1
Serial ATA PCI
Quick Installation Guide
04-0265F
Introducing the Serial ATA PCI
The Serial ATA PCI is an ultra high-speed dual channel
Serial ATA controller board for use in Pentium-class
computers. It achieves burst data transfer rates up to
150MB/s (1.5Gb/s) and supports various brand of hard
disk drives with capacities greater that 137GB.
FeaturesandBenefits
•Add up to two high-speed SATA hard drives
•New Serial ATA cable - easier to install & provides
better air circulation
•Compliant with Serial ATA 1.0 specification
•Compliant with PCI 2.3 specification
•Supports data transfer rate up to 1.5Gb/s
(150MB/s)
•Two independent bus master DMA channels with
256-byteFIFOsperchannelforhostreadsandwrites
•Breaksthe137GBbarrier!Works withvariousbrands
of large capacity Serial ATA hard disk drives
SystemRequirements
• Pentium®or equivalent PC with an available PCI
slot
• Windows®98SE / ME / NT4.0 / 2000 / XP (32-/64-
bit) / Server 2003 & 2008 (32-/64-bit) / Vista (32-/
64-bit)
2
PackageContents
•Serial ATA PCI adapter
•Driver CD
•Serial ATA cable
•Serial ATA power cable
•Quick installation guide
BoardLayout
Figure 1. Serial ATA PCI Board Layout
Hardware Installation
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
CN1
CN2
Serial ATA
connector
3
1. Turn OFF the power to your computer and any
other connected peripheral devices.
2. Unplug the power cord from the back of the
computer.
3. Remove the computer cover.
4. Remove the slot bracket from an available PCI slot.
5. To install the card, carefully align the card bus
connector to the selected PCI slot on the
motherboard. Push the board down firmly, but
gently, until it is well seated.
6. Replace the slot bracket holding screw to secure the
card.
DeviceConnection
TheSerialATA PCI is a dual channel Serial ATA controller
that supports up to two Serial ATA hard disk drives. If
you plan to use the second Serial ATA channel, you will
need to purchase another Serial ATA cable.
1. Install hard disk drive(s) in chassis.
2. ConnecttheSerialATA hard disk drive tothesystem
power supply using the Serial ATA power cable.
3. Connect one end of the Serial ATA cable to the hard
disk drive.
Figure 2: Hard disk drive connecrions
4. Attach the other end of the Serial ATA cable to the
Serial ATA connector on the Serial ATA PCI.
Serial ATA cable
Serial ATA power
cable
4
Figure 3. Connecting the Serial ATA cable
5. Follow the same instructions when connecting a
second hard drive. Device connection is now
complete.
6. Replacethecomputercover andreconnectthe power
cord.
Driver Installation
This section provides information on how to install the
Serial ATA PCI drivers.
Windows98SE
For New Windows 98SE Installation
1. Install the board and follow Microsoft procedures
to install Windows 98SE accordingly.
2. Once Windows has been installed, right click My
Computer and click Properties. Select Device
Manager tab.
3. Double click PCI Mass Storage Controller listed
under Other Devices.
4. Select Driver tab, then click Update Driver button.
5. Insert the driver CD and click Next.
Serial ATA
cable
5
6. Select Search for a better driver..., then click Next.
7. Check Specify a location, uncheck the other boxes,
then click Next.
8. Click Next,then click Finish.
9. Remove the driver CD and restart Windows to
complete the installation.
For Existing Windows 98SE Installation
1. Install the board and boot up Windows.
2. At the Add New Hardware Wizard, click Next.
3. Select Search for the best driver for your device and
click Next.
4. Insert the driver CD, check Specify a location,
uncheck the other boxes, type D:\98SE, then click
Next. (Change D: to match the drive letter of your
CD-ROM)
5. Click Next,then Finish.
6. Remove the driver CD and restart Windows to
complete the installation.
WindowsME
For New Windows ME Installation
1. Install the board and follow Microsoft procedures
to install Windows ME accordingly.
2. Once Windows has been installed, right click My
Computer, then click Properties. Select Device
Manager tab.
3. Double click PCI Mass Storage Controller listed
under Other Devices.
4. Select Driver tab, then click Update Driver button.
5. Insert the driver CD, select Specify the location of
the driver (Advanced), then click Next.
6
6. Check Specify a location, uncheck the other box,
type D:\ME, click Next. (Change D: to match the
drive letter of your CD-ROM)
7. Click Next, then click Finish. Remove the driver CD
and restart Windows to complete the installation.
For Existing Windows ME Installation
1. Install the board and boot up Windows ME.
2. AttheAddNewHardwareWizard,insertthedriver
CD.
3. Select Specify thelocationof the driver(Advanced),
then click Next.
4. Check Specify a location, uncheck the other box,
type D:\ME, click Next. (Change D: to match the
drive letter of your CD-ROM)
5. Click Next, then click Finish.
6. Remove the driver CD and restart Windows to
complete the installation.
ToVerifyWindows98SE/MEInstallation
1. Right-click My Computer, then click Properties.
Select Device Manager tab.
2. Double click SCSI controllers, Silicon Image SiI...
Controller should be listed.
3. Double click Silicon Image SiI... Controller and
click Properties. A message This device is working
properly is displayed in the dialog box when the
driver is correctly installed.
7
WindowsNT4.0
For New Windows NT4.0 Installation
A new installation of Windows NT4.0 requires a floppy
disk for the driver installation. To make this floppy disk,
copy the contents of the NT4 folder, found on the driver
CD, onto a blank floppy disk then follow the directions
below.
1. Install the board and follow Microsoft procedures
to install Windows NT4.0 accordingly.
2. At the Windows NT Setup screen, press F6 to
specify and add the driver.
3. Press S, select Other, then press Enter.
4. Insert the driver diskette then press Enter.
5. Select Silicon Image... for Windows NT 4.0 and
2000 and press Enter.
6. Press Enter to continue, then follow the on-screen
instructions to complete Windows NT4.0
installation.
For Existing Windows NT4.0 Installation
1. Install the board and boot up Windows NT4.0.
2. Double click My Computer/Control Panel/SCSI
Adapters, then click the Drivers tab.
3. Click Add..., then click Have Disk....
4. Insert the driver CD, type D:\NT4, then click OK.
(Change D: to match the drive letter of your
CD-ROM)
5. Highlight Silicon Image in the left column, then
select Silicon Image SiI... SATALink Controller,
and click OK.
6. ClickOK,removethedriver CD and restart NT4.0 to
complete the installation.
8
ToVerifyWindowsNT4.0Installation
1. Double click My Computer/Control Panel/SCSI
Adapters.
2. Highlight Silicon Image... Controller from SCSI
Adapters listing and click Properties. A message
This device is working properly is displayed in the
dialog box when the driver is correctly installed.
Windows2000
For New Windows 2000 Installation
A new installation of Windows 2000 requires a floppy
disk for the driver installation. To make this floppy disk,
copy the contents of the Floppy folder, found on the
driver CD, onto a blank floppy disk then follow the
directions below.
1. Install the board and follow Microsoft procedures
to install Windows 2000 accordingly.
2. Restart your system when prompted during
Windows' installation.
3. At the Windows 2000 Setup screen, press F6 to
install the driver.
4. Insert the driver diskette. Press S, then press Enter.
5. Select Silicon Image SiI... Controller and press
Enter.
6. Press Enter to continue and follow on-screen
instructions to complete the installation.
For Existing Windows 2000 Installation
1. Install the board and boot up Windows 2000.
2. At the Found New Hardware Wizard, click Next.
3. Select Search for a suitable driver for my device
(recommended) and click Next.
9
4. InsertthedriverCD,checkCD-ROMdrives,uncheck
the other boxes, and click Next. Click Next again to
continue.
5. Click Finish, remove the driver CD and restart
Windows to complete the installation.
WindowsXP/Server2003(32-bit)
For New Windows XP/Server 2003 Installation
A new installation of Windows XP/Server 2003 requires
a floppy disk for the driver installation. To make this
floppy disk, copy the contents of the Floppy folder,
found on the driver CD, onto a blank floppy disk then
follow the directions below.
1. Install the board and follow Microsoft procedures
to install Windows accordingly.
2. Restart your system if prompted by Windows
installation.
3. At the Windows Setup screen, press F6 to install the
driver.
4. Insert the driver diskette. Press Sthen press Enter.
5. Select Silicon Image SiI... Controller and press
Enter.
6. Press Enter to continue and follow the on-screen
instructions to complete the installation.
For Existing Windows XP/Server 2003 Installation
1. Install the board and boot up Windows.
2. At the Found New Hardware Wizard:
XP (w/SP1 or earlier)/Server 2003: continue to step #3
XP (w/SP2 or later)/Server 2003 (w/ SP1 or later): select
No, not at this time, then click Next.
3. Insert the driver CD, select Install the software
automatically (Recommended),and click Next.
10
4. Click Finish and restart Windows to complete the
installation.
WindowsXP/Server2003(64-bit)
For New Windows XP/2003 Installation
A new installation of Windows XP 64-bit/Server 2003
64-bit requires a floppy disk for the driver installation.
To make this floppy disk, copy the contents of the 64bit
folder, found on the driver CD, onto a blank floppy disk
then follow the directions below.
1. Install the board and follow Microsoft procedures
to install Windows accordingly.
2. Restart your system when prompted by Windows
installation.
3. At the Windows Setup screen, press F6 to install the
driver.
4. Insert the floppy disk you made above. Press Sthen
press Enter.
5. Select Silicon Image SiI 3512... that matches your
system processor, then press Enter.
6. Press Enter to continue and follow the on-screen
instructions to complete the installation.
For Existing Windows XP/2003 Installation
1. Install the board and boot up Windows.
2. AttheFound New Hardware Wizard, select No, not
at this time, then click Next.
3. Insert the driver CD, select Install the software
automatically (Recommended),and click Next.
4. Click Finish and restart Windows to complete the
installation.
Altri manuali per Serial ATA PCI
1
Indice
Altri manuali SIIG Hardware per computer
SIIG
SIIG SATA II PCIe RAID Manuale utente
SIIG
SIIG Parallel PCI 1P Manuale utente
SIIG
SIIG Network Device EVTEK-5103 Guida all'installazione
SIIG
SIIG NN-PCMM12-S3 Manuale utente
SIIG
SIIG 104-0487A Manuale utente
SIIG
SIIG Dual Profile Hi-Speed USB 4-Port PCI Manuale utente
SIIG
SIIG CyberParallel Dual Manuale utente
SIIG
SIIG JU-PCM422-S2 Manuale utente
SIIG
SIIG UltraATA 133 PCI Manuale utente
SIIG
SIIG NN-EC2812-S1 Manuale utente
SIIG
SIIG DP FireWire 800 PCIe Manuale utente
SIIG
SIIG NN-E20022-S1 Manuale utente
SIIG
SIIG DP FireWire 800 3-Port PCIe Manuale utente
SIIG
SIIG Serial ATA PCI RAID Manuale utente
SIIG
SIIG JU-P40412-S1 Manuale utente
SIIG
SIIG DP SoundWave 4 Channel PCI Manuale utente
SIIG
SIIG SATA II-150 PCI Manuale utente
SIIG
SIIG NN-8CB212-S1 Manuale utente
SIIG
SIIG Serial ATA 4-Channel PCI Manuale utente
SIIG
SIIG Parallel Pro Manuale utente
Manuali Hardware per computer popolari di altre marche
EMC2
EMC2 VNX Series Manuale del proprietario
Panasonic
Panasonic DV0PM20105 Manuale utente
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuale utente
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuale utente
Raidon
Raidon iT2300 Manuale utente
National Instruments
National Instruments PXI-8186 Manuale utente
