TRENDnet TEW-PCI Manuale utente
TRENDnet's TEW-PCI 11Mbps Wireless LAN PCI Card
creates freedom for your desktop PC. This PCI Card plugs
right into your PCI Bus Slot providing wire-free access to
networked resources from your LAN and Internet or create a
network without networking cables. It dynamically shifts
between 11, 5.5, 2, and 1 Mbps for maximum availability and
reliability. Complying with 2.4 GHz frequency band and IEEE
802.11b standard, TRENDnet's TEW-PCI ensures great
security and performance for your wireless networking
environment.
TEW-PCI
11Mbps Wireless PCI Network Card
Wire-Free access to networked resources for desktop PC
Uses 2.4 GHz frequency band (DSSS), which complies
with world wide requirements
Delivers data rate up to 11 Mbps
Dynamically shifts between 11, 5.5, 2, and 1 Mbps
network speed, based on signal strength, for maximum
availability and reliability of connection
Reverse SMA connector for external Antenna
LEDs indicating Power and Link
Supports Windows 95/98/2000/ME/NT4.0/XP and Linux
Ensures great security by providing the 64-bit and 128-bit
Wired Equivalent Privacy (WEP) defined in IEEE 802.11b
standard
3-Year Warranty
BENEFITSFEATURES
Integration Friendly:
Economical:
Flexible:
Cost Effective:
Performance:
Drivers support most popular Network
Operating Systems.
Save time, labor, and material for
network cable installation.
Creates wireless peer-to-peer network
in Ad-Hoc mode or connects to
Ethernet LAN in Infrastructure mode
using wireless Access Point.
Supports IEEE 802.11b wireless
standard, user can connect to any
IEEE 802.11b wireless network.
Connects at a speed up to 11Mbps,
wirelessly!
TEW-PCI (11-01-2002)
TRENDnet
TRENDware, USA
What's Next in Networking
PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TEW-AP100plus: Wireless Access Point with Built in
External Dipole Antenna
TEW-AP100: Wireless Access Point
TEW-PC16: 11Mbps Wireless LAN PCMCIA Card
TEW-PS3: 3-port Wireless Ethernet Print Server
TEW-USB: 11Mbps Wireless USB Adapter
NETWORKING SOLUTIONS
SPECIFICATIONS
Interface Type:
• PCI Local Bus 2.1 compliance
Standards:
• IEEE 802.11b WLAN Standard
Antenna:
• External 2dbi Antenna
(length = 108 mm) with Reverse
SMA connector
Data Rate:
• 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps
Media Access Protocol:
• IEEE 802.11
Module Technique:
• Direct Sequence Spread Spectrum
(DSSS), BPSK, QPSK, CCK
Frequency:
• 2.4 to 2.4835GHz (Industrial Scientific
Medical Band)
Output Power:
• 15 dBm (typical)
Receiver Sensitivity:
• -84dBm
Channels:
• 11 Channels (US & Canada)
Power Consumption:
• 5V, 250mA (Max.)
Coverage Area:
• Indoor: 50 meters @ 11Mbps;
80 meters @ 5.5Mbps or lower
Outdoor:
• 150 meters @11Mbps;
• 300 meters @ 5.5Mbps or lower
Dimensions:
• 135 x 22 x 121 mm
(5.31 x 0.87 x 4.76 inches)
without antenna
Weight:
• 113 grams (4.0 Oz.) with antenna
Temperature:
• Operating: 0° - 55° C (32° - 131° F)
• Storage: -25° - 70° C (-13° - 158° F)
Humidity:
• 10% - 90% (no-condensing)
(Operating and Storage)
Certification:
• FCC, CE
TEW-PCI
11Mbps Wireless PCI Network Card
TEW-PCI
11Mbps Wireless PCI Network Card
TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit
____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: 310-891-1100
Fax: 310-891-1111
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
TRENDnet
TRENDware, USA
R
