC PCI Express Gigabit

PHY (MB898F/RF only) or 82562V 10/100 PHY (MB898 only) LAN

controllers. Serial ATA connectors offer 3Gb/s data throughput speed -

faster than the most advanced parallel ATA.

Expansion is provided by four PCI slots, two PCI Express x1 and one

PCI Express x16. Other advanced features include ten USB 2.0 ports,

IrDA interface, digital I/O, four serial ports, watchdog timer and audio

function. Dimensions of the board are 12” by 9.5” in an ATX form

factor.

Remarks: MB898/MB898F supports Intel Core 2 Duo Dual Core

CPU, Pentium® D Dual Core CPU and Pentium® 4 HT single core

CPU. It also supports EMT64 processors.

MB898RF supports six Serial ATA connectors (with RAID function).

MB898 and MB898F support four Serial ATA connectors only.

INTRODUCTION

MB898 User’s Manual 3

Specifications

MB898/MB898F

Socket LGA775 Pentium®4 ATX Motherboard w/ Intel®Q965 Chipset

Features Supports Intel Core 2 Duo / Pentium®D / Pentium®4 HT / Celeron®D

processors Up to 3.8GHz+, 533MHz/800MHz/1066MHz FSB

DDR2 DIMM x 4, max. 8GB

ICH8 10/100 or Intel PCI Express Gigabit Ethernet

Integrated Intel®Q965 VGA, CRT support

4 x SATA II, 10 x USB 2.0, 4 x COM, Watchdog timer, Digital I/O

(MB898RF supports 6 x SATA with RAID)

4 x PCI, 2 x PCI Express (x1), 1 x PCI Express (x16) slots

System

CPU Socket LGA775 for Intel Core 2 Duo / Pentium

D / Pentium

HT / Celeron®D, up to 3.8GHz+

System Memory DDRII DIMM x 4, max. 8GB, 533/667/800MHz

System Chipset Intel

Q965 + ICH8, 533MHz/800MHz/1066MHz FSB

BIOS Award 8Mbit

Watchdog Timer 256 levels

SSD NA

H/W Monitor Yes

Expansion Slot 4 PCI, 2 PCI Express (x1), 1 PCI Express (x16)

Graphics

VGA Controller Intel

Q965 integrated

VGA Memory Shared memory

Max. 224MB

LCD Interface N/A

Ethernet

Controller ICH8 integrated with 82562V PHY 10/100 or

Intel 82566DC PCI Express Gigabit LAN (on

MB898F/MB898RF)

Connector One RJ-45 on board

Multi I/O

Chipset ICH8, Winbond 83627EHF, Fintek F81216

1x IDE (UDMA33/66/100), 1x FDD, 1x KB, 1x Mouse

4x RS-232, 4x SATA II (300MB/s)

MB898RF supports 6x SATA II with RAID function

USB 4 ports on board

Pin header for 6 ports (USB 2.0)

Audio Built-in audio + AC97 codec

Others IrDA, 4-in/4-out digital I/O

Mechanical and Environmental

Dimensions 305mm x 244mm (12“ x 9.6“)

Max. Power Requirement TBC

Operating Temperature 0°C~60°C (32°F~140°F)

Storage Temperature -20°C~80°C (-68°F~176°F)

Relative Humidity 10%~90% (non-condensing)

Remarks: MB898/MB898F supports Intel Core 2 Duo Dual Core CPU,

Pentium® D Dual Core CPU and Pentium® 4 HT single core CPU. It also

supports EMT64 processors.

INSTALLATIONS

Board Dimensions

4MB898 User’s Manual

INSTALLATIONS

MB898 User’s Manual 5

Installations

This section provides information on how to use the jumpers and

connectors on the MB898/MB898F in order to set up a workable system.

The topics covered are:

Installing the CPU........................................................................ 6

ATX Power Installation............................................................... 6

Installing the Memory.................................................................. 7

Setting the Jumpers...................................................................... 8

Connectors on MB898/MB898F................................................ 12

Watchdog Timer Configuration................................................. 24

INSTALLATIONS

Installing the CPU

The MB898/MB898F motherboard supports an LGA 775 processor

socket for Intel® Pentium® 4 processors.

The LGA 775 processor socket comes with a lever to secure the

processor. Refer to the pictures below, from left to right, on how to place

the processor into the CPU socket. Please note that the cover of the

LGA775 socket must always be installed during transport to avoid

damage to the socket.

ATX Power Installation

The system power is provided to the motherboard with the ATX1 and

ATX_12V power connectors. ATX1 is a 24-pin power connector and

ATX_12V is a 8-pin 12V power connector.

The 24-pin power connector can to be connected to a standard 20-pin

ATX power connector in a standard ATX power supply (Min. 400watt).

Note: The power supply 5VSB voltage must be at least 2A.

6MB898 User’s Manual
