USER INSTRUCTIONS

ORIGINAL INSTRUCTIONS DL0122

AIRLINE TYRE INFLATOR

MODEL NO: TPG30P

PART NO: 3082105

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

INTRODUCTION

Thank you for purchasing this CLARKE product. Before attempting to use this

product, please read this manual thoroughly and follow the instructions

carefully. In doing so you will ensure the safety of yourself and that of others

around you, and you can look forward to your purchase giving you long and

satisfactory service.

GUARANTEE

This product is guaranteed against faulty manufacture for a period of 12

months from the date of purchase. Please keep your receipt which will be

required as proof of purchase.

This guarantee is invalid if the product is found to have been abused or

tampered with in any way, or not used for the purpose for which it was

intended.

Faulty goods should be returned to their place of purchase, no product can

be returned to us without prior permission. This guarantee does not effect your

statutory rights.

SPECIFICATION

GENERAL SAFETY PRECAUTIONS

1. Compressed air can be dangerous. Ensure that you are thoroughly familiar

with all precautions relating to the use of compressors and a compressed

air supply.

2. NEVER direct a jet of compressed air at people or animals.

3. ALWAYS ensure that the equipment/tool being used has a safe working

pressure exceeding the output pressure of the compressor that it is

connected to.

4. NEVER exceed the operating pressure stated in the specification.

5. ALWAYS ensure that the air supply is turned off at the tool outlet and vent all

compressed air from the air hose and the equipment attached to it, before

disconnecting air hoses or other equipment from your compressor.

Weight 0.60 kg

Connecting Hose Length 400 mm

Max Working Pressure 8 bar/ 116 psi

Airline Connection size 1/4” BSP

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

6. Ensure all fixed air connections are properly sealed using teflon tape or

pipe sealant.

7. Check the gauge periodically for accuracy and replace if damaged or

inaccurate.

OPERATION

Under or over inflated tyres are dangerous. Consult vehicle owners handbook

before using this tyre inflator.

Attach the airline hose to the tyre inflator and fully tighten. Use PTFE tape if

needed. Turn on the air supply and check that the airline pressure DOES NOT

exceed 8 bar (116psi)

1. Remove the dust cap from the tyre valve and check that the tyre valve is

clean before connecting.

2. Push the connector fully home onto the tyre valve. If the valve leaks, the

connector may need repositioning. Correct position is confirmed by a

steady reading on the gauge.

3. Check the tyre pressure on the gauge.

4. Pull the trigger to inflate the tyre. Re-check the tyre pressure. Note that

when the trigger is pulled, the gauge will show the airline pressure, not the

tyre pressure.

5. To deflate the tyre, partially pull the trigger and check the pressure again.

6. When the tyre pressure is correct, disconnect and remove the connector.

Replace the dust cap on the tyre valve.

IMPORTANT: The air pressure gauge on this product is for guidance only. It is

important that you check the pressure with an approved, calibrated

gauge.

7. Inspect the air hose for wear or damage periodically and replace if

necessary.

8. DO NOT use damaged or leaking hoses. Occasionally clean the product

and lubricate the trigger parts.

CAUTION: THIS PRODUCT MAY HAVE A LOWER WORKING PRESSURE

THAN SOME COMPRESSORS WILL SUPPLY, THEREFORE, AN AIRLINE

REGULATOR SHOULD BE INSTALLED.

CAUTION: AIRLINE LUBRICATORS SHOULD NOT BE USED WITH THIS ITEM

Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com

DECLARATION OF CONFORMITY
