Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Job Information Type:

Job Name:

Cat. No.:

Lamp(s):

Notes:

Lytecaster®Recessed Downlighting 1179M1

Page 1 of 2 6 3/4" Aperture Basic Baffle Reflector Trim

Features

1. Reflector: Hydroformed aluminum, .040" thick (18 ga.) ; non-yellowing,

scruff-resistant Perma White finish with 88% reflectance; white trim flange.

2. Step Baffle: Molded high temperature phenolic. Stepped conical surface for

low brightness; matte black or gloss white finish.

3. Frame-In Kit: (1102P1 standard frame shown). Other frames listed above

and shown on the right. See Frame-In Kit specification sheets for more

details.

Options & Accessories

Par30 Socket Extender: 1968 - for short neck Par30 lamp

Spread Lens: L56WWLENS - Proprietary spread lens for use with

combination of wall washer optics and LED Frame-In Kits.

Labels

UL (Suitable for Damp Locations), I.B.E.W.

1179M1/1100 DEEP IC Series

Incandescent Insulated Ceiling

9 1/4"

1179M1/1102P1

Standard Incandescent

5 1/2"

7 9/16"

6 3/8”

3/4" Max.

6 3/8"

1179M1/1103R

0™Non-IC

Remodeler Ring

1179M1/1104IC/N

0™Convertible

IC/Non-IC

7 1/2”

Reflector Trim

Frame-In Kit — See Individual Frame-In Kit Specification Sheets

1179M1

Matte Black Baffle

1179WH

Perma White Baffle

LED

Fluorescent

Frame-In Kit Installation Type Lamping Height

L56LED Non-IC Retrofit LED 6 3/8"

1104F13 Series IC (1) Quad/Triple 13W (GX24q-1) 7 1/2"

Incandescent

1104F18 † Series IC (1) Quad/Triple 18W (GX24q-2) 7 1/2"

1102P1

1103R

Non-IC

Non-IC Remodeler

75W A19, PAR30*

85W BR30

6 3/8"

1100FTU Series Non-IC (1) Triple 26/32W (GX24q-3) 6 7/8"

1100IC

1100AICM

1104ICX/N

AirSeal®IC

75W PAR30

85W BR30

7 5/16"

7 1/4"

1100AICMFT AirSeal®-IC

(1) Triple 26/32W (GX24q-3)

6 7/8"

1104IC/N**

1104ICR**

AirSeal®IC

IC Remodeler

90W PAR38**

75W PAR30

85W BR30

7 1/2"

7 1/2" 1910XDH1 Conversion Kit (2) Quad 13W (GX23-2) 6 7/8"

1104IC/N**

1104ICR**

Non-IC

Non-IC Remodeler

75W PAR30*

85W BR30

90W PAR38

7 1/2"

7 1/2" 1910XFH1 Conversion Kit (1) Quad 13W (GX23-2) 6 7/8"

1100DAICM

1100DICM

Deep AirSeal®IC

Deep IC

75W PAR30*

85W BR30

9 1/4"

†Lightolier recommends the use of triple tube lamps.

* Use socket extender 1968 for short neck PAR30 lamp.

**PAR38 use only with Frame-In Kits indicated

Lightolier a Genlyte company www.lightolier.com

631 Airport Road, Fall River, MA 02720 • (508) 679-8131 • Fax (508) 674-4710

We reserve the right to change details of design, materials and finish.

Lytecaster®Recessed Downlighting 1179M1

Page 2 of 2 6 3/4" Aperture Basic Baffle Reflector Trim

Job Information Type:

To convert lighting data for a lower wattage incandescent lamp of the same type, multiply the footcandle (or candlepower) values by the ratio of the lumens of the two lamps.

The coefficients of utilization remain the same.

RECESSED LYTECASTER DOWNLIGHT,

5 1/2” APERTURE, BASIC BLACK BAFFLE

ONE 85W BR30 FLOOD LAMP, LUMEN RATING = 925 LMS

ANGLE MEAN CP LUMENS

0 658

5 644 61

10 607

15 550 155

20 483

25 416 193

30 357

35 309 195

40 263

45 197 148

50 107

55 46 49

60 21

65 12 13

70 7

75 4 4

80 2

85 1 1

90 1

ZONE LUMENS % LAMPS % LUMINAIRE

0-30 409 44.28 49.96

0-40 604 65.31 73.68

0-60 801 86.65 97.76

0-90 819 88.63 100.00

40-90 215 23.33 26.32

60-90 18 1.98 2.24

90-180 0 .00 .00

0-180 819 88.63 100.00

** EFFICIENCY = 88.6% **

DATE: DATE APRIL 10, 1997

PREPARED FOR:

LIGHTOLIER, FALL RIVER, MA

CERTIFIED TEST REPORT NO. 0286FX

COMPUTED BY LSI PROGRAM **TEST LITE**

Conversion Factor: 85W BR30 FL, White, C.U. x 1.1. 2 Lt. 13W Quad Tube: Black, C.U. x 0.25;

White, C.U. x 0.35. 1 Lt. 13W Quad Tube: Black, C.U. x 0.3; White, C.U. x 0.4. 75W A19: Black,

C.U. x 0.35; White, C.U. x 0.50.

80 70 50 30 10

% WALL REFLECTANCE

50 30 10 50 30 10 50 30 10 50 30 10 50 30 10 0

1 .98 .98 .94 .96 .94 .92 .92 .91 .89 .89 .88 .87 .86 .85 .84 .82

2 .91 .87 .84 .89 .86 .83 .86 .84 .81 .84 .82 .80 .81 .80 .78 .76

3 .84 .79 .76 .83 .79 .75 .81 .77 .74 .78 .76 .73 .76 .74 .72 .70

4 .78 .73 .69 .77 .73 .69 .75 .71 .68 .73 .70 .67 .72 .69 .66 .65

5 .73 .67 .63 .72 .66 .63 .70 .66 .62 .68 .65 .62 .67 .64 .61 .60

6 .67 .62 .58 .67 .61 .57 .65 .61 .57 .64 .60 .57 .63 .59 .56 .55

7 .62 .56 .53 .62 .56 .52 .60 .55 .52 .59 .55 .52 .58 .54 .51 .50

8 .58 .52 .48 .57 .52 .48 .56 .51 .48 .55 .51 .47 .54 .50 .47 .46

9 .53 .48 .44 .53 .47 .44 .52 .47 .43 .51 .46 .43 .50 .46 .43 .42

10 .49 .44 .40 .49 .44 .40 .48 .43 .40 .47 .43 .39 .47 .42 .39 .38

20% FLOOR CAVITY REFLECTANCE

ROOM CAVITY RATIO

Lytecaster®Recessed Downlighting 1179M1

Page 2 of 2 6 3/4" Aperture Basic Baffle Reflector Trim
