SIIG UltraATA 133 PCI Manuale utente
1
UltraATA 133 PCI
Quick Installation Guide
04-0233D
Introducing the UltraATA 133 PCI
TheUltraATA133PCIisanultrahigh-speeddualchannel
UltraATA/133controllerboardforuseinPentium-class
computer.
Features and Benefits
•CompliantwithUltraDMA6ATA/133specifications
•Compliant with PCI v2.2 Plug-n-Play
•Provides two independent Ultra ATA channels
(built-in 256-byte FIFOs per channel)
•Full ACPI power management support
•Supports Ultra DMA 0-6 and Multi-word DMA 0-2
•Breaks the 137GB barrier! Supports hard drives
larger than 137GB
•Coexists with on-board controller
•CRC (Cyclical Redundancy Check) error-checking
provides data verification and achieves flawless
data tranfer
•Flash BIOS for easy upgrade
•Achieves burst data transfer rates up to 133MB/sec
•Workswithvariousbrand,capacityharddiskdrives
and ATAPI devices
System Requirements
•Pentium-class computer with an available PCI slot
•Windows98SE/ME/NT4.0/2000/XP/Server2003
2
Package Contents
•UltraATA 133 PCI adapter
•Driver diskette
•40-pin/80-wire Ultra ATA cable
•This quick installation guide
Layout
IDE1
IDE2
Jumper On
(do not remove)
Pin1 Pin1
HDD
Activity
LED
Figure 1. UltraATA 133 PCI RAID layout
Hardware Installation
General instructions for installing the card are provided
below. Since the design of computer cases and
motherboards vary, refer to your computer’s reference
manual for further information, if needed.
Static Electricity Discharge may permanently damage
your system. Discharge any static electricity build up in
your body by touching your computer’s case for a few
seconds. Avoid any contact with internal parts and
handle cards only by their external edges.
3
1. Turn OFF the power to your computer and any
other connected peripheral devices.
2. Unplug the power cord from the back of the
computer.
3. Remove your computer’s cover.
4. Remove the slot bracket from an available PCI slot.
5. To install the card, carefully align the card's bus
connector with the selected PCI slot on the
motherboard. Push the board down firmly, but
gently, until it is well seated.
6. Replace the slot bracket's holding screw to secure
the card.
Device Connection
The UltraATA 133 PCI is a dual channel Ultra ATA/133
controller that supports up to four IDE hard disk drives
or ATAPI devices. If you plan to use the second IDE
channel (IDE2).
Inordertoachievehigh-speeddatatransfer,a40-pin/80-
wire Ultra ATA ribbon cable is recommended. Also, do
not mix Ultra ATA/133 hard disk with slower IDE or
ATAPI devices on the same channel.
1. Install hard disk drive(s) in chassis.
2. Attach one connector on the long end of the Ultra
ATA ribbon cable to the board's IDE connector and
the other connector(s) to your IDE drive(s). Make
sure pin 1 on the cable (indicated by the colored
stripe) matches pin 1 on the board's IDE connector
and your IDE drive(s).
3. When two drives are installed on the same IDE
channel,makesureonedriveissetupasMasterand
the other as Slave. This rule applies to both IDE
channels.
4
4. The Ultra ATA ribbon cable has two connectors. If
you install only one drive, connect it to the end
connector of the cable. On the other hand, if you
install two drives, connect the master drive to the
end connector of the cable and the slave drive in the
middle connector.
Figure 2. Connecting the cable
5. Reconnect the system power and other peripherals
to your computer.
Driver Installation
This section provides information on how to install the
UltraATA 133 PCI drivers for the following operating
systems:
Windows 98SE...........................................................page 5
Windows ME.............................................................page 6
Verify Windows 98SE/ME Installation..............page 6-7
Windows NT 4.0 .......................................................page 7
Verify Windows NT 4.0 Installation ...................... page 8
Windows 2000 ...........................................................page 8
Windows XP/Server 2003 ....................................... page 9
Verify Windows 2000/XP/2003 Installation ......page 10
Bios Configuration..................................................page 10
5
Windows 98SE
For New Windows 98SE Installation
1. InstalltheboardandfollowMicrosoftproceduresto
install Windows 98SE accordingly.
2. Once Windows has been installed, right click My
Computer and click Properties. Select Device
Manager tab.
3. Double click PCI Mass Storage Controller listed
under Other Devices.
4. Select Driver tab, then click Update Driver button.
5. Insert the driver diskette and click Next.
6. Select Search for a better driver ... and click Next.
7. CheckFloppydiskdrives,unchecktheotherboxes,
then click Next. Click Next again, then Finish.
8. Remove the driver diskette and restart Windows to
complete driver installation.
For Existing Windows 98SE Installation
1. Install the board and boot up Windows 98SE.
2. At the Add New Hardware Wizard, click Next.
3. SelectSearchforthebestdriverforyourdeviceand
click Next.
4. Insertthedriverdiskette,checkFloppydiskdrives,
uncheck the other boxes, then click Next.
5. Click Next,then Finish.
6. Remove the driver diskette and restart Windows to
complete driver installation.
6
Windows ME
For New Windows ME Installation
1. InstalltheboardandfollowMicrosoftproceduresto
install Windows ME accordingly.
2. Once Windows has been installed, right click My
Computer, then click Properties. Select Device
Manager tab.
3. Double click PCI Mass Storage Controller listed
under Other Devices.
4. Select Driver tab, then click Update Driver button.
5. Insert the driver diskette, select Automatic search
forabetterdriver(Recommended),thenclickNext.
6. Click Finish, remove the driver diskette and click
Yes to restart Windows to complete driver
installation.
For Existing Windows ME Installation
1. Install the board and boot up Windows ME.
2. AttheAddNewHardwareWizard,insertthedriver
diskette.
3. Select Automatic search for a better driver
(Recommended), then click Next.
4. Click Finish.
5. Remove the driver diskette and restart Windows to
complete driver installation.
To Verify Windows 98SE/ME Installation
1. Right-click My Computer, then click Properties.
Select Device Manager tab.
2. Double click SCSI Controllers, an entry, Silicon
ImageSiI0680ATA/133Controllershouldbelisted.
7
3. Highlight Silicon Image SiI 0680 ATA/133
Controller and click Properties. A message This
device is working properly is displayed in the dialog
box, the driver has been correctly installed. If any
error message is displayed, remove Silicon Image
SiI0680ATA/133Controllerandrestartyoursystem.
Windows NT 4.0
For New Windows NT 4.0 Installation
1. InstalltheboardandfollowMicrosoftproceduresto
install Windows NT 4.0 accordingly.
2. At the Windows NT Setup screen, press F6 to
specify and add the driver.
3. Press S, select Other, then press Enter.
4. Insert the driver diskette and press Enter.
5. Select Silicon Image SiI 0680 ATA/133 Controller
and press Enter.
6. Press Enter to continue and follow on-screen
instructions to complete Windows NT 4.0
installation.
For Existing Windows NT 4.0 Installation
1. Install the board and boot up Windows NT 4.0.
2. Double click My Computer/Control Panel/SCSI
Adapters, then click the Drivers tab.
3. Click Add… then Have Disk....
4. Insert the driver diskette, type in A:, then click OK.
5. Highlight Silicon Image SiI 0680 ATA/133
Controller and click OK.
6. ClickOK,removethedriverdisketteandrestartNT
to complete driver installation.
8
To Verify Windows NT 4.0 Installation
1. Double click My Computer/Control Panel/SCSI
Adapters.
2. Highlight Silicon Image SiI 0680 ATA/133
Controller from SCSI Adapters listing and click
Properties.Amessage This device isworkingproperly
is displayed in the dialog box, the driver has been
correctly installed.
Windows 2000
For New Windows 2000 Installation
1. InstalltheboardandfollowMicrosoftproceduresto
install Windows 2000 accordingly.
2. Restart your system when prompted during
Windows' installation.
3. At the Windows 2000 Setup screen, press F6 to
install the driver.
4. Insert the driver diskette. Press S, then press Enter.
5. Select Silicon Image SiI 0680 ATA/133 Controller
and press Enter.
6. Press Enter to continue and follow on-screen
instructions to complete installation.
For Existing Windows 2000 Installation
1. Install the board and boot up Windows 2000.
2. At the Found New Hardware Wizard, click Next.
3. Select Search for a suitable driver for my device
(recommended) and click Next.
4. Insertthedriverdiskette,checkFloppydiskdrives,
unchecktheotherboxes,andclickNext. ClickNext
again to continue.
5. Click Finish, remove the driver diskette and restart
Windows to complete driver installation.
9
Windows XP/Server 2003
For New Windows XP/Server 2003 Installation
1. InstalltheboardandfollowMicrosoftproceduresto
install Windows XP accordingly.
2. Restart your system when prompted during
Windows' installation.
3. AttheWindowsSetupscreen,pressF6toinstallthe
driver.
4. Insert the driver diskette. Press Sthen press Enter.
5. Select Silicon Image SiI 0680 ATA/133 Controller
and press Enter.
6. Press Enter to continue and follow on-screen
instructions to complete Windows XP installation.
7. When the Software Installation warning pops up,
click Yes. And when the Hardware Installation
warning pops up, click Yes again.
For Existing Windows XP/Server 2003 Installation
1. Install the board and boot up Windows XP.
2. At the Found New Hardware Wizard, insert the
driver diskette, select Install the software
automatically (Recommended), then click Next.
3. Click Finish, remove the driver diskette and restart
Windows to complete the installation.
10
To Verify Windows 2000/XP/2003 Installation
1. Right click My Computer and click Manage.
2. Select Device Manager.
3. Double click SCSI and RAID Controllers, then
double click Silicon Image SiI 0680 ATA/133
Controller to display driver properties.
4. AmessageThisdeviceisworkingproperlyisdisplayed
in the dialog box, the driver has been correctly
installed.
Bios Configuration
The UltraATA 133 PCI BIOS will appear everytime your
systemstartsup. Ifthebiosdoesn'tshow,pleasetryyour
controllerinanotherPCIslot. Duringthis(Post)process,
thebioswillshowupandindicatethedevicesattachedto
it.
Altri manuali per UltraATA 133 PCI
5
Indice
Altri manuali SIIG Hardware per computer
SIIG
SIIG Cyber PCI I/O Manuale utente
SIIG
SIIG JU-P40412-S1 Manuale utente
SIIG
SIIG SoundWave 5.1 PCI-LP Manuale utente
SIIG
SIIG JJ-E01111-S1 Manuale utente
SIIG
SIIG FireWire 800 + Hi-Speed USB Combo Manuale utente
SIIG
SIIG Low Profile USB Adapter Manuale utente
SIIG
SIIG Silent Mini Notebook Cooler Manuale utente
SIIG
SIIG Low Profile POS 2000RJ Manuale utente
SIIG
SIIG DP SoundWave 4 Channel PCI Manuale utente
SIIG
SIIG CE-H23J11-S1 Manuale utente
SIIG
SIIG Hi-Speed ExpressCard CF R/W Manuale utente
SIIG
SIIG SoundWave 5.1 PCI Manuale utente
SIIG
SIIG NN-8CB212-S1 Manuale utente
SIIG
SIIG Single-Serial PC Card Manuale utente
SIIG
SIIG Serial ATA 4-Channel PCI Manuale utente
SIIG
SIIG Serial ATA PCI RAID Manuale utente
SIIG
SIIG ExpressCard/54 CF R/W Manuale utente
SIIG
SIIG DP FireWire 800 PCIe Manuale utente
SIIG
SIIG SC-SE6412 Manuale utente
SIIG
SIIG ExpressCard 11-in-1 Reader/Writer Manuale utente
Manuali Hardware per computer popolari di altre marche
EMC2
EMC2 VNX Series Manuale del proprietario
Panasonic
Panasonic DV0PM20105 Manuale utente
Mitsubishi Electric
Mitsubishi Electric Q81BD-J61BT11 Manuale utente
Gigabyte
Gigabyte B660M DS3H AX DDR4 Manuale utente
Raidon
Raidon iT2300 Manuale utente
National Instruments
National Instruments PXI-8186 Manuale utente
